VVX Expansion Module with a paper display Hardware Feature Descriptions
Reference
Number Feature
1 Line key
2 LED Indicators
3 Base Stand
4 Plastic Cover
Overlying
Directory Card
5 Plastic Cover
Cut Out

Connect VVX Expansion Modules

VVX Expansion Modules are powered and signaled by VVX phones and require minimal setup. After you
connect an expansion module to a VVX phone, the module is automatically configured to work with the
phone.
For more information on setting up VVX Expansion Modules, see the
Expansion Modules.
Note: You cannot connect paper display and color display expansion modules together on the same phone.
» Connect an auxiliary cable from the AUX port on the phone to the AUX 1 port on the expansion
module.
The LED lights on the module's line keys flash red and green as the module starts up. The VVX Color
Expansion Modules takes approximately 20 seconds to power up, and the VVX Expansion Modules
with a paper display take approximately three seconds to power up.
Polycom, Inc.
(Adapted by Atlantic Broadband)
Feature Description
Selects available line key contacts, functions, and assignments.
Indicates a line or busy lamp field contact's status. The following lists the LED
Indicator behaviors shown on the expansion modules:
● Solid Green Indicates an active call in progress.
● Fast-flashing Green Indicates an incoming call.
● Flashing Green Indicates the remote party placed the call on hold.
● Solid Red Indicates the phone of a monitored busy lamp field
contact is placing a call or is in a call.
● Flashing Red Indicates a held call.
Hooks into the back of the expansion module to stand up the display.
Protects the directory card. The directory card is a paper sheet that displays line
numbers, busy lamp field contacts, favorites, and line key functions.
Helps insert or remove the plastic cover.
Phone Accessories
Quick Start Guide for Polycom_VVX
99
