VVX 300 Series Hardware Feature Descriptions (continued)
2 Reversible tab
3 Speaker
4 Soft keys
5 Transfer key
6 Dialpad keys
7 Messages key
8 Hold key
9 Microphone
10 Volume keys
11 Mute key
12 Speakerphone
key
13 Headset key
14 Navigation key/
Select key
15 Home key
16 Line keys
17 Screen
18 Message Waiting
Indicator

VVX 400 Series Hardware

The following figure displays the hardware features on the VVX 400, 401, 410, and 411 business media
phones. The table lists each feature numbered in the figure.
Polycom, Inc.
Getting Started with Polycom VVX Business Media Phones
Secures the handset in the cradle when your phone stand is positioned at a
high angle. To secure the handset, remove the tab, reverse it so the
protrusion points up, and re-insert it. Position the handset so the protrusion
on the tab fits into the slot on the handset.
Provides ringer and speakerphone audio output.
Enable you to select context sensitive keys that display along the bottom of
the screen.
Transfers an active call to a contact.
Enable you to enter numbers, letters, and special characters. You can also
use the dialpad keys to select menu items that have index numbers.
Enables you to access and manage instant and voice messages.
Holds an active call or resumes a held call.
Transmits audio to other phones.
Adjust the volume of the handset, headset, speaker, and ringer.
Mutes local audio during calls and conferences. The key glows red when
activated.
Enables you to place and receive calls using the speakerphone. The key
glows green when activated.
Enables you to place and receive calls through a headset. The key glows
green when an analog headset is activated, and blue when a USB or
Bluetooth headset is activated.
Scrolls through information or options displayed on the phone's screen.
Selects a field of displayed data.
Displays the Home screen from other screens, and displays the Lines and
Calls screen from the Home screen.
Enable you to select a phone line, view calls on a line, or quickly call a
favorite contact.
Shows a 3.2-inch (8.3 cm) diagonal screen with a backlight that enables you
to view menus and data.
Flashes red to indicate when you have new messages.
