Target Track - Simrad SH90 - REFERENCE MANUAL REV A Reference Manual

Simrad SH90
164
• : Click to record the sonar echoes once every fifth
Each 5th s
second in a series of separate images.
• : Click to record the sonar echoes once every tenth
Each 10th s
second in a series of separate images.
• : Click to record the sonar echoes once every half
Each 30th s
minute in a series of separate images.
• : Click to record the sonar echoes once every
Each 60th s
minute in a series of separate images.
• : Click to close the parameter dialog.
Close
• : Click to access the on-line help.
Help
Related topics
• Setup menu on page 98
• Store/Recall menu on page 103
• Store on page 162
• Recall on page 153
• Recall Mode on page 153

Target Track

Dialog description
The parameter dialog opens when you click the
Target Track
button in the
Target Track
The menu is in turn activated by pressing the
GeoView
button on the Operating Panel (or the middle mouse button) in
any horizontal view, and then selecting
pop-up menu.
Target track lines show the movement history of targets as a line
after the respective symbols. They are shown as straight line
segments drawn between each position fix, with optional minute
markers to be added for each minute along the line. You can
switch the track line(s) off, or enable them for the priority target
only (P), or for all targets.
menu.
GeoView
View menu
View
in the
View
323775/A
