6.15 Parallel Port

CN5: DB25

6.16 Storage: SATA, PATA, FDD, CF

CN9/11/12/17:
Express-BASE User's Manual
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
SATA
1 7
Signal Pin Signal
STROBE# 14 AUTOFD#
DATA0 15 ERROR#
DATA1 16 INIT#
DATA2 17 SELIN#
DATA3 18 GND
DATA4 19 GND
DATA5 20 GND
DATA6 21 GND
DATA7 22 GND
ACK# 23 GND
BUSY 24 GND
PAPER EMPTY 25 GND
SEL 26 N/C
Pin Signal Pin
1 GND 2
3 Tx- 4
5 Rx- 6
7 GND
Signal
Tx+
GND
Rx+
Page 27
