Operation
1
6
7
5
4
5
9
4
6
To switch off the switchable seed wheels
(1) for creating tramlines:
1. Disconnect the grub screws (6) from
the sowing shaft (7) by turning them
out (1-2 mm) and bring the seed
wheels into the freewheeling position.
2. Move the gearwheels (4) on the coun-
tershaft (5) so that they engage with
the gearwheels (2) of the switchable
seed wheels (1).
3. Secure the gearwheels (4) on the
countershaft using clamps (9).
In the case of two-part gearwheels (4), the
gearwheel (4) must be secured by means
of tightening the clamping bolts (6) on the
countershaft (5).
61
