Gear dialog options
• : Click to select small, medium or large purse.
Purse
• : Click to select small, medium or large bottom
Bottom Trawl
trawl.
• : Click to select small, medium or large pelagic
Pelagic Trawl
trawl.
• : Click to open a dedicated parameter dialog to edit the
Edit
parameters of the chosen gear.
• : Click to close the parameter dialog.
Close
• : Click to access the on-line help.
Help
Related topics
• Setup menu on page 98
• Edit Gear (Purse) on page 132
• Edit Gear (Trawl) on page 133

Heading

Dialog description
The parameter dialog opens when you click the
Heading
(Heading) button in the
of the menus.
The read-out of the current heading is a repetition of the
connected course gyro input. This parameter dialog allows you
to set a manual heading input if the signals from the external
heading sensors are missing.
Note
This heading read-out must not be used for navigation.
parameter dialog at the bottom
Status
Hdg
