1. General Description

The D2 Turbo is designed to open and close domestic sliding gates weighing up to 250kg.
The gearbox, moulded from a high-tech engineering polymer not only looks good, but is
corrosion-free and guarantees that even if you live on the coast, your D2 Turbo will just keep
on going. A robust steel pinion ensures that your D2 Turbo can easily be retrofitted on sites
with existing steel rack and will deliver years of reliable service.
The D2 Turbo Low-Voltage is a cost-effective domestic sliding gate motor for gates weighing
up to 250kg. Its logic controller and onboard charger require only a low-voltage AC or DC input,
which means there is no need for costly high-voltage cable runs or expensive isolators.
The integral 12V 5Ah battery (charged by an internal charger) comes with full battery backup
and advanced lightning protection so you can always get in – even when the power is out.
For increased power capacity you can install a larger, 7Ah battery (your D2 Turbo was designed
to cater for this), or you can even use a solar panel to power it (See the section on Solar Panels,
for more details about solar charging).
Advanced features of the D2 Turbo logic controller:
The D2 Turbo has various useful features and functions, all easily-accessible from a user-friendly
dial-based setup system:
• Opening and closing safety beam inputs with beam circuit functional test
• High-security cleared-beam Autoclose in conjunction with safety beams (PIRAC)
• Multiple Modes of Operation: Standard Mode, Open only Mode (multi-user),
Reversing Mode, and two Pre-flashing Modes
• Automatic closing with adjustable time delay, and pushbutton override
• Remote gate-status indicator (gate position, power failure, low battery,
multiple collision detection and Pillar Light status indication)
• Pedestrian Opening
• Holiday Lockout
3
• Courtesy/Pillar-Light timer (fixed duration), with pre-delays and two Pre-flashing Modes
• Selectable gate speed modes - Low Speed/High Speed (High Speed is the default)
• Positive Close Mode (e.g. ensure activation of electric fence contact switch)
• Onboard multichannel code-hopping receiver with the ability to learn transmitter buttons
to specific functions (e.g. Gate trigger, Pedestrian Opening, Holiday Lockout)
1. Infrared Safety Beams or equivalent detection device must be fitted
2. Remote LED must be fitted
3. Onboard receiver must be used or external access control device such as a keypad or keyswitch that must be fitted
4. Pillar Lights/Pre-flash warning light must be fitted
www.CentSys.com
(with adjustable Autoclose time)
