FAST TRACK Mechanical Setup
These abbreviated instructions are for the experienced installer who needs a checklist
to get a standard installation up and running in the minimum of time.
Detailed installation features and functions are referred to later in this manual.
STEP
Gather Required Tools and Equipment
1
STEP
Heed Necessary Site Considerations
2
STEP
Cabling requirements
3
STEP
Lubrication
4
STEP
Operator installation
5
STEP
Foundation plate installation
6
STEP
Cabling and Wiring
7
STEP
Mount Gearbox
8
STEP
Mount the Rack
9
www.CentSys.com
page 5
page 16
page 17
page 21
page 22
page 23
page 25
page 31
page 31
page 34
