1. General Description

The V400/V500, available in two models with actuation strokes of 400mm and 500mm,
respectively, has been designed to automate a wide variety of swing gates, from single light-
domestic gates to heavy industrial double swing gates.
The fail-safe and fully-redundant Position and Collision Detection System has been designed
and tested to set the standard in safety of operation and to provide an unparalleled level of
reliability and durability in operation.
The gate Travel Limits are managed by a sealed double-redundant opto-electronic system
that has been designed not only to ensure ultra-reliable operation, but also to ensure precise
position and trajectory control. This enables very accurate and reliable collision detection to
ensure safe operation even under trying conditions.
This guide covers the mechanical installation of your new swing gate operator.
The V400/V500 can be installed on both inward- and outward
opening swing gates. Please see the relevant sections for each type of
installation, paying attention to any site preparation that needs to be
made before the operators are installed.
