17. Troubleshooting

Problem
Gate does not move
Gate moves a short
distance, and then
stops
Gate starts closing,
then stops and
re-opens
Gate overrides
its limits
www.CentSys.com
• Fuse is blown – Check 30A ATO fuse, and replace if
necessary
• LCK (Holiday lockout) input activated. Green LCK light
should be ON
• IRBC/IRBO (IR beams) inputs activated
• Latching input on TRG. (TRG light must be off for gate to
operate
• IRBC - gate will not close once open; IRBO - gate will not
open once closed
• Green IRBC/IRBO lights should be ON -
• Check the battery condition with Procedure A: Low battery
voltage condition, later in this section
• Procedure B: False collision detection, later in this section
• If the problem persists, the main controller might be faulty
• If Status light flashes four times, then the operator is in
Multiple Collision Mode. If required, check with
• Check the battery condition with Procedure A: Low battery
voltage condition, especially if the Status Light flashes
three times
• Check for false collisions with Procedure B: False Collision
Detection, later in this section
• Intermittent IRBC/IRBO signals. Check that the voltage
applied to the beams is appropriate
• False trigger. Intermittent short due to possible moisture
on the TRG input. Monitor TRG LED
• If the problem is still not solved, the main controller might
be faulty
• Check collision sensitivity and other causes with Procedure
B: False Collision Detection
• Besides a faulty controller, which will be considered last,
the only factor that could cause this symptom is a missing
origin or faulty DOSS module
• However, initially before the gate overrides its limits, if the
origin is not detected, the controller will automatically start
beeping when the gate is running, but it will allow normal
operation.
page 89
Possible faults
