7.5. Starting and running forces
Test the starting force of the gate as per Figure 6. Use a pull scale to determine the
maximum amount of pull force required to get the gate moving
Determine the running force of the gate by continuing to pull on the scale with just
sufficient force to keep it running and read off the maximum value in kgf shown on the
scale
Where possible determine the gate mass
The warranty will be void if the pull force and/or gate mass exceed the operator
specification as below:
• Starting force - 18kgf
• Running (rated) force - 9kgf
• Maximum gate mass - 250kgf
Pull scale
FIGURE 6. STARTING AND RUNNING FORCES
