Polycom VVX Business Media Phones User Guide
VVX Expansion Module Hardware Feature Descriptions
Reference Feature
Number
4 Plastic Cover
Overlying
Directory Card
5 Plastic Cover
Cut Out

Connect VVX Expansion Modules

VVX Expansion Modules are powered and signaled by VVX phones and require minimal setup. After you
connect an expansion module to a VVX phone, the module is automatically configured to work with the
phone. Note that you cannot connect paper display and color display expansion modules together on the
same phone.
Web Info: Setting up Expansion Modules
For more information on setting up VVX Expansion Modules, see the
Polycom VVX Expansion
To connect the VVX Expansion Module to your phone:
» Connect an auxiliary cable from the AUX port on the phone to the AUX 1 port on the expansion
module.
The LED lights on the module's line keys flash red and green as the module starts up. The VVX Color
Expansion Modules takes approximately 20 seconds to power up, and the VVX Expansion Modules
with a paper display take approximately three seconds to power up.

Connect Additional Expansion Modules

After the first module is on, you can connect up to two additional modules to your VVX phone.
To connect multiple VVX Expansion Modules:
1 Connect an auxiliary cable from the AUX 2 port on the first module connected to the phone to the
AUX 1 port on the second module.
2 Connect an auxiliary cable from the AUX 2 port on the second module to the AUX 1 port on the third
module.
The LED lights on the line keys light up for each connected module as the expansion modules start
up.

Using VVX Expansion Modules

This section includes the following topics on how to use the VVX Expansion Modules with your VVX phone:
Assigning Busy Lamp Field Contacts, Microsoft Lync Contacts, and Favorites
●
Generate the VVX Expansion Module Directory Card
●
Polycom, Inc.
Feature Description
Protects the directory card. The directory card is a paper sheet that displays line
numbers, busy lamp field contacts, favorites, and line key functions.
Helps insert or remove the plastic cover.
Modules.
Quick Start Guide for
200
