Using a pair of long-nosed pliers,
bend the ends of the anchor
brackets at a 90° angle.
Fit the mounting bolts to the
foundation plate and secure in place
with nuts and washer.
Long-nosed
pliers
Anchor
brackets
M10
washer
M10 gearbox
mounting bolts
page 26
FIGURE 14
FIGURE 15
M10 nut
FIGURE 16
