Group name, ID no.
Read basic rotation from the
preset table, 504
Datum table selected, 505
Data from the active pallet table,
510
Existence of machine
parameter, 1010
Example: Assign the value of the active scaling factor for the Z
axis to Q25.
55 FN 18: SYSREAD Q25 = ID210 NR4 IDX3

FN 19: PLC: Transfer values to the PLC

The function FN 19: PLC transfers up to two numerical values or Q
parameters to the PLC.
Increments and units: 0.1 µm or 0.0001°
Example: Transfer the numerical value 10 (which means 1 µm or
0.001°) to the PLC
56 FN 19: PLC=+10/+Q3
HEIDENHAIN iTNC 530
Number Index
Preset -
number
1 -
1 -
2 -
3 -
4 -
MP MP index
number
Meaning
Basic rotation from the ROT column
Return code = 0: No datum table active
Return code not equal to 0: Datum table active
Active line
Palette number from PAL/PGM field
Current line of the pallet table
Last line of the NC program of the current pallet
Return value = 0: MP does not exist
Return code not equal to 0: MP exists
323
