HEIDENHAIN ITNC 530 - CONVERSATIONAL PROGRAMMING User Manual page 636

Setting Meaning
OPTIONS for Data without spaces, separated by commas,
FILESYSTEMTYPE and written in sequence. Switch between
=smb for direct upper and lower case letters.
connection to ip=: IP address of PC to which the TNC is to
Windows networks be connected
username=: User name under which the TNC
is to log on
workgroup=: Work group under which the
TNC is to log on
password=: Password with which the TNC is
to log on (up to 80 characters)
AM Definition of whether the TNC upon
switch-on should automatically connect with
the network drive.
0: Do not automatically connect
1: Connect automatically
The entries username, workgroup and password in the
OPTIONS column may not be necessary in Windows 95
and Windows 98 networks.
With the ENCODE PASSWORD soft key, you can encode
the password defined under OPTIONS.
636 MOD Functions
