Simrad SH90
160
Speed dialog options
• + (plus): Click to increase the manual speed.
• – (minus): Click to decrease the manual speed.
• : Click to allow manual speed entry.
Manual
• : Click to allow automatic reception of speed data from a
Auto
relevant external sensor.
• : Click to close the parameter dialog.
Close
• : Click to access the on-line help.
Help
Related topics
• Status on page 161

Stabilizer

Dialog description
The button is located in the
Stabilizer
When the stabilizer is active, the transducer beam will be
stabilized electronically for roll and pitch. The beam direction
will change continuously according to the vessel's movements,
and thus be compensated whenever the vessel is out of trim. The
beam angle will always be maintained as if referred to a "flat"
water surface. When the stabilizer is used, this will also allow
you to use the PP Filter in rough seas. This filter will give a
cleaner and more stable echo presentation.
menu.
Setup
