FN 18: SYS-DATUM READ: Read system data

With the function FN 18: SYS-DATUM READ you can read system data
and store it in Q parameters. You select the system data through a
group name (ID number), and additionally through a number and an
index.
Group name, ID no.
Program information, 10
Machine status, 20
Cycle parameter, 30
HEIDENHAIN iTNC 530
Number Index
1 -
2 -
3 -
4 -
1 -
2 -
3 -
4 -
5 -
8 -
9 -
10 -
11 -
15 -
17 -
1 -
2 -
3 -
4 -
5 -
6 -
7 -
8 -
9 -
Meaning
mm/inch condition
Overlap factor for pocket milling
Number of the active fixed cycle
Number of the active machining cycle (for cycles with
numbers greater than 200)
Active tool number
Prepared tool number
Active tool axis
0=X, 1=Y, 2=Z, 6=U, 7=V, 8=W
Programmed spindle speed
Active spindle status: –1=undefined, 0=M3 active,
1=M4 active, 2=M5 after M3, 3=M5 after M4
Coolant status: 0=off, 1=on
Active feed rate
Index of prepared tool
Index of active tool
Number of logical axis
0=X, 1=Y, 2=Z, 3=A, 4=B, 5=C, 6=U, 7=V, 8=W
Number of the current traverse range (0, 1, 2)
Set-up clearance of active fixed cycle
Drilling depth / milling depth of active fixed cycle
Plunging depth of active fixed cycle
Feed rate for pecking in active fixed cycle
1st side length for rectangular pocket cycle
2nd side length for rectangular pocket cycle
1st side length for slot cycle
2nd side length for slot cycle
Radius for circular pocket cycle
