VVX Expansion Module Hardware Feature Descriptions
Reference Feature
Number
4 Plastic Cover
Overlying
Directory Card
5 Plastic Cover
Cut Out

Connect VVX Expansion Modules

VVX Expansion Modules are powered and signaled by VVX phones and require minimal setup. After you
connect an expansion module to a VVX phone, the module is automatically configured to work with the
phone. Note that you cannot connect paper display and color display expansion modules together on the
same phone.
Web Info: Setting up Expansion Modules
For more information on setting up VVX Expansion Modules, see the
Polycom VVX Expansion
To connect the VVX Expansion Module to your phone:
» Connect an auxiliary cable from the AUX port on the phone to the AUX 1 port on the expansion
module.
The LED lights on the module's line keys flash red and green as the module starts up. The VVX Color
Expansion Modules takes approximately 20 seconds to power up, and the VVX Expansion Modules
with a paper display take approximately three seconds to power up.
You can also view the following video for a demonstration of connecting the VVX expansion module to a
VVX phone.
Polycom VVX Expansion Module Quick Start video
Polycom, Inc.
Feature Description
Protects the directory card. The directory card is a paper sheet that displays line
numbers, busy lamp field contacts, favorites, and line key functions.
Helps insert or remove the plastic cover.
Modules.
Quick Start Guide for
206
