7 Click the necessary characters on the on-line keyboard to
build a new file name.
8 Click the button in the parameter dialogue when you
Close
have completed the new file name.
Figure 18 On-screen keyboard
You are also permitted to change the file name on images in the
field. However, if you wish to transfer the chosen
Temporary files
image to the
Permanent files
the new file name is changed by the transfer process.

How to print sonar images

Click the tab to open the menu.
1
Setup
2 Click the
Store/Recall
3 Observe the list of images in the
4 Click one of the images to select it.
Click the button below the files to print the selected
5
Print
image.
The image will be sent to the default printer connected to the
Processor Unit. You are not allowed to control the output size
and format.

How to burn sonar images on a CD

The SH90 Processor Unit is provided with a CD player capable
of burning blank CDs. Observe the following procedure to burn
selected sonar images on a blank CD. Do not attempt this while
the sonar is in use searching for fish!
Note
This procedure assumes that you have basic knowledge of file
management in Windows.
To access the operating system functions, you can click any
button. When the help window opens, you can also access the
with the
Taskbar Start
Insert a blank recordable CD in the Processor Unit.
1
field afterwards, you will find that
button to open the
Store/Recall
button.
menu.
Store/Recall
menu.
Help
