Adding code-hopping
remote controls
To add a code-hopping remote
control to the onboard receiver
and assign a button to any specific
function as described above, please
follow the steps below:
Step 1: Rotate the Function Dial to
the REMOTES position (B).
Step 2: Rotate the Setting Dial to
the desired selection along the 'B'
row of options.
You can choose from the following settings:
• Tx TRG to assign a remote control button to be learned into the system and
trigger the gate to fully open
• Tx PED to assign a remote control button to be learned into the system and
partially open the gate for a pedestrian
• Tx LCK to assign a remote control button to be learned into the system and
activate Holiday Lockout Mode
Step 3: Press the pushbutton to
select the setting chosen from above
– the Status LED will change from
red to green to confirm the setting.
page 70
FIGURE 99
FIGURE 100
