North up

76
When North up mode is selected, true north is always up on the
screen. The vessel symbol is stationary with the bow pointing in
the vessel's course direction. The movement of the echoes across
the screen are controlled by a combination of the vessel's course
and speed and the target's own movements.
Figure 27 'North up' display mode
323775/A
