Simrad SH90
144

Mode Buttons

Dialog description
The button is located on the
Mode Buttons
This is simply a selector switch. Click on the button to select
Mode or User, and by this defining the operational function of
the four buttons on the Operating Panel.
Mode
For more information about the
Panel, see 'Mode' field on page 84.
Mode Buttons options
• : The four
Mode Mode
used to select from your favourite display modes.
When the buttons on the Operating Panel are used to
Mode
select display modes, the four buttons will select the four top
display modes in the same order as they appear in the
menu.
Modes
• : The four
User Mode
used to select between four favourite user settings.
Related topics
• Display menu on page 97
• Sort Modes menu on page 106
• Mode on page 143

Movements

Dialog description
The parameter dialog opens when you click the
Movements
button on the
Movements
This function makes it possible to estimate the position of
a tracked school at a given time (from one to ten minutes).
Estimated school position is presented by a violet dot. If you
select 0, the movement estimation is switched off.
Display
buttons on the Operating
Mode
buttons on the Operating Panel can be
buttons on the Operating Panel can be
menu.
Setup
menu.
Sort
