These majority of the menu options on the basic
menu provide the same functions as their respective buttons on
the Operating Panel:
• : This option provide the same function as the
Target Track
button on the Operating Panel. See 'Train' field
Target Track
on page 87.
• : This option provide the same function as the
Position Track
button on the Operating Panel. See 'Train'
Position Track
field on page 87
• : This option provides the same function as the
Set Marker
button on the Operating Panel. See 'Symbol' field on page 82.
•
New Own Ship Marker
function as the button on the Operating Panel. See 'Symbol'
field on page 82.
• : This option provides the same function as the
Circle Marker
button on the Operating Panel. See 'Symbol' field on page 82.
• : When this function is selected, a straight line is
New Ruler
drawn from the current cursor position (where the
pop-up menu was selected) to another selected position. The
ruler will display range and bearing between the two points.
To remove the ruler, click on it with the right mouse button,
and select
Remove Ruler
(► Ruler on page 154)
• : This option provides the same function as the
Gear Symbol
button on the Operating Panel. See 'Symbol' field on page 82.
Target parameters
When you open the
positioned over a defined object (marker) on the display, it will
display additional parameters.
• : This option opens a parameter dialog with
Inspect [object]
detailed information about the current target. See Inspect
Object on page 139.
• : When this function is selected, the object
Delete [object]
will be removed. This is the same function as provided by
the menu.
Objects
•
Make [object] Priority Target
give priority to an "old" target tracking symbol, which locks
the audio channel on the target.
: This option provides the same
from the
Object
pop-up menu with the cursor
Object
: This function can be used to
Menu descriptions
pop-up
Object
Object
pop-up menu.
