VVX Color Expansion Module Hardware Feature Descriptions
Reference
Number Feature
1 Line Key
2 LED Indicators
3 Page Keys
4 Base Stand
5 LED Page
Indicators
6 Color Display

Connect VVX Expansion Modules

VVX Expansion Modules are powered and signaled by VVX phones and require minimal setup. After you
connect an expansion module to a VVX phone, the module is automatically configured to work with the
phone.
For more information on setting up VVX Expansion Modules, see the
Polycom_VVX_Expansion
» Connect an auxiliary cable from the AUX port on the phone to the AUX 1 port on the expansion
module.
The LED lights on the module's line keys flash red and green as the module starts up. The VVX Color
Expansion Modules take approximately 20 seconds to power up.

Connect Additional Expansion Modules

After the first module is on, you can connect up to two additional modules to your VVX phone.
Polycom, Inc.
Feature Description
Selects available line key contacts, functions, and assignments.
Indicates a line or busy lamp field contact's status. The following lists the LED
Indicator behaviors shown on the expansion modules:
● Solid Green Indicates an active call in progress.
● Fast-Flashing Green Indicates an incoming call.
● Flashing Green Indicates the remote party placed the call on hold.
● Solid Red Indicates the phone of a monitored busy lamp field
contact is placing a call or is in a call.
● Flashing Red Indicates a held call.
● Flashing Green and Red Indicates the phone of a monitored busy
lamp field contact is on an active call or is receiving an incoming call.
Navigates between pages on the expansion module.
Hooks into the back of the expansion module to stand up the display.
Indicates a page's status.
• Fast-Flashing Green Indicates an incoming call on a page not currently
displayed. Press the page key with the fast-flashing green LED indicator to view
the contact with an incoming call.
• Slow-Flashing Green Indicates a monitored busy lamp field contact on a page
not currently displayed is receiving an incoming call.
• Solid Red Indicates the current page displayed.
Displays line numbers, busy lamp field contacts, Microsoft Skype for Business
presence contacts, and favorites.
Modules.
