Fish Alarm - Simrad SH90 - REFERENCE MANUAL REV A Reference Manual

323775/A
External Synchronisation dialog options
• : Click to select one of the three synchronization
Sync mode
modes below.
• Mode : Click to disconnect the SH90 from the
None
synchronisation system. The sonar will then operate
completely on its own.
• Mode : Click to connect the SH90 as a slave to an
Slave
external system. The external system will then instruct the
sonar when to transmit.
• Mode : Click to allow the SH90 to be in control. The
Master
sonar will then instruct the external system on when it can
transmit.
• : Click to select the delay between the SH90
Delay
transmission and the transmission of the external system,
or vice versa. A dedicated dialog is provided to make the
selection.
• : Click to close the parameter dialog.
Close
• : Click to access the on-line help.
Help
Related topics
• Setup menu on page 98

Fish Alarm

Dialog description
The parameter dialog opens when you click the
Fish Alarm
button on the
Alarm Setup
This is an on/off switch used to activate or deactivate the fish
alarm function. You can define an alarm area with inner and outer
range radius and a chosen width, and select an alarm threshold.
When fish is detected within the area, the alarm will be initiated.
To mute the alarm, press the
menu.
button on the Operating Panel.
Mute
Parameters
Fish
135
