Page 3 Installation manual This manual provides you with the basic information required to install the Simrad SH90 Sonar. For information about the practical use of the product, refer to the Simrad SH90 Operator manual or the Simrad SH90 Reference manual. All user documentation is included on the USB memory device that is provided with the Simrad SH90.
Page 4 If you require maintenance or repair, contact your local dealer. You can also contact us using the following address: simrad.support@simrad.com. If you need information about our other products, visit http: //www.simrad.com. On this website you will also find a list of our dealers and distributors. See also Support information on page 32. Kongsberg Maritime AS...
Page 5: Table Of Contents
When the SH90 is not used................16 When you are docking your vessel ............... 16 If something breaks down................16 When you switch off the SH90 ..............16 Manual operation of the hull unit ..............17 Transducer handling..................17 System description ....................17 System diagram ......................19...
Page 6 Simrad SH90 General installation requirements................31 Supply power ..................... 31 Uninterrupted Power Supply (UPS).............. 31 Wiring......................31 Compass deviation..................32 Noise sources ..................... 32 Dry docking ....................32 Approval by classification society ..............32 Support information ....................32 INSTALLATION PROCEDURE ........... 34 PREPARATIONS ..............
Page 7 Installation manual About the sonar trunk installation ................55 Mounting the sonar trunk ..................56 Protecting the sonar trunk..................57 Sonar trunk installation principles................57 Installation of a trunk with open blister............58 Installation of a trunk with oil filled blister ........... 59 Sonar trunk installation measurements and check list..........60 INSTALLING THE HULL UNIT ..........
Page 8 Simrad SH90 List of cables ......................93 Cable procedures ....................99 Connecting AC mains to the Uninterrupted Power Supply ......100 Connecting the video cable from the Processor Unit to the colour display ..................... 101 Connecting the USB cable from the Operating Panel to the Processor Unit ......................
Page 9 Opening the Installation menu ..............147 Configuring and testing the interface to the motion reference unit ....147 Entering the stabilisation offset angle into the SH90........149 Connecting a secondary Operating Panel.............150 Parts and tools required to install a secondary Operating Panel ....150 Physical installation of the Operating Panel ..........
Page 10 Starting up the SH90 system ................193 Preparations before the SH90 system is started ........... 193 Starting up the SH90 system, bridge actions ..........194 Starting up the SH90 system, sonar room actions ........195 Alignment of the sonar picture ................196 Defining own ship parameters ................197 Specifying ship dimensions ...............
Page 11 Weights and outline dimensions................217 Power specifications .....................218 Environmental specifications ................219 Minimum display requirements................220 TELEGRAM FORMATS ............ 221 Telegrams received and sent by the SH90............222 Course gyro telegrams................222 Speed log telegrams .................. 222 GPS telegrams ..................223 ITI and trawl system telegram..............223 Echo sounder telegrams................
Page 12 Simrad SH90 HFB Trawl headrope to footrope and bottom ..........238 MDS Measured data shoal................. 238 MTW Water temperature at the trawl ............239 PSIMP-D PI Sensor data ................239 PSIMP-F PI Sensor data................241 TDS Trawl door spread ................241 TFI Trawl filling ..................
Page 13 Coatings....................273 Re-packaging......................273 Temperature protection..................273 Circuit board handling and packaging..............274 Electro-Static Discharge (ESD)................275 Disposal ........................275 SH90 CABLE DETAILS ........... 277 Cabling principles....................278 Cables to peripheral devices.................278 Positioning system interface ..............279 Echo sounder system interface ..............279 Trawl sonar interface................. 279 Catch monitoring system interface .............
Page 14 Simrad SH90 Cable terminations....................303 Cable identification....................303 INSTALLATION REMARKS ..........304 323776/D...
Page 15: About This Manual
The purpose of this manual is to provide the information and basic drawings required for installation of the Simrad SH90. For more detailed information about the practical use of the product, refer to the Simrad SH90 Operator manual or the Simrad SH90 Reference manual.
Page 16 Simrad SH90 Installation drawings Detailed vessel specific mechanical drawings for the installation must be provided by the customer, or any shipyard contracted to perform the installation. Kongsberg Maritime AS may, on special order, provide assistance to these drawings. Drawings must be approved by the appropriate vessel certification authority prior to installation of the system.
Page 17: Simrad Sh90
Simrad SH90 Simrad SH90 Study this chapter to familiarize yourself with the Simrad SH90. Topics • System description on page 17 • System diagram on page 19 • System units on page 20 • Scope of supply on page 23 •...
Page 18: Important
When the SH90 is not used To protect the SH90 when it is not in use, we strongly advice you to hoist the transducer, even though you may not switch off the power. In narrow or shallow waters this is very important, since you may - in worst case - run the transducer into the bottom.
Page 19: Manual Operation Of The Hull Unit
Therefore, before you start the manual operation, read carefully through the relevant procedure(s). You will then familiarize yourself with the methods and the safety requirements. Important The relevant procedures are located in the Simrad SH90 Operator Manual and in the Simrad SH90 Reference Manual. Transducer handling Note All transducers must be handled as delicate items.
Page 20 Simrad SH90 signal processing system using the full dynamic range of the signals. In addition to the traditional single frequency transceiver system, the Simrad SH90 contains an advanced frequency modulated filter system (FM). 323776/D...
Page 21: System Diagram
Simrad SH90 System diagram A standard SH90 system diagram is provided. Interface capabilities, uninterrupted power supplies and power cables are not shown. Processor Unit SIMRAD Colour display MENU Operating Panel Operating Panel Power Supply SIMRAD SX90 Transceiver Unit SIMRAD Power Supply Unit...
Page 22: System Units
• Hull Unit on page 21 • Transducer on page 22 Colour display Any commercial colour display can be used with the Simrad SH90 system. The chosen display must be designed for maritime use, and it must meet the minimum performance specifications.
Page 23: Operating Panel Power Supply
A small commercial power supply is implemented to provide stand-by power to the Operating Panel. The power supply is connected to the Processor Unit. Transceiver Unit The SH90 Transceiver Unit is located in the sonar room, close to the Hull Unit. The transceiver performs the transmission and reception control of the 480 transmitters and 480 receiver channels.
Page 24: Transducer
Simrad SH90 When the sonar is switched on, press the button on the Operating Panel to lower Down the transducer into the water. Before the sonar is switched off, press the button on the Operating Panel to retract the transducer into the installation trunk for protection.
Page 25: Scope Of Supply
Simrad SH90 Scope of supply Please observe the standard and optional parts provided with the Simrad SH90 delivery. Topics • Main units included with the standard delivery on page 23 • Additional items on page 23 Related topics • Additional required items on page 24 •...
Page 26: Additional Required Items
• Course gyro on page 25 Colour display The Simrad SH90 requires a VGA or DVI colour display with a resolution of at least 1280 x 1024 pixels. The SH90 Processor Unit offers two video outputs. A secondary display may then be mounted at an other location on the vessel.
Page 27: Installation Trunk
• Installation trunk on page 26 Speed log In order to operate correctly, the Simrad SH90 requires input from a speed log. In most cases a suitable sensor is already installed on the vessel. A differential global positioning system ((D)GPS) can also be used.
Page 28: Optional Items
• Configuring and testing the interface to the course gyro on page 161 Optional items The following optional equipment and functionality may be ordered at an additional charge to augment the standard Simrad SH90 system delivery, or purchased locally by the installation shipyard or end user. Topics •...
Page 29: Scientific Interface
Scientific interface KIT-203477 Other peripheral equipment The Simrad SH90 provides several serial lines. Two of these are used to interface to the speed log and course gyro. The remaining serial lines can be used to communicate with other peripheral equipment.
Page 30 Simrad SH90 Motion reference unit (MRU) The SH90 offers a built-in motion sensor to provide stabilisation of the sonar beams. You may increase the efficiency and accuracy if you install a separate motion reference unit (MRU). The SH90 provides an interface to the...
Page 31: External Motion Reference Unit (Mru)
• Radio buoys connection interface on page 280 External motion reference unit (MRU) By default, the SH90 uses a built-in motion reference detector mounted on the hull unit. For improved accuracy, and external motion reference unit (MRU) may be used.
Page 32: General Supply Conditions
Related topics • Connecting a secondary Operating Panel on page 150 General supply conditions The following general supply conditions apply to this Simrad SH90 delivery. Topics • Equipment responsibility on page 30 • Receipt, unpacking and storage on page 30...
Page 33: General Installation Requirements
The Uninterrupted Power Supply must have the capacity to independently maintain power to the system for a minimum of 10 minutes. This ensures that the SH90 can be switched off in a controlled manner in the event of a power failure.
Page 34: Compass Deviation
The shipowner and shipyard performing the installation are responsible for obtaining the installation approval. Support information If you need technical support for your Simrad SH90 you must contact your local dealer, or one of our support departments. A list of all our dealers is provided on http://www.simrad.com.
Page 35 : +34 966 852 304 Telefax • simrad.spain@simrad.com E-mail address • http://www.simrad.es Website • : Kongsberg Underwater Technology Inc / Simrad Fisheries Company name • : 19210 33rd Ave W, Lynnwood, WA 98036, USA Address • : +1 425 712 1136 Telephone •...
Page 36: Installation Procedure
Simrad SH90 Installation procedure The Simrad SH90 is a complex and advanced product for professional use. An overall installation procedure is provided below. The procedure does not describe any detailed tasks, but refers to the relevant procedures in this manual.
Page 37 → Basic cable requirements on page 300 Perform the “setting to work” procedures. Note In order to set up the SH90 in a safe and correct manner, these procedures must be complied to! → Setting to work on page 166 Connect the peripheral units.
Page 38: Preparations
Then proceed to the Hull Unit installation description. This chapter provides the information necessary to plan the installation of the Simrad SH90 according to Kongsberg Maritime’s requirements. Correct installation of the hull unit and transducer is vital to the system performance.
Page 39: Installation Drawings
• Drawing file on page 250 Necessary tools and equipment The installation of the Simrad SH90 must take place in dry dock, and the work must be done by a qualified shipyard. In order to do the SH90 installation, all necessary tools and equipment for mechanical hull work, cabinet installation and electrical wiring must be available.
Page 40: Worker Skills
Simrad SH90 Worker skills The installation of the Simrad SH90 is a demanding task, and it is very important that the shipyard workers that are involved in the work are competent. As a minimum, the following certified craftsmen must be available: •...
Page 41: Determing The Location Of The Hull Unit
Preparations Determing the location of the hull unit Observe general recommendations related to the physical location of the hull unit. Topics • Fore and aft location on page 39 • Athwartships location on page 40 • Important considerations related to noise on page 40 Fore and aft location The hull unit should preferably be located within 1/3 to 1/10 of the vessel’s Length Between Perpendiculars (LBP) from its Forward Perpendicular (FP).
Page 42: Athwartships Location
The installation trunk must be installed so that it will remain vertical under normal operating conditions. The primary sources of underwater disturbance (other than a vessel’s main propeller and bow/stern thruster) that affect SH90 reception are: • Main or bilge keels •...
Page 43: Sonar Room Requirements
The “sonar room” is the compartment in which the Transceiver Unit, the Power Supply Unit and the hull unit are installed. Observe these minimum requirements to obtain suitable working conditions for Simrad SH90 installation, use and maintenance. It is strongly recommended to use a dedicated compartment to house the hull unit, the Transceiver Unit and the Power Supply Unit.
Page 44: Size And Access
The sonar room must be dimensioned to house all the relevant cabinets that comprise the Simrad SH90. The sonar room must not be used for any other machinery. The sonar room must not be unnecessarily obstructed by girders, pipes etc, which may cause installation problems or impede maintenance.
Page 45: Cable Protection
Preparations In the room, the air inlet must whenever possible be located close to the deck and the outlet as high as possible. A funnel shaped drip-collector must be mounted below the vent pipes to divert moisture to the bilge. On the main deck, the best ventilation is provided when the outlet pipe is at least four meters higher than the inlet pipe.
Page 46: Sonar Room Arrangement Example
Simrad SH90 Sonar room arrangement example These drawings illustrate a typical sonar room with ample space for the hull unit, the Power Supply Unit, the Transceiver Unit and personnel. Topics • Sonar room arrangement example 1 – Top view on page 44 •...
Page 47: Sonar Room Arrangement Example 2 - Side View
Preparations Sonar room arrangement example 2 – Side view The Power Supply Unit can be mounted, over, under or besides the Transceiver Unit. 323776/D...
Page 48: Hull Unit Orientation Example
Irrespective of the hull unit orientation, the transducer shall not be mechanically aligned. Transducer alignment is performed in the SH90 Processor Unit by rotating the echo presentation on the display. Related topics •...
Page 49: Acoustic Noise
It is therefore important that we keep this noise level as low as possible in order to obtain long range and dependable interpretation. Even with the advanced noise filtering offered by the SH90, we must address the noise challenge during the planning and preparations for the system installation.
Page 50: Self Noise
Simrad SH90 Noise sources on sonars Electrical noise Analogue noise Digital noise (generators, pumps, in amplifiers in analogue parts refrigerator systems, etc) Signal Amplifier processing Converter Electrical noise from power supplies (CD015904-001) Biological disturbances Interference Cavitation Propeller noise Flow noise...
Page 51 Preparations Machinery noise The main contributor is usually the main engine on board the vessel. The contribution from auxiliary machinery may, however, be considerable, especially if some of it is in poor shape. The machinery noise can be transmitted to the transducer as a: •...
Page 52: Ambient Noise
Simrad SH90 of the boundary layer. When the flow speed is high, the turbulence can be violent enough to destroy the integrity of the water. Small voids or cavities in the water will occur and this is called cavitation. Boundary layers underneath a vessel...
Page 53: Fishing Gear Noise
Preparations Precipitation noise The ambient noise is usually not a limiting factor to the performance of the sonar and echo sounders. In some areas, however, where many fishing vessels are operating together the engine and propeller noise from other vessels might be disturbing. Interference from hydroacoustic instruments located in other vessels may also be a limiting factor.
Page 54 Note The information here must be considered as general advice. Each SH90 installation must be handled separately depending on the hull design and the other electrical and mechanical systems installed.
Page 55 Use shielded cables with correct grounding is necessary. Separate SH90 cables from other cables with heavy currents or transients. Use a supply voltage without disturbances like transients from the supply itself, or from other equipment fed by the same supply.
Page 56: Installing The Sonar Trunk
Simrad SH90 Installing the sonar trunk This chapter explains how to install the sonar trunk. Topics • About the sonar trunk installation on page 55 • Mounting the sonar trunk on page 56 • Protecting the sonar trunk on page 57 •...
Page 57: About The Sonar Trunk Installation
Installing the sonar trunk About the sonar trunk installation The sonar trunk provides the physical foundation for the entire hull unit gantry. The trunk further penetrates the hull, and it is therefore a crucial part of the hull unit assembly. In order to ensure proper sonar operation, the location of the sonar trunk must be carefully selected.
Page 58: Mounting The Sonar Trunk
Simrad SH90 Mounting the sonar trunk Purpose Orientation of the sonar trunk This procedure offers the general steps of the sonar trunk installation. If required, additional procedures providing more information must be provided by the installation shipyard. Prerequisites The installation shipyard must prepare and provide all relevant resources.
Page 59: Protecting The Sonar Trunk
Installing the sonar trunk Observe these installation principles. Important The height from the top of the trunk flange to the underside of the protection blister must be selected as shown in the figures in section Sonar trunk installation principles on page 57. In order to obtain optimal sonar performance, the total height of the trunk must be as close as possible to its stated minimum height.
Page 60: Installation Of A Trunk With Open Blister
Simrad SH90 Installation of a trunk with open blister 323776/D...
Page 61: Installation Of A Trunk With Oil Filled Blister
Installing the sonar trunk Installation of a trunk with oil filled blister 323776/D...
Page 62: Sonar Trunk Installation Measurements And Check List
Simrad SH90 Sonar trunk installation measurements and check list For future reference, the measurements “A”, “B”, “C” and “D” from the drawing must be made and noted in the table below. Trunk installation measurements Inches Millimeters “A” “B” “C” “D”...
Page 63: Installing The Hull Unit
Installing the hull unit Installing the hull unit This chapter describes the physical installation of the Simrad SH90 Hull Unit. Topics • About the hull unit installation on page 62 • Hull unit familiarization and main parts identification on page 63 •...
Page 64: About The Hull Unit Installation
Simrad SH90 About the hull unit installation The hull unit is a large and crucial part of the sonar system. Due to its physical size and weight, and the fact that the trunk penetrates the vessel hull, it is very important that the hull unit is installed and secured properly. The installation shipyard must provide all necessary installation drawings, and if required, these must be approved by the applicable authorities.
Page 65: Hull Unit Familiarization And Main Parts Identification
Installing the hull unit Hull unit familiarization and main parts identification Upper limit switch S304 Transducer cable Transducer shaft Lower limit switch S305 Grease nipple (Pressure release plug on rear side) Air bleeding plug Hoisting motor Motor Control Unit Hoisting unit Mounting flange Installation trunk Transducer...
Page 66: Motor Control Unit Familiarization And Main Parts Identification
Simrad SH90 Motor Control Unit familiarization and main parts identification Internal 24 Vdc power supply Ethernet connector HOIST STOP REMOTE LOWER P302 S302 Hand crank S303 Mains filter Hull Unit Controller circuit K303 S301 board K302 Fuse for internal power...
Page 67 Installing the hull unit Note The transducer is protected with a thick layer of foam to prevent damage during transport and hull unit installation. This protection must remain attached while the hull unit is being manoeuvred into the sonar room. Lifting eye on the hoisting unit Mounting hardware (wooden cradle and support construction) Transducer protection (thick foam)
Page 68: Mounting The Hull Unit
Simrad SH90 Important Use the correct lifting eye! There are two lifting eyes on each side of the hull unit: one on the hoisting unit and one on the top of the transducer shaft. Make sure that you use the lifting eye on the hoisting...
Page 69 Installing the hull unit Related topics • Hull unit installation check list on page 71 Procedure To make sure that the procedure is followed correctly, and in the right order, tick off each task after you have done it. Use a tackle to lower the hull unit (with the foamed transducer protection in place) into the sonar room [_____] Ok Remove the blind cover from the trunk.
Page 70: Mounting The Mechanical Support
[_____] Ok Transducer alignment Irrespective of the hull unit orientation, the transducer shall not be mechanically aligned. Transducer alignment is performed in the SH90 Processor Unit by rotating the echo presentation on the display. Related topics • Alignment of the sonar picture on page 196...
Page 71: Visual Inspection Of The Transducer
Even a small an nearly invisible damage to the transducer may cause water to penetrate the transducer, and in time this will damage the transducer beyond repair. [_____] Ok If you suspect damage, take a high resolution picture, and contact Simrad’s support department for advice. [_____] Ok Hoist the transducer using the hand crank provided.
Page 72: Lowering And Hoisting The Transducer Manually Using The Hand Crank
Simrad SH90 Lowering and hoisting the transducer manually using the hand crank Purpose Location of S301 in the Motor Control Unit Observe this procedure to lower the transducer manually using the hand crank. HOIST STOP REMOTE LOWER Important When not in use, the hand crank must always be placed inside the Motor Control Unit.
Page 73: Hull Unit Installation Check List
Installing the hull unit Hull unit installation check list Perform a close visual inspection of the sonar room and the physical installation of the hull unit. Refer to the applicable requirements provided in section Sonar room requirements on page 41, and fill in the table below. Item Are the access hatches satisfactory constructed and located? Is the heating satisfactory?
Page 74: Installing The Transceiver Unit
Installing the Transceiver Unit Purpose Installation of mounting brackets (1) This procedure explains how to install the Simrad SH90 Transceiver Unit. The Transceiver Unit is normally positioned in the sonar room close to the hull unit. Prerequisites Free bulkhead space is required to mount the Transceiver Unit cabinet.
Page 75 Installing the Transceiver Unit absorbers. These Procedure bars are supplied by Simrad. Prepare the installation site. Observe the general sonar room requirements provided in section Sonar room requirements on page 41. Provide ample space around the cabinet to allow for inspection, maintenance and parts replacement.
Page 76 Simrad SH90 Weld the mounting brackets securely to the bulkhead. [____] Ok Installation of mounting brackets (2) Deckhead Bulkhead Deck Angle bars with threaded holes for shock absorbers. These bars are supplied by Simrad. Use a chain fall or similar device to lift the Transceiver Unit into position.
Page 77 Installing the Transceiver Unit Connect the grounding cable from the Transceiver Unit to the mounting bracket. [____] Ok Installation of Transceiver Unit with grounding cable Upper shock absorber Transceiver Unit Heat Exchanger Grounding cable Grounding cable, detail Do not connect the transducer cable connector. This will be done later in the installation process.
Page 78: Installing The Power Supply Unit
This chapter explains how to install the Simrad SH90 Power Supply Unit. The SH90 Power Supply Unit must be installed close to the Transceiver Unit. The distance between the two cabinets is limited by the length of the power cable between them.
Page 79: Power Supply Unit Preparations
Installing the Power Supply Unit Power Supply Unit preparations Free bulkhead space is required to mount the Power Supply Unit cabinet. We recommend that it is mounted over, below or besides the Transceiver Unit. Provide ample space around the cabinet to allow for inspection, maintenance and parts replacement.
Page 80: Power Supply Unit Installation Procedure
Simrad SH90 Power Supply Unit installation procedure Purpose This procedure describes how to install the Power Supply Unit. Description The Power Supply Unit must be mounted on the bulkhead close to the Transceiver Unit. Observe the limited length of the cables.
Page 81: Installing The Bridge Units
Installing the bridge units Installing the bridge units This chapter explains how to install the Simrad SH90 hardware units normally positioned on the bridge. Note The installation shipyard must provide all necessary installation drawings, and if required, these must be approved by the applicable authorities.
Page 82: Preparations For Installation
A display selector will allow you to set up the SH90 (or any other system) to be viewed on any display, and this may be chosen depending on the current operations taking place.
Page 83: Location Of The Processor Unit
Installing the bridge units Related topics • Maximum distances between the units on page 82 • Installation of the colour display on page 83 Location of the Processor Unit The computer should be installed inside a console, in a cabinet or on a desk. Make sure that adequate ventilation is available to avoid overheating.
Page 84: Location Of The Operating Panel Power Supply
Simrad SH90 Location of the Operating Panel Power Supply The Operating Panel Power Supply supplied with the Simrad SH90 provides the stand-by power for the Operating Panel. The power supply connects to the rear side of the Processor Unit. We recommend that the power supply is placed in the immediate vicinity of the Processor Unit.
Page 85: Installation Of The Colour Display
Installing the bridge units Installation of the colour display Purpose This procedure explains how to install the colour display. Procedure Prepare the location and the necessary tools. Observe the installation requirements. The display must be located so that it is best protected from glare which reduces readability.
Page 86 Simrad SH90 If you intend to mount the processor Unit in a 19” rack, you can disregard this procedure. However, you may then wish to remove the bottom plate and shock absorbers as described in this procedure, as these will not be required.
Page 87: Installation Of The Operating Panel
[____] Ok Installation of the Operating Panel Purpose This procedure explains how to install the Operating Panel provided with the SH90 sonar. The Operating Panel is designed to be recessed in a panel. 323776/D...
Page 88: Installation Of The Operating Panel Power Supply
Simrad SH90 Procedure 372 mm ø7x4 Prepare the location and the necessary tools. [____] Ok Mount the operating panel in an almost horizontal position to facilitate operation of the trackball. The necessary mounting Nut plate (CD015022M) hardware (four screws, four nut plates and four bolt covers) are supplied in the standard delivery.
Page 89: Installing The Uninterrupted Power Supply
Installing the Uninterrupted Power Supply Installing the Uninterrupted Power Supply In order to ensure continuous operation of the Simrad SH90 independent of varying quality of the vessel's mains supply, the use of uninterrupted power supplies (UPS) is required. Two UPS units are used: •...
Page 90: Cable Layout And Interconnections
Simrad SH90 Cable layout and interconnections This chapter provides the cable plan and cable installation requirements for the Simrad SH90. Topics • Read this first! on page 89 • Cable plan on page 91 • List of cables on page 93 •...
Page 91: Read This First
For more information, see the basic cable requirements. Note Before you start the SH90 cabling, ensure that the mains circuit breaker for the system is switched off. Observe the relevant procedures for health, environment and safety. Important...
Page 92 Simrad SH90 Related topics • Cabling principles on page 278 • Cables to peripheral devices on page 278 • Cable drawings on page 281 • Basic cable requirements on page 300 323776/D...
Page 93: Cable Plan
Cable layout and interconnections Cable plan Observe the cable plan for the Simrad SH90. Cables identified with an asterisk (*) are provided by Simrad. Bridge cables AC power C12* SIMRAD C10* C11* C13A, C13B, C13C etc Serial line communication Ship 's network...
Page 94: Sonar Room Cables
Transceiver Unit Power Supply Unit Uninterrupted Power Supply Motor Control Unit Ethernet communication to bridge Ethernet communication to Motor Control Unit Transducer cable 3–phase AC mains to Motor Control Unit Cables identified with an asterisk (*) are provided by Simrad. 323776/D...
Page 95: List Of Cables
→ AC mains with IEC 60320 socket and inline plug on page 289 SH90/C04 +12 Vdc from Operating Panel power supply to Processor Unit This is a commercial power supply. It is provided with the SH90. The DC cable is physically fixed to the power supply body.
Page 96 Minimum one cable must be connected, two parallel Ethernet cables may be used to provide redundancy. Each cable must be a high quality Ethernet cable. They can be provided by the installation shipyard, or ordered from Simrad. → Connecting the Processor Unit to the Transceiver Unit on page 108 →...
Page 97 → DVI–I Display cable on page 298 SH90/C10 Operating Panel USB cable to Processor Unit This cable is provided with the SH90 Operating Panel. It is a standard USB data cable with length 4,5 meters. → Connecting the USB cable from the Operating Panel to the Processor Unit on page 102 →...
Page 98 → AC mains with IEC 60320 socket and inline plug on page 289 SH90/C16 AC mains to Transceiver Unit This cable is provided with the SH90. It is a standard mains supply cable. The transceiver end is normally terminated with an IEC C13 inline socket.
Page 99 Motor Control Unit. Do not substitute with a standard cable. SH90/C20 Transducer cable This transducer cable is provided with the SH90. It contains one cable pair for each of the transceiver channels in a special screened cable. The transducer cable is physically attached to the top of the transducer shaft, and connects to a special connector on the side of the Transceiver Unit.
Page 100 Simrad SH90 SH90/C21 AC mains to Power Supply Unit This cable is provided with the SH90. It is a standard mains supply cable. The power supply end is terminated with an IEC C13 inline socket. The other end is terminated in an AC connector suitable for the chosen Uninterrupted Power Supply (UPS) system.
Page 101: Cable Procedures
In order to ease access for maintenance purposes, and to allow for vibration, make sure that some slack is provided for each cable. Before you do the SH90 cabling, ensure that the mains circuit breakers are switched off. Do not mount the flexible transducer cable to the Transceiver Unit. This will be described later.
Page 102: Connecting Ac Mains To The Uninterrupted Power Supply
Simrad SH90 Connecting AC mains to the Uninterrupted Power Supply Purpose There are two Uninterrupted Power Supply (UPS) locations; the sonar room and the bridge. Standard commercial AC mains cables are used. The power supply end is normally terminated with an IEC C13 inline socket.
Page 103: Connecting The Video Cable From The Processor Unit To The Colour Display
If you have two displays both can be connected simultaneously, but they will show the same picture. Cable identifier This is cable SH90/C09 Related topics • Cable plan on page 91 • List of cables on page 93 • DVI–I Display cable on page 298 •...
Page 104: Connecting The Usb Cable From The Operating Panel To The Processor Unit
Simrad SH90 Connecting the USB cable from the Operating Panel to the Processor Unit Purpose This procedure explains how to connect the USB cable from the Operating Panel to the Processor Unit. This is a standard commercial USB data cable. The cable length is 4,5 meters.
Page 105: Connecting The Dual Interface Cable From The Operating Panel To The Processor Unit
9-pin female and male D–connectors connected to appropriate sockets on the rear side of the Processor Unit. Cable identifiers These are cables SH90/C11 SH90/C12 Related topics • Cable plan on page 91 • List of cables on page 93 •...
Page 106: Connecting The Operating Panel Power Supply To The Processor Unit
Simrad SH90 Connecting the Operating Panel Power Supply to the Processor Unit Purpose In order to facilitate the sonar's on/off function, the Operating Panel must be fed a permanent stand-by power. This supply power is provided by a small commercial power supply connected to the rear side of the Processor Unit.
Page 107: Connecting Ac Mains And Ground To The Processor Unit
SH90/C03 while the grounding cable is SH90/C06 Important This cable is provided with the SH90. It is a standard commercial mains cable. The computer end is normally terminated with an IEC C13 inline socket. The other end is terminated in an AC connector suitable for the chosen Uninterrupted Power Supply (UPS) system.
Page 108: Connecting Ac Mains To The Colour Display
Simrad SH90 Connecting AC mains to the colour display Purpose This cable is provided with the display. It is a standard commercial mains cable. The display end is normally terminated with an IEC C13 inline socket. The other end is terminated in an AC connector suitable for the chosen Uninterrupted Power Supply (UPS) system.
Page 109: Connecting Ground To The Operating Panel
Connecting ground to the Operating Panel Purpose This is a standard grounding cable. Cable identifier This is cable SH90/C07 Related topics • Cable plan on page 91 • List of cables on page 93 • Vessel ground on page 288 Procedure Connect the grounding cable to the Operating Panel.
Page 110: Connecting The Processor Unit To The Transceiver Unit
Simrad SH90 Connecting the Processor Unit to the Transceiver Unit Purpose The Transceiver Unit is connected to the Processor Unit on the bridge using an Ethernet line. The cable must be provided by the installation shipyard, but it may be ordered from Kongsberg Maritime.
Page 111 Cable layout and interconnections Note Each end of the Ethernet cables must be terminated with a Phoenix Contact Variosub RJ45 connector. Connectors (and mounting Quickcon instructions) are provided in the sonar delivery. 323776/D...
Page 112: Connecting Ac Mains To The Transceiver Unit
Simrad SH90 Connecting AC mains to the Transceiver Unit Purpose The mains voltage for the Transceiver Unit is 230 Vac. The AC mains cable is a standard commercial item. The transceiver end is terminated with an IEC C13 inline socket.
Page 113: Connecting The Power Cable From The Power Supply Unit To The Transceiver Unit
DC power from the Power Supply Unit to the Transceiver Unit. The cable is fastened to the bottom of the Power Supply Unit, and thus provided by Simrad. It is approximately 1,5 meters long. Cable identifier This is cable SH90/C25 Related topics •...
Page 114: Connecting The Ethernet Cable From The Power Supply Unit To The Transceiver Unit
The Power Supply Unit must be installed close to the Transceiver Unit. Ethernet cable with noise suppressor is used from the Transceiver Unit to the Power Supply SH90/C29 Unit. The cable is provided by Simrad. It is 1,6 meters long. Cable identifier This is cable SH90/C29 Related topics •...
Page 115: Connecting Ac Mains And Ground To The Power Supply Unit
Two cables are used: • AC mains cable from the Uninterrupted Power Supply to the Power Supply SH90/C24 Unit. This cable is provided with the sonar. • Grounding cable from Power Supply Unit to vessel ground. This cable SH90/C30 must be provided by the installation shipyard.
Page 116 Simrad SH90 Connect the grounding cable from the connection bolt at the bottom of the Power Supply Unit to vessel ground. The ground connection bolt is located under the Power Supply Unit. The ground cable must be connected to the vessel's ground in the fuse box (or other common grounding point).
Page 117: Connecting Ac Mains To The Motor Control Unit
This is a special mains cable for 3-phase AC mains. It must be provided by the installation shipyard. Observe the cable specifications, see 3–phase AC mains to Motor Control Unit on page 290. Cable identifiers This is cable SH90/C18 HOIST STOP REMOTE LOWER...
Page 118: Connecting The Transceiver Unit To The Motor Control Unit
Connecting the Transceiver Unit to the Motor Control Unit An Ethernet cable with noise suppressor is used from the Transceiver Unit to the Motor Control Unit. The cable is provided by Simrad. It is 9,7 meters long. Cable identifier This is cable...
Page 119: Connecting The Ethernet Cable For Scientific Output
Use a commercial high quality Ethernet cable suitable to match the bandwidth on the ship's network. Cable identifier This is cable SH90/C14 Related topics • Cable plan on page 91 • List of cables on page 93 • RJ45 Ethernet, straight on...
Page 120: Connecting The Transducer Cable
Simrad SH90 Connecting the transducer cable The transducer cable is provided by Kongsberg Maritime. It is physically connected to the top of the transducer shaft, and terminated in the other end with a large connector. Note Do not mount the flexible transducer cable to the Transceiver Unit. This operation is described later.
Page 121: Moxa Cp114El-I Serial Adapter Setup
Important This functionality is intended for certified maintenance technicians and service engineers from Simrad. We strongly advice end users not to alter these parameters. Topics • Serial line support on page 119 • Jumper and DIP switch settings on page 119 •...
Page 122: Software Setup (Windows Xp)
Note This procedure is intended for certified maintenance technicians and service engineers from Simrad. It is assumed that you are familiar with the Windows operating systems, computer technology, and interface principles. We strongly advice end users not to alter the parameters described.
Page 123 Cable layout and interconnections Click to open the dialog. Port Setting Port Set up the interface parameters to suit your preferences. Select port number (by default, the port chosen before you opened the dialog box is shown) Select the Auto Enumerating COM Number option to map subsequent ports automatically.
Page 124: Software Setup (Windows 7)
Note This procedure is intended for certified maintenance technicians and service engineers from Simrad. It is assumed that you are familiar with the Windows operating systems, computer technology, and interface principles. We strongly advice end users not to alter the parameters described.
Page 125: Adapter Cable
Cable layout and interconnections Click to open the configuration dialog box. Port Setting Set up the interface parameters to suit your preferences. Select port number (by default, the port chosen before you opened the dialog box is shown) Select the Auto Enumerating COM option to map subsequent ports Number...
Page 126 Simrad SH90 9–pin D-connector converter RS-232 RS-422 RS485 (4–wire) RS485 (2–wire) — TXD-(A) TXD-(A) — TXD+(B) TXD+(B) RXD+(B) RXD+(B) Data-(B) RXD-(A) RXD-(A) Data-(A) — — — — — — — — — — — — — 323776/D...
Page 127: References To Detailed Cable Drawings And Specifications
Cable layout and interconnections References to detailed cable drawings and specifications All detailed information about the cables are provided in the appendix. See Cable drawings on page 281. Related topics • Generic RS-232 Serial line (Three wires) on page 282 •...
Page 128: Interfacing Peripheral Equipment
Interfacing peripheral equipment This chapter describes how the Simrad SH90 shall be set up to accept the signals from peripheral devices, and how you can verify that the various interfaces are fully functional. The chapter also describes how connect the Simrad SH90 to other acoustic systems to allows for transmit synchronisation.
Page 129: Overview Of Interfaces And Supported Telegram Formats
The GLL telegram may be received from integrated instruments using the “ii” talker identifier. The Simrad ITI system uses the same talker identifier “ii”, and this has caused some confusion for some of our users. In order to rectify this, the ITI GLL telegram has been inhibited.
Page 130 Simrad SH90 Echo sounder Path: Installation menu→I/O Setup→Sensors→Echo sounder • EchoNMEA – DBS Depth below surface on page 229 – DBT Depth below transducer on page 229 – DPT Depth on page 229 – DBS Depth of trawl below surface on page 237...
Page 131: Telegrams Sent To External Devices
Interfacing peripheral equipment Speed sensor Path: Installation menu→I/O Setup→Sensors→Speed • SpeedLog – VBW Dual ground and water speed on page 233 – VTG Course over ground & ground speed on page 235 – RMC Recommended minimum specific GNSS data on page 233 –...
Page 132: Monitoring And Changing The Interface Settings
Simrad SH90 Trawl system Path: Installation menu→I/O Setup→Sensors→Trawl system • Simrad ITI – TPP Tracked target position or marker on page 242 Target output Path: Installation menu→I/O Setup→Sensors→Target Output • CM60 – MDS Measured data shoal on page 238 Monitoring and changing the interface settings This section defines the default interface settings provided at delivery.
Page 133: Changing The Interface Settings
• Specifying interface parameter settings using the Installation menu on page 131 • Selecting which input telegrams to read on page 133 Opening the Installation menu Purpose This procedure explains how to open the menu on the SH90 Processor Unit. Installation Procedure Click the tab on the...
Page 134 Simrad SH90 Click any other settings if you wish to define the sensor's interface parameters. Observe that the parameter dialog appears at the bottom of the menu Sensor Config field. Make the appropriate settings for the chosen sensor. Click the...
Page 135 Interfacing peripheral equipment Selecting which input telegrams to read Purpose This procedure explains how to select input telegrams from the following external sensors: • Buoy • Position • Heading • Speed • Course For each sensor input, you can choose .
Page 136: Monitoring The Traffic On A Serial Or Ethernet Line
One is started from the sonar Object Inspector program, the other is started from the beamformer program that runs in the background on the SH90 Processor Unit. In this context the sonar program version is used. This version is generally referred to as “...
Page 137 Interfacing peripheral equipment Opening the Object Inspector [sonar program] utility Purpose This procedure explain how to open the sonar program's Object utility on the Inspector Processor Unit. This utility is elsewhere referred to as “Object Inspector [Sonar program]”. Procedure Click the Setup on the right hand side to open the...
Page 138 Inspector program]. Open by clicking the + Simrad SH90 →SensorIOControl →HWPortManager symbols. Observe the list of communication ports. Click the + sign in front of the serial or Ethernet (LAN) port you wish to monitor. Some interface ports are used by the sonar system. By default this is: •...
Page 139: Synchronisation With Other Acoustic Systems
Interfacing peripheral equipment Synchronisation with other acoustic systems The Simrad SH90 may be set up to be synchronized with other hydroacoustic instruments. This is necessary if you wish to prevent several hydroacoustic systems to transmit simultaneously. Individual transmission is often a necessity to prevent interference.
Page 140 Installation Selecting synchronisation mode Purpose This procedure explains how to set up the SH90 to operate as a slave or master device in a synchronised system. Prerequisites It is assumed that the required cabling has been made, that the connections have been tested for continuity, and that the applicable port has been chosen in the menu.
Page 141: About Synchronisation
Click to connect the SH90 as a slave to an external system. The external system will then instruct the SH90 when to transmit. • Master Click to allow the SH90 to be in control. The SH90 will then instruct the external system on when it can transmit. Click...
Page 142: Synchronisation Using A Serial Line
(flutter) over and below 0 Vdc to trigger the interface. SH90 set up as Slave When the SH90 is set up as a Slave, the sonar must receive a trigger signal from the synchronisation unit each time the sonar shall be permitted to transmit. This trigger...
Page 143: Synchronisation Sequences
Interfacing peripheral equipment • When in mode, the Master pings as fast as possible, raising its Free running signal at start of ping and lower it at end of ping. The Slave will be triggered by the raised signal as before. •...
Page 144: Synchronisation Of The Sonar Clock With An External Clock
Synchronisation of the sonar clock with an external clock The Simrad SH90 may be connected to an external clock. If required, the sonar's internal clock may then be synchronised and/or controlled by the external clock. In order to take advantage of an external clock, the time information must be provided an the ZDA telegram format, and the external device providing the telegrams must be connected as a GPS system.
Page 145: Opening The Installation Menu
Interfacing peripheral equipment Note This functionality is only provided if you use SH90 software version or later. 2.1.X Topics • Opening the Installation menu on page 143 • Changing the necessary parameter to allow for clock synchronization on page 143...
Page 146: Connecting The Speed Log
Pulse log (200 pulses/nautical mile) The SH90 does not provide an input for a pulse log. In order to connect a speed log with pulse log, you will need a converter to match the serial line input on the Processor Unit.
Page 147: Connecting The Course Gyro
Connecting the course gyro Purpose A course gyro must be connected to the SH90. The cable must be provided by the installation shipyard. The SH90 can read the course information from a serial line. If only a 3-phase synchro or stepper signal is available, an optional Gyro Interface Unit must be used for converting these signals to serial line format.
Page 148: Connecting An External Motion Reference Unit (Mru)
Connecting an external motion reference unit (MRU) By default, the SH90 uses a built-in motion reference detector mounted on the hull unit. For improved accuracy, and external motion reference unit (MRU) may be used. The motion reference interface functionality on the SH90 has been designed to match the MRUs manufactured by Kongsberg Seatex.
Page 149: Opening The Installation Menu
• The connection to the motion reference unit must be made according to the cabling information in the manufacturer’s manual. • The connection to the rear side of the SH90 Processor Unit is made according to drawing Generic RS-232 Serial line (Three wires) on page 282 or Generic RS-422 Serial line (Five wires) on page 285.
Page 150 Once you close the parameter dialog, the chosen communication port will “disappear”. If you later need to change communication parameters, you must first choose internal sensor (select ) in the menu, and then restart the SH90. Transceiver1 Click to exit the parameter dialog.
Page 151: Entering The Stabilisation Offset Angle Into The Sh90
Interfacing peripheral equipment Entering the stabilisation offset angle into the SH90 Purpose Once the offset angle has been measured, it must be entered into the SH90 setup parameters. Procedure Open the menu. Setup Click the button to open the menu.
Page 152: Connecting A Secondary Operating Panel
372980 This section describes how to install and connect the secondary Operating Panel to the SH90 system. Note This functionality is only provided if you use SH90 software version or later. 2.1.X Topics • Parts and tools required to install a secondary Operating Panel on page 150 •...
Page 153: Physical Installation Of The Operating Panel
[365914] Secondary Operating Panel, Installation manual Physical installation of the Operating Panel Purpose This procedure explains how to install the Operating Panel provided with the SH90 sonar. The Operating Panel is designed to be recessed in a panel. Procedure 372 mm ø7x4...
Page 154: Opening The Installation Menu
Processor Unit. Use the serial interface adapter provided for the plug. Connect all power supplies. Observe the dedicated procedure to set up the SH90 software. → Configuring and testing the interface to the secondary Operating Panel on page 152...
Page 155 Interfacing peripheral equipment Click I/O Setup→Control Panel Observe that the parameter dialog appears at the bottom Control Panel Configuration of the menu field. Change the settings in the parameter dialog to suit your Control Panel Configuration requirements for the interface. Specify how many Operating Panels you wish to use.
Page 156: Cable Plan For A Secondary Operating Panel
Simrad SH90 Cable plan for a secondary Operating Panel Slave Operating Panel (CD01551 1-002) +12 Vdc 230 Vac SIMRAD C1/C2* MAIN SYMBOL MODE GAIN RANGE CURSOR Mode POWER Gain Gain Range Select View Object Range Menu Mode RS-232 CAT5-E Mode...
Page 157: List Of Cables Required For The Secondary Operating Panel
List of cables required for the secondary Operating Panel SH90/C1 Operating Panel “Dual cable” to power supply and RS-232 extender This cable is provided with the SH90 Operating Panel. It is a special dual cable with one common 15-pin connector leading to two separate 9-pin connectors in the two other ends of the cable.
Page 158: C10 Sh90/C10 Operating Panel Usb Cable To Processor Unit
→ Operating Panel power supply on page 292 SH90/C10 Operating Panel USB cable to Processor Unit This cable is provided with the SH90 Operating Panel. It is a standard USB data cable with length 4,5 meters. → Connecting the USB cable from the Operating Panel to the Processor Unit on page 102 →...
Page 159: Establishing Emergency Hoist Functionality
The emergency hoist functionality is provided by the Hull Unit Control circuit board in the Motor Control Unit. Simrad does not offer any optional products or kits to put this functionality to use. Any applications that the end user wish to establish must be designed and manufactured based on the information provided in this section.
Page 160: Circuit Board Interface Description
Simrad SH90 Power down the SH90 system, and make sure that it can not be unintentionally restarted. Connect a cable to the plug. Drill a hole in the Motor Control Unit cabinet to pull the cable through. Important Make sure that the hole in the Motor Control Unit cabinet does not have any effect on its splash proof integrity.
Page 161: Testing The Interfaces To Peripheral Devices
• Configuring and testing the interface to a radio buoy system on page 164 • Configuring and testing the interface to a sea current meter on page 165 Opening the Installation menu Purpose This procedure explains how to open the menu on the SH90 Processor Unit. Installation Procedure Click the tab on the...
Page 162: Configuring And Testing The Interface To The Speed Log
Simrad SH90 Configuring and testing the interface to the speed log Observe the relevant test procedure for your speed data source. Topics • Speed log (serial line interface) on page 160 • (D)GPS speed data (serial line interface) on page 160...
Page 163: Configuring And Testing The Interface To The Course Gyro
Interfacing peripheral equipment Observe that the parameter dialog appears at the bottom of the menu Sensor Config field. Change the settings in the parameter dialog to suit your requirements Sensor Config for the serial line. Remember to set correct baud rate, and set to GP.
Page 164: Configuring And Testing The Interface To The Positioning System (Gps)
Simrad SH90 Check that the heading read-out in the parameter dialog corresponds to the Status GPS heading. If you need or wish to monitor the detailed data traffic on the communication line, observe the dedicated procedures in section Monitoring the traffic on a serial or Ethernet line on page 134.
Page 165: Configuring And Testing The Interface To A Trawl System
To check the interface to the Simrad ITI system, click I/O Setup→Sensors →Trawl system →ITI To check the interface to the Simrad FS20/25 and FS70 systems, click Setup→Sensors →Trawl system →FS3300 Observe that the parameter dialog appears at the bottom of the menu Sensor Config field.
Page 166: Configuring And Testing The Interface To A Catch Monitoring System
To check the interface to the Simrad ITI system, click I/O Setup→Sensors →Trawl system →ITI To check the interface to the Simrad FS20/25 and FS70 systems, click Setup→Sensors →Trawl system →FS3300 Observe that the parameter dialog appears at the bottom of the menu Sensor Config field.
Page 167: Configuring And Testing The Interface To A Sea Current Meter
Interfacing peripheral equipment Observe that the parameter dialog appears at the bottom of the menu Sensor Config field. Change the settings in the parameter dialog to suit your requirements Sensor Config for the communication line. Click to exit the parameter dialog. Close Sensor Config Open the...
Page 168: Setting To Work
Simrad SH90 Setting to work The procedures in this chapter explains how to set the SH90 to work for the first time. They shall be done once all the SH90 hardware units have been installed, and the cabling has been completed.
Page 169: Starting Up The Hull Unit
Setting to work Starting up the Hull Unit Observe the following procedures to start up the hull unit provided for the Simrad SH90. WARNING Before you start up the SH90 on a recently launched vessel, make sure that the depth under the keel is sufficient for the transducer to be lowered safely.
Page 170: Hull Unit Familiarization And Main Parts Identification
Simrad SH90 Hull unit familiarization and main parts identification Upper limit switch S304 Transducer cable Transducer shaft Lower limit switch S305 Grease nipple (Pressure release plug on rear side) Air bleeding plug Hoisting motor Motor Control Unit Hoisting unit Mounting flange...
Page 171: Motor Control Unit Familiarization And Main Parts Identification
Setting to work Motor Control Unit familiarization and main parts identification Internal 24 Vdc power supply Ethernet connector HOIST STOP REMOTE LOWER P302 S302 Hand crank S303 Mains filter Hull Unit Controller circuit K303 S301 board K302 Fuse for internal power F301 K301 supply...
Page 172: Apply 3-Phase Ac Power
Simrad SH90 Use a spanner to open the door on the Motor Control Unit which is mounted on the Hull Unit gantry. [_____] Ok Locate the motor protecting switch , and check that the operating handle is S301 pressed down to OFF position.
Page 173: Check The Hoisting Motor's 3-Phase Ac Connections
Setting to work Check the hoisting motor's 3–phase AC connections Purpose Mains connection to the hoisting motor In order to ensure that the hoisting 230 Vac 380/440 V ac motor operates properly, and to avoid serious damage to the motor, you must check that the motor connections are made in accordance with the supplied 3–phase voltage.
Page 174: Check 3-Phase Connection For Correct Rotation
Simrad SH90 Check 3–phase connection for correct rotation Purpose Location of S302, S301, E301, K303 and LED L1 in the Motor Control Unit The Motor Control Unit is equipped with a Phase Watch Relay ( ), which K303 prevents operation of the hoisting motor...
Page 175: Check The K301 Contactor Operation
Setting to work Check the K301 contactor operation Purpose Location of S301, S302, K301, K302 and LED L2 in the Motor Control Unit Observe this procedure to verify that the contactor in the Motor Control Unit K301 is operational. HOIST STOP REMOTE LOWER...
Page 176: Verify Correct Hoist And Lower Functionality
Simrad SH90 10 Remove the hand crank from its storage position. [_____] Ok 11 Check that the contactor is deactivated. [_____] Ok Important Do not place the hand crank back into its storage position. 12 Set the hoist/lower switch to the STOP position.
Page 177 Setting to work Set the hoist/lower switch to the STOP position. S302 [_____] Ok Put the hand crank back to its storage position in the Motor Control Unit. [_____] Ok Check if there is sufficient space under the keel to lower the transducer. [_____] Ok Make sure that the flexible transducer cable is in such a position that the transducer can be lowered without stretching or hard-bending the cable.
Page 178: Starting Up The Bridge Units
Observe these procedures that start the bridge units for the first time. Note In order to prevent inadvertent use of the SH90, the AC mains plug must be disconnected when the vessel is in dry dock. Operating the sonar with the transducer in air may cause serious damage to the system.
Page 179: Setting Up The Sonar To Retrieve Simulated Sonar Echoes
• Own course • Target type and number [_____] Ok Opening the Installation menu Purpose This procedure explains how to open the menu on the SH90 Processor Unit. Installation Procedure Click the tab on the Setup right hand side to open the menu.
Page 180: Checking The Operating Panel
Panel are organized in fields. Each field has a name that describes the main functions provided by its respective buttons. For more information about the Operating Panel, see the SH90 Reference manual. Topics • Operating Panel functional tests on page 178 •...
Page 181 Setting to work Press the button on the Operating Panel. Select Click the button on the menu. Delete All Objects Check that both the Target Marker and the Ship Marker disappear. [_____] Ok Check the Circle Marker. Press the button. Circle Marker Check if a circle appears centred around the cursor.
Page 182 Simrad SH90 Horizontal range Purpose Range Range Check the horizontal range read-out. Procedure Press the button to select mode 270°/Vertical. Mode 2 Press the buttons in the Range field on the Operator Panel Range H- Range H+ repeatedly. Check that the Range read-out in the...
Page 183 Setting to work Full screen Purpose Check the Full screen function. This function will remove the menu system from the sonar screen. Procedure Press the button in the Cursor field. Menu Check that the menu disappears for a full screen echo presentation. Press the button once again to recall the menu.
Page 184 Simrad SH90 Manual and automatic tilt Purpose The tilt can be adjusted both on the Operator Panel and in the menu system. You will now check the functionality and the read-out of the tilt. Procedure Open the menu. Horizontal Press...
Page 185: Checking The Operating Panel Backlight
Setting to work Training Purpose Observe this procedure to check the training function, as well as position and target track. Procedure Press the (arrow) buttons Train left Train right in the Train field repeatedly. Target Position Track Track Check that the white audio line on the screen trains correspondingly.
Page 186: Powering Off The Sonar
Simrad SH90 Powering off the sonar Purpose Observe the following procedure to switch off the sonar for the remaining tests. Procedure Click the tab to open the menu. Horizontal Horizontal Locate the button. TX Power Click the button to switch off transmit power.
Page 187: Starting Up The Transceiver Unit And The Power Supply Unit
Setting to work Starting up the Transceiver Unit and the Power Supply Unit Observe the location of the Figure 2 SH90 Power Supply Unit service switch on the top left corner of the Power Control Board. can be used to select modes Remote, Off or Service.
Page 188 Simrad SH90 Start the Power Supply Unit by placing service switch to position SERVICE. [_____] Ok Check that the fans in the Transceiver Unit start up. The output voltages (+5 Vdc, +12 Vdc and +72 Vdc) are now available on the terminal plug on the top of the front mounted circuit board.
Page 189: Checking The Hoist/Lower Functionality
Setting to work Checking the hoist/lower functionality The following set of procedures allows you to check that the transducer can be lowered and hoisted. The procedures require two persons: • One person must be stationed on the bridge to operate the sonar. •...
Page 190: Checking The Hoist/Lower Functionality From The Bridge
Simrad SH90 Checking the hoist/lower functionality from the bridge Note The instructions marked [ ] are done in the sonar room. Sonar room This procedure must be performed simultaneously with the next procedure; Checking the hoist/lower functionality from the sonar room on page 190.
Page 191 Setting to work When lower position has been reached, check that the LED next to the Down button illuminates continuously, that the audible signal stops, and that the upper button in the menu shows Transducer: DOWN. Status [_____] Ok Hoist the transducer back up to its middle position. Press the button on the Operating Panel to move the transducer to its Middle...
Page 192: Checking The Hoist/Lower Functionality From The Sonar Room
Simrad SH90 Check that the LED next to the button starts to flash, and that the audible signal indicates transducer movement. [_____] Ok When upper position has been reached, check that the LED next to the button illuminates continuously, that the audible signal stops, and that the upper button in the menu shows Transducer: UP.
Page 193: Measuring The Self-Noise
Setting to work ] Lower the transducer to its lower position. Bridge ] Hoist the transducer back up to its middle position. Bridge ] Hoist the transducer back up to its upper position. Bridge ] Lower the transducer to its lower position. Bridge 10 [ ] Hoist the transducer back up to its upper position.
Page 194 Simrad SH90 Reduce the from 50 to 0. Gain Then, adjust the gain up until the echo images on the sonar display are dynamic, and you can distinguish between the individual echoes. The gain setting does not affect the noise measurement.
Page 195: Starting Up The Sh90 System
• Preparations before the SH90 system is started on page 193 • Starting up the SH90 system, bridge actions on page 194 • Starting up the SH90 system, sonar room actions on page 195 Preparations before the SH90 system is started...
Page 196: Starting Up The Sh90 System, Bridge Actions
SH90 system, sonar room actions on page 195. The instructions marked [ ] are done in the sonar room. Sonar room Purpose This procedure explains the actions to be made on the bridge when the SH90 system is started. Procedure Start up the sonar. [_____] Ok Check that the depth is sufficient for lowering of the transducer.
Page 197: Starting Up The Sh90 System, Sonar Room Actions
] are performed on the bridge. Note that those Bridge procedures are more detailed that what is presented here. Purpose This procedure explains the actions to be made in the sonar room when the SH90 system is started. Procedure ] Start up the sonar.
Page 198: Alignment Of The Sonar Picture
Simrad SH90 Alignment of the sonar picture Purpose Figure 3 Hull unit alignment This procedure explains how to align the sonar presentation to the hull unit. Independent of the hull unit orientation, the alignment is always defined as: The angle measured...
Page 199: Defining Own Ship Parameters
Setting to work In order to verify the alignment, a particular target such as a buoy is required. When the alignment is correct, write down the angle here: Alignment correction (degrees): [_____] Ok Defining own ship parameters In order to achieve accurate readings from the sonar system, certain vessel parameters must be entered.
Page 200: Specifying Instrument Position Offsets
When a new display mode is selected, the instruments will change to the chosen positions. Opening the Installation menu Purpose This procedure explains how to open the menu on the SH90 Processor Unit. Installation Procedure Click the tab on the...
Page 201 Setting to work Observe that the menu appears at the top of the display. Installation 323776/D...
Page 202: Final Tests And Measurements
Simrad SH90 Final tests and measurements In order to verify that the SH90 works properly, a number of measurements, tests and backup operations must be done. Topics • Noise/speed curve measurements on page 201 • Processor Unit backup and restore on page 205...
Page 203: Noise/Speed Curve Measurements
Final tests and measurements Noise/speed curve measurements This section explains how to create a noise/speed curve for the sonar installation. Topics • Preparations on page 201 • Test procedure on page 201 • Problems with flow noise on page 202 •...
Page 204: Problems With Flow Noise
Simrad SH90 Problems with flow noise In case of very high ship noise levels, the RCG function will automatically regulate the receiver gain down. This lower gain will then cause a reduction in the receiving range. To find out if this high noise level is caused by flow noise from the vessel’s hull or by the engine/propeller, perform the following test.
Page 205 Final tests and measurements Noise verification results Table 3 Noise verification Bearing is 0° for all measurements Speed Stable speed Acceleration Retardation 0 knots 2 knots 4 knots 6 knots 8 knots 10 knots 12 knots 14 knots 16 knots 323776/D...
Page 206 Simrad SH90 Noise/Speed plot results Table 4 Noise/Speed plot +90 dB Noise/speed curve for 0° bearing and maximum gain Stable speed +86 dB Acceleration Retardation (CD015047E) +82 dB +78 dB +74 dB +70 dB +66 dB +62 dB +58 dB...
Page 207: Processor Unit Backup And Restore
Your backup will then include the operating system, the system software, as well as all the interface parameters that you have defined. A USB memory device is included with the SH90 system. This device is bootable, and it contains several folders with information.
Page 208: Creating A Backup Image Of All The Sonar Software
SH90. Procedure Boot the computer from the USB memory device. This procedure describes how to start up the SH90 computer from a bootable USB memory device. Connect a computer keyboard to one of the USB connectors on the computer.
Page 209: Restoring The Sonar Software From A Backup Image
If you restore your system from a generic image file, you must both change the Windows license, and activate it, before you can use the SH90. You must also reinstall the SH90 software. For this reason, it is important that you use the backup file that you made after the sonar installation was completed.
Page 210: Reactivating The Windows License
Simrad SH90 13 Click Next Note If the hard disk on the Processor Unit contains data, a confirmation dialog box appears to remind you that all data on the hard disk will be lost. 14 Click in the dialog box.
Page 211 Final tests and measurements Answer to reactivate Windows. If the system fails to ask, you can start the activation wizard by clicking in the bottom left corner, and choose from the menu. Activate Windows Observe the following dialog: Click Yes, I want to telephone a customer service representative... Click Next Observe the following dialog:...
Page 212 Simrad SH90 Observe the following dialog: 10 Enter the license code 11 Click Update 12 Click Back 13 Observe the following dialog: 14 If your computer is connected to the Internet. Note Do not leave the computer connected to the Internet for longer than absolutely required.
Page 213 Final tests and measurements Observe the following dialog: Click No, I don't want to register now... Click Next Observe the following dialog: 15 If your computer is not connected to the Internet. Click Yes, I want to telephone a customer service representative... Click Next 323776/D...
Page 214 Simrad SH90 Observe the following dialog: Select your location. Call the number provided. Provide the installation ID to the service desk. Type in the confirmation ID provided to you. Click Next Observe the following dialog: 16 When activation succeeds, click , and allow the computer to restart.
Page 215: Creating A Bootable Usb Memory Stick
Final tests and measurements Creating a bootable USB memory stick Purpose This procedure explains how to create a bootable USB memory device to use for backup purposes. The software used is . It is readily Acronis True Image installed on the Processor Unit. Procedure Insert the USB memory device you wish to format.
Page 216: Technical Specifications
This chapter provides the technical specifications and requirements related to the Simrad SH90. Note In Simrad, we are continuously working to improve the quality and performance of our products. Technical specifications may therefore be changed without prior notice. Topics • Performance specifications on page 215 •...
Page 217: Performance Specifications
Technical specifications Performance specifications This section provides the performance specifications for the Simrad SH90. Operational frequency • : 111.5 to 116.5 kHz in steps of 0.5 kHz Selectable Operational range • : 50 to 2000 meters Range steps Tilt and tip functionality •...
Page 218 Simrad SH90 Beams • : 360° Horizontal transmission • : 8° Horizontal reception • : 7,5° Vertical transmission • : 7,5° Vertical reception • (transmission + reception): 5,5° Vertical resolution Beam widths • : Narrow, Normal or Wide User selected Stabilisation •...
Page 219: Weights And Outline Dimensions
For more detailed information about the physical dimensions, see the Drawing file. Related topics • Drawing file on page 250 Colour display • The colour display is not a part of the Simrad SH90 scope of supply. Refer to the documentation provided by the manufacturer. Processor Unit •...
Page 220: Power Specifications
This section provides the technical specifications and requirements related to the AC and/or DC mains supply. Colour display • The colour display is not a part of the Simrad SH90 scope of supply. Refer to the documentation provided by the manufacturer. Processor Unit •...
Page 221: Environmental Specifications
To extend the lifetime of the equipment, it is strongly recommended to mount the units at dry and clean locations with sufficient ventilation. Observe the sonar room requirements. Colour display • The colour display is not a part of the Simrad SH90 scope of supply. Refer to the documentation provided by the manufacturer. Processor Unit •...
Page 222: Minimum Display Requirements
Minimum display requirements Unless specifically ordered from Simrad, the SH90 is not provided with a colour display. This item must be purchased locally. You can use one or two displays one your SH90 computer depending on personal and operational preferences.
Page 223: Telegram Formats
All NMEA, third party and proprietary telegrams available are not described here, only those used by the SH90. If the specifications here differ from the original specifications published by NMEA, the specifications issued by NMEA must be regarded as the correct version.
Page 224: Telegrams Received And Sent By The Sh90
• Target output telegrams on page 225 Course gyro telegrams Note In order to provide its full operational features, the Simrad SH90 must be provided with heading information. The Simrad SH90 software reads an external course gyro through a serial line using the NMEA 0183 standard for reception of heading information.
Page 225: Gps Telegrams
Telegram formats The Simrad SH90 software reads an external speed log through a serial line using the NMEA 0183 standard for reception of the vessel speed. The sonar accepts the following NMEA speed telegrams: → VBW Dual ground and water speed on page 233 →...
Page 226: Echo Sounder Telegrams
The GLL telegram may be received from integrated instruments using the “ii” talker identifier. The Simrad ITI system uses the same talker identifier “ii”, and this has caused some confusion for some of our users. In order to rectify this, the ITI GLL telegram has been inhibited.
Page 227: Wind Sensor Telegrams
Telegram formats Wind sensor telegrams The Simrad SH90 software reads wind data from an external wind sensor through a serial line using the NMEA 0183 standard for reception of wind direction and speed. The sonar accepts the following NMEA wind telegrams: →...
Page 228: About The Nmea Telegram Format
Setup →Trawl System →ITI About the NMEA telegram format The Simrad SH90 can send and receive information to and from several different peripherals. All transmissions take place as telegrams with data sentences. Each telegram has a defined format and length.
Page 229: Nmea Telegram Principles
Telegram formats The NMEA 0183 Interface Standard defines electrical signal requirements, data transmission protocol and time, and specific sentence formats for a 4800 baud serial data bus. Each bus may have only one talker but many listeners. — National Marine Electronics Association For more information about the National Marine Electronics Association and the NMEA 0183 standard, refer to the organization's web site at http://www.nmea.org.
Page 230: Specification Of Nmea Telegrams
@ character. The checksum field may then not be in use. Specification of NMEA telegrams All standard NMEA telegrams supported by the SH90 are specified here. The information is extracted from the original NMEA specifications. If additional details about the individual telegram formats are required, see the original source file.
Page 231: Dbs Depth Below Surface
Telegram formats DBS Depth below surface This telegram provides the current depth from the surface. The telegram is no longer recommended for use in new designs. It is often replaced by the telegram. Format $--DBS,x.x,f,y.y,M,z.z,F*hh<CR><LF> Format description = talker identifier –...
Page 232: Gga Global Positioning System Fix Data
Simrad SH90 = telegram identifier = water depth, in meters, relative to the transducer = offset, in meters, from the transducer = maximum range scale in use GGA Global positioning system fix data This telegram contains time, position and fix related data from a global positioning system (GPS).
Page 233: Hdg Heading, Deviation And Variation
The GLL telegram may be received from integrated instruments using the “ii” talker identifier. The Simrad ITI system uses the same talker identifier “ii”, and this has caused some confusion for some of our users. In order to rectify this, the ITI GLL telegram has been inhibited.
Page 234: Hdm Heading, Magnetic
Simrad SH90 HDM Heading, magnetic This telegram contains vessel heading in degrees magnetic. The telegram is no longer recommended for use in new designs. It is often replaced by the telegram. Format $--HDM,x.x,M*hh<CR><LF> Format description = talker identifier – –...
Page 235: Mwv Wind Speed And Angle
Telegram formats MWV Wind speed and angle This telegram provides the direction from which the wind blows relative to the moving vessel's centre line. For more information about this telegram format, refer to the NMEA standard. Format $--MWV,x.x,a,y.y,b*hh<CR><LF> Format description = talker identifier –...
Page 236: Vhw Water Speed And Heading
Simrad SH90 Format $--VBW,x.x,z.z,A,r.r,q.q,A,p.p,A, c.c,A*hh<CR><LF> Format description = talker identifier – – = telegram identifier = longitude water speed, knots = transverse water speed, knots = status, water speed, characters (data valid) or (data not valid) are used. = longitudinal ground speed, knots...
Page 237: Vtg Course Over Ground & Ground Speed
Telegram formats VTG Course over ground & ground speed This telegram contains the actual course and speed relative to the ground. Format $--VTG,x.x,T,y.y,M,z.z,N,g.g,K,a*hh<CR><LF> Format description = talker identifier – – = telegram identifier = course over ground, degrees true x.x,T = course over ground, degrees magnetic y.y,M = speed over ground, knots, resolution 0.1...
Page 238: Proprietary Telegrams And Formats
= local zone hours, 00 to ±13 = local zone minutes, 00 to ±59 Proprietary telegrams and formats These are the proprietary telegrams supported by the SH90. These telegram formats have all been defined by Simrad. The telegrams are listed in alphabetical order. Topics •...
Page 239: Dbs Depth Of Trawl Below Surface
= sign bit = is the 14 bit absolute depth value in units of 0.1525879 m. bbbbbb bbbbbbbb GLL Trawl position This proprietary Simrad telegram provides the geographical position of the trawl sensor. Format $IIGLLddmm.hh,N,dddmm.hh,W,hhmmss.ss,A<CR><LF> Format description = talker identifier (mandatory)
Page 240: Hfb Trawl Headrope To Footrope And Bottom
The GLL telegram may be received from integrated instruments using the “ii” talker identifier. The Simrad ITI system uses the same talker identifier “ii”, and this has caused some confusion for some of our users. In order to rectify this, the ITI GLL telegram has been inhibited.
Page 241: Mtw Water Temperature At The Trawl
= water temperature, degrees Celcius xx.x,C PSIMP-D PI Sensor data This proprietary Simrad telegram contains the type and configuration of PS and PI sensors used by the external PI catch monitoring system. Note This telegram format is no longer in use. It has been replaced by PSIMP-D1. The description is not complete.
Page 242 Simrad SH90 Format $PSIMP,D,tt,dd,M,U,S,C,V,Cr,Q,In,SL,NL,G, Cb,error*chksum<CR><LF> Format description = Talker identifier (mandatory) = Telegram identifier = Sentence specifier = Time of day = Current date = Measurement type: • D = Depth • T = Temperature • C = Catch • B = Bottom •...
Page 243: Psimp-F Pi Sensor Data
OR of all characters between, but not including, the "$" and "*" characters PSIMP-F PI Sensor data This proprietary Simrad telegram contains the type and configuration of PS and PI sensors used by the external PI catch monitoring system.
Page 244: Tfi Trawl Filling
= depth of the trawl below the water surface TPP Tracked target position or marker This proprietary Simrad telegram sends the horizontal range, bearing and depth of a tracked target to the ITI system. On the ITI system, this information is used to show the tracked target in the tactical mode.
Page 245: Tpt Trawl Position True Vessel
• Note that position telegrams for markers are not be transmitted to the ITI. TPT Trawl position true vessel This proprietary Simrad telegram contains the true bearing and water depth of the trawl sensor, as well as its distance from the vessel.
Page 246 Simrad SH90 Format description = talker identifier (mandatory) = telegram identifier = horizontal distance, in meters, from the trawl to the shoal in a direction normal to the vessel’s centre line = horizontal distance, in meters, from the trawl to the shoal the direction of the vessel’s centre line...
Page 247: Proprietary Third Party Telegrams And Formats
Proprietary third party telegrams and formats All third party telegram formats supported by the SH90 are specified here. These telegram formats are created by third party organizations, and they are supported by the SH90 to allow for interface to third party systems.
Page 248 Simrad SH90 Data sentences Table 6 Furuno CIF, Sentence no. 56: Speed and direction for current layer one Byte # ASCII Comment Data no.56 Current speed x 10 kn Current speed x 1 kn Current speed x 1 kn Current direction x 100 deg...
Page 249 Telegram formats Table 7 Furuno CIF, Sentence no. 66: Current Indicator - Derived ship speed & course (cont'd.) Byte # ASCII Comment Ship speed x 1 kn Ship speed x 0,1 kn True course x 100 deg True course x 10 deg True course x 1 deg True course x 0,1 deg Ship heading x 100 deg...
Page 250: Kaijo Vdvcd Vector Current Direction
Simrad SH90 Table 8 Furuno CIF, Sentence no. 76: Depth, speed and direction for each current layer (cont'd.) Byte # ASCII Comment End of sentence Kaijo VDVCD Vector current direction This telegram is provided by the Kaijo range of sea current sensors, and provides sea current and depth.
Page 251: Serpe Bsc Buoy Input
Telegram formats = hours, minutes and seconds hhmmss = latitude llll.ll = north/south = longitude yyyyy.yy = east/west = year, month, day yymmdd = water temperature from 0 to 35.5°C tt.t = echo sounder data a0b0c0d0e0f0g0h0i0 = battery voltage BB.B Serpe BSC Buoy input This telegram is provided by the buoys to provide the geographical location of...
Page 252: Drawing File
Simrad SH90 Drawing file This chapter contains relevant drawings related to the installation and maintenance of the Simrad SH90. Note These mechanical drawings are for information and guidance only. They are not in scale. All dimensions are in mm unless otherwise is noted. The original installation drawings are available on PDF and/or AutoCad's DWG format.
Page 253: Cabinet Outline Drawings
Drawing file Cabinet outline drawings Topics • Transceiver Unit dimensions on page 252 • Power Supply Unit dimensions on page 255 • Processor Unit dimensions on page 257 • Operating Panel dimensions on page 258 Related topics • Installing the Transceiver Unit on page 72 •...
Page 254: Transceiver Unit Dimensions
Simrad SH90 Transceiver Unit dimensions 323776/D...
Page 255 Drawing file 323776/D...
Page 256 Simrad SH90 323776/D...
Page 257: Power Supply Unit Dimensions
Drawing file Power Supply Unit dimensions 323776/D...
Page 258 Simrad SH90 323776/D...
Page 259: Processor Unit Dimensions
Drawing file Processor Unit dimensions 461.60 479.60 All measurements in mm. [385609] Rev .A The drawing is not in scale. CD0151 12-001 323776/D...
Page 260: Operating Panel Dimensions
Simrad SH90 Operating Panel dimensions 323776/D...
Page 261: Hull Unit Drawings
Drawing file Hull Unit drawings Topics • Hull unit dimensions drawing on page 260 • Sonar trunk dimensions drawing on page 261 • Sonar trunk production drawing on page 262 • Blind cover dimensions drawing on page 264 Related topics •...
Page 262: Hull Unit Dimensions Drawing
Simrad SH90 Hull unit dimensions drawing 323776/D...
Page 263: Sonar Trunk Dimensions Drawing
Drawing file Sonar trunk dimensions drawing 12.50 Material: ø18 Mild steel, St.42 or better 12 Holes, spacing 30 degrees 323776/D...
Page 264: Sonar Trunk Production Drawing
Simrad SH90 Sonar trunk production drawing 323776/D...
Page 265 Drawing file 323776/D...
Page 266: Blind Cover Dimensions Drawing
Simrad SH90 Blind cover dimensions drawing 323776/D...
Page 267: General Safety Rules
Appendix A General safety rules Appendix A General safety rules WARNING The Simrad SH90 operates on 230 Vac 50/60 Hz. This voltage is lethal! The following safety precautions must be followed at all times during installation and maintenance work • Always switch off all power before installation or maintenance.
Page 268: Equipment Handling
Simrad SH90 Appendix B Equipment handling This section provides the basic rules for transportation, storage and handling of units. In this context, a unit may be any large or small part of the system. It can be supplied as part of the initial delivery, or as a spare part.
Page 269: Transportation
Appendix B Equipment handling Transportation Unless otherwise stated in the accompanying documentation, electronic, electro-mechanical and mechanical units supplied by Kongsberg Maritime can be transported using all methods approved for delicate equipment; (by road, rail, air or sea). The units are to be transported in accordance with general or specific instructions for the appropriate unit(s), using pallets, transport cases, or carton boxes as appropriate.
Page 270: Storage Prior To Installation Or Use
Simrad SH90 Storage prior to installation or use When a system, a unit or a spare part has been delivered to the customer, it may be subject to long time storage prior to installation and use. During this storage period, certain specifications must be met.
Page 271: Inspection
Appendix B Equipment handling Inspection An inspection must be carried out immediately after the unit(s) have arrived at their destination. Check all wooden or cardboard boxes, plastic bags and pallets for physical damage. Look for signs of dropping, immersion in water or other mishandling. If damage is detected externally, you will have to open the packaging to check the contents.
Page 272: Unpacking Electronic And Electromechanical Units
Simrad SH90 Once the carton is open, carefully remove all loose packing and insulation material. Check for manuals and other documents that may have been added to the carton during packing, and put these to one side. Check also for special tools, door keys etc.
Page 273: Storage After Unpacking
Appendix B Equipment handling Storage after unpacking The unit must whenever possible be stored in its original transportation crate until ready for installation. The crate must not be used for any purpose for which it was not intended (eg. work platform etc.). Once unpacked, the equipment must be kept in a dry, non condensing atmosphere, free from corrosive agents and isolated from sources of vibration.
Page 274: Mechanical Units
Simrad SH90 Mechanical units If a mechanical unit may has been exposed to a salt atmosphere while it was in use, it must be thoroughly cleaned both internally and externally to prevent corrosion. If the construction materials and type of unit permits, wash the unit using a high-pressure hose and copious amounts of fresh water.
Page 275: Dehumidifier
Appendix B Equipment handling Dehumidifier Place a suitably sized bag of desiccant material (silica gel or similar) into the unit to keep the electronic components as dry as possible. Coatings Spray the unit externally with a corrosion inhibitor (e.g. a light oil) before packing. Re-packaging Whenever possible, the unit must be stored and transported in its original packing material and/or crate.
Page 276: Circuit Board Handling And Packaging
Simrad SH90 Circuit board handling and packaging Circuit boards are delicate items. They may work year after year in an advanced product, but then fail due to a small spark of static electricity. For this reason, it is very important that they are properly handled and protected during shipping.
Page 277: Electro-Static Discharge (Esd)
Appendix B Equipment handling DO NOT use standard plastic bags, such as commercial bubble wrap. Fill in all the necessary information on the applicable documentation and place it inside the bag. Seal the bag. Place the circuit board in a suitable carton, and secure it for shipping. Electro-Static Discharge (ESD) What is ESD? Electro-Static Discharge (ESD) is the transfer of an electrostatic charge between two...
Page 278 Simrad SH90 Kongsberg Maritime offers a product recycling service and we recommend that this is used. The service is described on http://www.km.kongsberg.com →Products →Services →Product recycling All electrical and electronic components must be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or local authorities.
Page 279: Sh90 Cable Details
Appendix C SH90 cable details Appendix C SH90 cable details This appendix provides detailed information related to the installation of system cables. Topics • Cabling principles on page 278 • Cables to peripheral devices on page 278 • Cable drawings on page 281 Related topics •...
Page 280: Cabling Principles
Kongsberg Maritime accepts no responsibility for damage to the system or reduced operational performance caused by improper wiring. Cables to peripheral devices This section explains how to connect the various peripheral interfaces to the Simrad SH90. Topics • Positioning system interface on page 279 •...
Page 281: Positioning System Interface
Trawl sonar interface The Simrad SH90 can read the trawl data from a Simrad FS20, FS25 or FS70 Trawl sonar or the Simrad ITI (Integrated Trawl Instrumentation) system. The communication is achieved using a serial line.
Page 282: Catch Monitoring System Interface
Kaijo “C82” unit. For additional information about the telegrams provided as well as necessary setup, refer to the relevant installation manual. Radio buoys connection interface The Simrad SH90 can read the data from one of the following GPS based radio buoy systems: • SERPE •...
Page 283: Cable Drawings
Appendix C SH90 cable details Cable drawings Topics • Generic RS-232 Serial line (Three wires) on page 282 • Generic RS-232 Serial line (Nine wires) on page 283 • RS-232 used as external trigger input or output on page 284 •...
Page 284: Generic Rs-232 Serial Line (Three Wires)
Simrad SH90 Generic RS-232 Serial line (Three wires) This cable holds a multi purpose serial line. It provides interface with any peripheral unit. One end of the cable connects to the local unit (DTE) with a 9-pin D-connector, while the other connects to the peripheral (DCE) as described in the peripheral unit’s documentation.
Page 285: Generic Rs-232 Serial Line (Nine Wires)
Appendix C SH90 cable details Generic RS-232 Serial line (Nine wires) This cable comprises a multi purpose serial line. It provides interface with any peripheral unit. One end of the cable connects to the local unit with a 9-pin D-connector,...
Page 286: Rs-232 Used As External Trigger Input Or Output
Simrad SH90 RS-232 used as external trigger input or output This cable comprises an RS-232 serial line applied as an external trigger. It provides interface with any peripheral unit that requires or controls transmit/receive synchronization. One end of the cable connects to the local unit with a 9-pin D-connector, while the other connects to the peripheral system as described in the peripheral unit documentation.
Page 287: Generic Rs-422 Serial Line (Five Wires)
Appendix C SH90 cable details Generic RS-422 Serial line (Five wires) This cable holds a multi purpose RS-422 balanced serial line. It provides interface with any peripheral unit. One end of the cable connects to the local unit (DTE) with a 9-pin D-connector, while the other connects to the peripheral (DCE) as described in the peripheral unit’s documentation.
Page 288: Moxa Cp114El-I Serial Line Adapter
Simrad SH90 Moxa CP114EL-I Serial line adapter The Processor Unit is equipped with a serial adapter board. Each Moxa CP114EL–I board provides four serial lines. The connections to the board are made using four 9–pin D-connectors, and short converter cables are provided with the board.
Page 289: Moxa Cp114El-I Serial Adapter Setup
Appendix C SH90 cable details Pin assignments This board supports RS-232, RS-422 and RS-485 (both 2 and 4-wire). The board is provided with a four way connector cable to offer four 9–pin male D-connectors. Moxa CP114EL-I 9–pin D-connector converter RS-232 RS-422 RS485 (4–wire)
Page 290: Vessel Ground
Simrad SH90 Vessel ground This cable is used to connect a system unit to the ship's ground. Note that this cable must be as short as possible. To vessel ground UNIT'S GROUND TAG (CDC 31 1) Cable specifications • : 1 x 6 mm²...
Page 291: Ac Mains With Iec 60320 Socket And Inline Plug
Appendix C SH90 cable details AC mains with IEC 60320 socket and inline plug This is a commercial 230 Vac power cable for mains power. One end is fitted with an IEC plug, the other with a standard European mains plug. This is a standard cable type supplied in different lengths.
Page 292: 3-Phase Ac Mains To Motor Control Unit
Simrad SH90 3–phase AC mains to Motor Control Unit This cable is used to connect 3-phase mains supply and ship’s ground to the hoisting motor on the hull unit. The connections are made to the Motor Control Unit. Caution Observe the difference between 230 Vac and 380/440 Vac wiring on the...
Page 293: Ac Mains With Iec 320/C7 Inline Plug
Appendix C SH90 cable details AC mains with IEC 320/C7 inline plug This is a commercial 230 Vac power cable for 2-phase mains power. One end is fitted with an IEC320/C7 plug, the other with a standard European mains plug. This is a standard cable type supplied in different lengths.
Page 294: Operating Panel Power Supply
Simrad SH90 Operating Panel power supply This is a commercial low voltage DC power supply. The input is a standard IEC 320/C8 connector. The output cable is fastened to the power supply, and holds a standard circular plug. The polarity is printed on the supply.
Page 295: Dc Power From Power Supply Unit To Transceiver Unit
Appendix C SH90 cable details DC power from Power Supply Unit to Transceiver Unit This cable is used to connect the DC power supply from the Power Supply Unit to the Transceiver Unit. The cable is provided fixed to the Power Supply Unit, and it connects to a socket underneath the Transceiver Unit.
Page 296: Rj45 Ethernet, Straight
Simrad SH90 RJ45 Ethernet, straight This cable is used to provide standard Ethernet connections. Note that various categories exists. Normally, CAT-5E and CAT-6 cables are used in local area networks with bandwidth exceeding 100 Mbit. Ethernet cables are available commercially in different lengths, colours and categories.
Page 297: Connecting The Processor Unit To The Transceiver Unit
Appendix C SH90 cable details 1000Base-T High-speed Ethernet connections (CAT5E and faster) Cable specifications • Not applicable. This is a commercial cable. Related topics • http://en.wikipedia.org/wiki/TIA/EIA-568-B • http://en.wikipedia.org/wiki/Category_5_cable • List of cables on page 93 • Connecting the Processor Unit to the Transceiver Unit on page 108 •...
Page 298: Rj45 Ethernet With Noise Suppressor
Motor Control Unit and the Power Supply Unit. Plug (C) must always be connected to the Transceiver Unit. Cable specifications • Not applicable. This cable is provided by Simrad as a part of the system delivery. Related topics • List of cables on page 93 •...
Page 299: Universal Serial Bus (Usb)
Appendix C SH90 cable details Universal Serial Bus (USB) Just about any computer that you buy today comes with one or more Universal Serial Bus (USB) connectors on the back. These connectors let you attach everything from mouse to printers to your computer quickly and easily. Since the operating system supports USB, installation of device drivers is also easy.
Page 300: Dvi-I Display Cable
Simrad SH90 DVI–I Display cable This cable is a standard DVI-I cable. It is normally provided with the colour display. Pin-out viewed from the socket (CDC 508) Signal Signal TMDS Data 2- (Digital red - (Link 1)) Ground (Return for pin 14 and analog sync)
Page 301: Operating Panel "Dual" Cable
Appendix C SH90 cable details Operating Panel “Dual” cable This cable is used to connect the Operating Panel to the Processor Unit. • The 15–pin plug connects to the Operating Panel. • The 9–pin female plug connects to the Processor Unit.
Page 302: Basic Cable Requirements
Simrad SH90 Appendix D Basic cable requirements This chapter provides general information related to the installation of system cables. Topics • Cable trays on page 301 • Radio Frequency interference on page 301 • Physical protection on page 302 • Grounding on page 302 •...
Page 303: Cable Trays
Appendix D Basic cable requirements Cable trays All permanently installed cables associated with the system must be supported and protected along their entire lengths using conduits and/or cable trays. The only exception to this rule is over the final short distance (maximum. 0,5 meters) as the cables run into the cabinets/units to which they are connected.
Page 304: Physical Protection
Simrad SH90 It is important that cables, other than those supplying services to the equipment installed in a radio room, are not installed through a radio room, high power switch gear or other potential sources of interference. Cables which must pass through a radio room must be screened by a continuous metal conduit or trunking which must be bonded to the screening of the radio room at its points of entry and exit.
Page 305: Cable Connections
Appendix D Basic cable requirements Cable connections All cable connections are shown on the applicable cable plan and interconnection diagrams. Where the cable plan shows cable connections outside an equipment box outline, the connections are to be made to a plug or socket which matches the plug or socket on that particular item of equipment.
Page 306: Installation Remarks
Simrad SH90 Appendix E Installation remarks Use this space to document comments and remarks related to the installation. When the installation has been fully completed, and all functional tests have been performed to full satisfaction, representatives from all parties concerned must sign.
Page 307 Bootable Transceiver Unit, 111 NMEA telegram USB flash drive, 213 Power Supply Unit to formats, 226 Simrad SH90, 17 Bridge units the Transceiver Unit, 113 distances, 82 Processor Unit to the synchronisation, 139 AC mains cable...
Page 308 Simrad SH90 Operating Panel power hoist/lower functionality current meter, 280 supply to the Processor (bridge), 188 (D)GPS positioning, 279 Unit, 104 hoist/lower functionality echo sounder, 279 Power Supply Unit (sonar room), 190 EK60, 279 Ethernet cable to the Check hoist/lower system,...
Page 309 Index video cable from the telegram, 229 mounting trunk outline Processor Unit to the Depth below transducer dimensions, 261 colour display, 101 telegram, 229 Mounting trunk Connections Depth range production, 262 requirements, 303 transducer, 21 Operating Panel outline Corrosion protection, 57 Depth telegram dimensions, 258 Course data, ground...
Page 310 Simrad SH90 straight cable, 294 telegram, 230, 237 align the sonar picture, 196 Ethernet cable, 108 Global positioning apply emergency hoist, 157 Example telegram, 230 backup software, 206 sonar room arrangement, 44 Global Positioning System boot from USB, 206–207 External motion reference...
Page 311 17 Insulation system interface, 164 when docking, 16 sonar room, 42 test course gyro when the SH90 is not Interconnection cables, 88 interface, 161 used, 16 Interface test D)GPS speed data Information catch monitoring system...
Page 312 Simrad SH90 display, 220 VHW, 234 Motion reference unit VTG, 235 LBP (Length Between cable procedure, 146 VWR, 235 Perpendiculars), 39 external, 29, 146 NMEA Telegram Length Between interface test, 147 formats, 221 Perpendiculars (LBP), Motion reference unit NMEA telegrams...
Page 313 Index drawings, 250 Positioning system (GPS) installation of display hull unit, 260 interface test, 162 unit, 83 mounting trunk, 261 Power on installation of Processor Operating Panel, 258 bridge actions, 194 Unit, 83 Power Supply Unit, 255 sonar room actions, 195 Manual lowering and Processor Unit, 257 Power supply...
Page 314 Simrad SH90 start hull unit, 167 Mounting trunk, 262 cable specifications start the sonar system, 193 Proprietary telegrams (three wires), 282 start wheelhouse units, 176 specifications, 236 RS-422 synchronisation cable, 137 Protection cable specifications, 285 synchronization port, 138 against ESD, 275...
Page 315 Skills, workers interface parameters, 131 introduction, 15 required for installation, 38 Speed main units, 20 Slave mode maximum, 21 SH90 Processor Unit synchronization, 140 Speed data location, 81 Slave Operating Panel interface test, 160 Ship parameters cable procedure, 151 Speed data, ground...
Page 316 Simrad SH90 about, 139 Recommended Telegrams modes, 139 minimum specific about, 227 setup, 138 GNSS data, 233 select and specify input slave mode, 140 Relative (apparent) wind telegrams, 133 Synchronization speed and angle, 235 synchronize sonar clock master mode, 140...
Page 317 Index true bearing, 238 Trawl, headrope Vessel speed Trademarks, 14 telegram, 238 maximum, 21 Transceiver Unit Trunk Vessel's dimensions description, 21 about, 55 enter values, 197 installation procedure, 73 installation, 25–26, 54 Vessel's length outline dimensions installation principles, 57 enter value, 197 drawing, 252 mounting, 56 Vessel's width...

Simrad SH90 Installation Manual

Table of Contents

Table of Contents

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Simrad SH90

Summary of Contents for Simrad SH90
