Simrad SH90 - REFERENCE MANUAL REV A Reference Manual page 88

Simrad SH90
86
Menu
The button is used for selection between Menu and Full
Menu
Screen presentations. When the main menu is displayed, the echo
presentation will be reduced correspondingly. In Full Screen
presentation, the full dimension of the screen is used for the echo
presentation. When the full screen echo presentation is displayed,
the cursor may be used to activate the menu field by moving it to
the left or right extremes of the screen. If you move the cursor
outside the menu field it will hide the menu.
Select
The button is used to execute a selection. This corresponds
Select
to the left button on a standard computer mouse.
View
The button activates the
View
display window. This button corresponds to the middle button
on a standard computer mouse.
Object
The button activates the
Object
selected display window. This button corresponds to the right
button on a standard computer mouse.
Trackball
The trackball controls the cursor, and allows you to move the
cursor on the sonar display. The cursor changes appearance in
relation to its location on the screen.
• An Orange cursor in the echo field.
• An Arrow in the menu field.
• A Negative or Positive sign at each end of the menu buttons.
The negative or positive sign indicates the direction in which
the corresponding parameter values will be changed when
the button is pressed.
Select
• A Menu symbol in the centre of the button.
When this symbol is shown, the relevant parameter dialog is
opened when you press the
pop-up menu for the selected
View
pop-up menu for the
Object
button.
Select
323775/A
