HEIDENHAIN ITNC 530 - CONVERSATIONAL PROGRAMMING User Manual page 173

Abbr. Inputs
DR Delta value for tool radius R.
Input range in mm: -99.9999 to +99.9999
Input range in inches: -3.937 to +3.937
Delta value for tool radius R2.
DR2
Input range in mm: -99.9999 to +99.9999
Input range in inches: -3.937 to +3.937
LCUTS Tooth length of the tool for Cycle 22.
Input range in mm: 0 to +99999.9999
Input range in inches: 0 to +3936.9999
ANGLE Maximum plunge angle of the tool for reciprocating plunge-cut in
Cycles 22 and 208 and 25x.
Input range: 0 to 90°
TL Set tool lock (TL: for Tool Locked)
Input range: L or space character
RT Number of a replacement tool, if available (RT: for Replacement
Tool; see also TIME2).
Input range: 0 to 65535
TIME1 Maximum tool life in minutes. This function can vary depending
on the individual machine tool. Your machine manual provides
more information.
Input range: 0 to 9999 minutes
TIME2 Maximum tool life in minutes during TOOL CALL: If the current tool
age exceeds this value, the TNC changes the tool during the next
TOOL CALL (see also CUR.TIME).
Input range: 0 to 9999 minutes
Current age of the tool in minutes: The TNC automatically counts
CUR.TIME
the current tool life (CUR.TIME). A starting value can be entered for
used tools.
Input range: 0 to 99999 minutes
DOC Comment on the tool.
Input range: 16 characters max.
PLC Information on this tool that is to be sent to the PLC.
Input range: 8 characters bit-coded
PLC-VAL Value of this tool that is to be sent to the PLC.
Input range: -99999.9999 to +99999.9999
HEIDENHAIN iTNC 530
Dialog
Tool radius oversize?
Tool radius oversize R2?
Tooth length in the tool axis?
Maximum plunge angle?
Tool locked?
Yes = ENT / No = NO ENT
Replacement tool?
Maximum tool age?
Maximum tool age for TOOL CALL?
Current tool life?
Tool description?
PLC status?
PLC value?
173
