7 LBL 1
8 L IZ-4 R0 FMAX
9 APPR CT X+2 Y+30 CCA90 R+5 RL F250
10 FC DR- R18 CLSD+ CCX+20 CCY+30
11 FLT
12 FCT DR- R15 CCX+50 CCY+75
13 FLT
14 FCT DR- R15 CCX+75 CCY+20
15 FLT
16 FCT DR- R18 CLSD- CCX+20 CCY+30
17 DEP CT CCA90 R+5 F1000
18 L X-20 Y+0 R0 FMAX
19 CALL LBL 1 REP 4
20 L Z+250 R0 FMAX M2
21 END PGM PGMWDH MM
HEIDENHAIN iTNC 530
Set label for program section repeat
Infeed depth in incremental values (in space)
Contour approach
Contour
Contour departure
Retract tool
Return jump to LBL 1; section is repeated a total of 4 times
Retract in the tool axis, end program
