Operation

9.2.3 Creating tramlines

Switching off seed wheels
1
6 2
2
1
4
If using a cultivation tractor with a differing track width, it is recommended that you
mount switchable seed wheels (1) with a gear wheel (2) on the sowing shaft (7) in
all rows as well as gearwheels (4) on the countershaft (5) so that the seed wheels
can be switched off to create tramlines.
3
7
5
To create tramlines, switchable seed
wheels (1) with a gearwheel (2) are moun-
ted in the rows instead of conventional
seed wheels (3). These switchable seed
wheels can be switched off when you want
to create tramlines.
The gearwheels (2) of the switchable seed
wheels (1) must each engage with a gear-
wheel (4) on the countershaft (5) and be
brought into the freewheeling position. To
enable this, the grub screws (6) - 2 per
gearwheel - must be twisted out 1 to 2 mm.
