12. Commissioning the System

Introduction
The D2 Turbo and D2 Turbo Low-Voltage sliding gate operators' advanced functions are
controlled by intelligent microcontroller-based electronic controllers. These systems'
features and functions are enabled and disabled using the two user-friendly setting dials,
with the top dial used for selecting the desired function, and the bottom dial used for
selecting the specific setting to be enabled or disabled.
Setting up the gate
Limits
Ensure that the gate is in the fully
closed position and the motor drive
is engaged.
Rotate the Function Dial to the
LIMITS position along the 'A' row of
options.
Rotate the Setting Dial to the SETUP
position along the 'A' row of options.
Press the pushbutton to select this
feature.
www.CentSys.com page 53
Close
the gate
FIGURE 71
FIGURE 72
FIGURE 73
