5. Additional Features
This chapter describes connectors, LEDs, switches and additional items located on the module and not necessarily included in the PICMG standard spec-
ification. The locations of these items are as below:
5.1. Module Feature Locations
Page 58
BIOS
Boot
Select
Figure 3 – Module feature locations (top side)
Copyright © 2022 ADLINK Technology, Inc.
Status
BIOS Default
LEDs
Reset Button
Fan
12V
PICMG COM.0 R3.0
