How To Copy Sonar Images To A Usb Memory Stick - Simrad SH90 - REFERENCE MANUAL REV A Reference Manual

323775/A
2 Observe that the operating system's auto-start function
opens a dialogue requesting guidance.
3 Select
Open writable CD folder using Windows Explorer
click .
OK
Observe that a
4
Windows Explorer
5 By means of normal Windows functions, navigate to the
folder d:/winson/screendumps.
Double-click to open sub-folder Permanent or Temporary.
6
7 Click to select the images you wish to burn on the CD, and
copy them to the CD's
Click
8
Write these files to CD
window, and wait until the process has finished.
9 Remove the CD, and close the
How to copy sonar images to a USB
memory stick
The SH90 Processor Unit is provided with several USB interface
ports. These are located on the rear side of the cabinet, and on
some models below the CD player under the front cover. Observe
the following procedure to copy selected sonar images over to
a USB memory stick. Do not attempt this while the sonar is in
use searching for fish!
Note
This procedure assumes that you have basic knowledge of file
management in Windows.
Insert a USB memory stick into the Processor Unit.
1
2 Observe that the operating system's auto-start function
opens a dialogue requesting guidance.
Select
3
Open Windows Explorer
4 Observe that a
Windows Explorer
5 By means of normal Windows functions, navigate to the
folder d:/winson/screendumps.
6 Double-click to open sub-folder Permanent or Temporary.
7 Click to select the images you wish to copy to the USB
memory stick, and copy them to the USB's
window.
Explorer
8 Remove the USB memory stick, and close the
window.
Explorer
To access the operating system functions, you can click any
button. When the help window opens, you can also access the
with the
Taskbar Start
Operational procedures
window opens.
Windows Explorer
in the
Windows Explorer
Windows Explorer
, and click
window opens.
button.
, and
window.
window.
.
OK
Windows
Windows
Help
53
