Operating Instructions
Furrow Press
FixPack
with hydraulic frame swing-in assy.
- EN -
Safety is our concern!
Part No. 175 3828
EN-1/06.04
LEMKEN GmbH & Co. KG
Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen
Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220
E-Mail: lemken@lemken.com, Internet: http://www.lemken.com
Advertisement
Related Manuals for LEMKEN FixPack F 150
Summary of Contents for LEMKEN FixPack F 150
- Page 1 - EN - Safety is our concern! Part No. 175 3828 EN-1/06.04 LEMKEN GmbH & Co. KG Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220 E-Mail: lemken@lemken.com, Internet: http://www.lemken.com...
- Page 3 Only use genuine Lemken spare-parts. Spurious parts negatively influence the function of the implement, show a shorter lifetime and increase in nearly all cases additional maintenance. We trust that you will understand that LEMKEN unable to guarantee poor operation and damage caused by using spurious parts!
- Page 4 Under „defined use“ the manufacturer’s prescribed operation-, maintenance- and repair conditions are to be adhered The LEMKEN FixPack may only be operated, maintained and repaired by such persons who have been made acquainted with it and who have been advised about the dangers! ...
- Page 5 4.4 Reconsolidation and crumbling effect of the roller ....... 12 ROLLERS ....................13 5.1 Cutting bar ..................13 5.2 Knife bar for star roller ..............14 PLOUGHING THE FIRST FURROW ............15 TRANSPORT ON PUBLIC ROADS ............17 7.1 Transport in half-turned position with depth- and transport wheel17 7.2 Transport in working position ............
- Page 6 1 SAFETY INSTRUCTIONS General Safety Instructions Before using the machine, always check both it and the tractor for roadworthiness and operational safety! As well as the notes in these instructions the operator is advised to comply with the generally applicable safety at work regulations and those relating to use of the public highway! ...
- Page 7 (e.g. raising/lowering) and there is a risk of accidents! Regularly check the hydraulic pipes and replace them in the event of damage or signs of ageing. The replacement pipes must comply with the technical specification as laid down by Lemken.
- Page 8 Hydraulic oil escaping at high pressure can penetrate the skin and cause serious injury! Before working hydraulic equipment lower implements/attachments, release hydraulic pressure where possible and switch off the tractor engine. Maintenance Repair-, maintenance- and cleaning operations as well as adjustments and remedy of function faults should principally be conducted with engine stopped and brakes applied.
- Page 9 2 WARNING STICKERS 2.1 General Instructions The LEMKEN FixPack is equipped with all features to ensure safe operation. Where potential danger areas of the implement can not be fully safeguarded, warning stickers are fitted which draw attention to these. 2.2 Meaning of the stickers Familiarise with the meaning of the stickers.
- Page 10 WARNING: Pinch Point! 390 0506 WARNING: Keep well clear of the working and swinging area of the implement! 390 0510 WARNING: Keep well clear of the turning and swinging area of the implement! 390 0520...
- Page 11 3 ATTACHMENT OF THE FIXPACK PRESS The FixPack can be fitted to the following LEMKEN mounted reversible ploughs, which are equipped with a suitable flange plate (F1). max. allowed number EuroPlough 5 and EuroPlough 6 to 9 and of furrows...
- Page 12 3.3 Fitting of the hydraulic ram The hydraulic ram (H1) will be fitted to the arm (F4) and the bracket (F2) as shown on the picture. 3.4 Fitting of the roller The frame tube of the roller (W0) will be fitted at the rear to the bracket of the adjustment device (S1).
- Page 13 4 ADJUSTMENTS 4.1 Length adjustment of the arm The length of the arm (F4) will be adjusted so that the roller (W0) runs always between the second and third body. If necessary displace the carrier (F5) on the arm (F4) as required.
- Page 14 4.4 Reconsolidation and crumbling effect of the roller By means of the pin adjustment (K1) the crumbling effect of the roller can be adjusted. Use pin (K2) which is positioned behind the guiding stop (K3), to adjust the reconsolidation effect. Use pin (K4) which is positioned in front of the guiding stop (K3) to limit the lowering movement of the roller in relation to the arm.
- Page 15 5 ROLLERS The FixPack is available with Ø 270 mm flat bar roller with cutting bar, Ø 330 mm tube bar roller with cutting bar, Ø 500 mm synthetic roller with scraper or Ø 330 mm star roller with cutting bar. Synthetic roller with scraper Star roller with cutting bar 5.1 Cutting bar...
- Page 16 5.2 Knife bar for star roller The knife bar (M1) will be fitted to the front carrier plates (M2) of the star roller. The working depth of the knifes (M3) will be adjusted by means of the pins (M4). If it is required to work without knife bar, the bar must be lifted completely and fixed in this position.
- Page 17 6 PLOUGHING THE FIRST FURROW Depending on ploughing the first furrow in the area of hedges, fences or other obstacles or for example in the area of ditches, it may be necessary to swing-in the FixPack. If the FixPack must be swung in for the first furrow, the first furrow must be ploughed right handed.
- Page 18 Swing-in the roller by means of a hydraulic ram (H1). Now the first furrow can be ploughed. Attention: The roller (W0) integrated packer FixPack is now positioned in a „swung- in“ position. In this position the locking pin (P3) may never be unlocked, as the centre of gravity is raised.
- Page 19 7 TRANSPORT ON PUBLIC ROADS 7.1 Transport in half-turned position with depth- and transport wheel Lock the locking pin of the turnover device. Convert depth- and transport wheel to transport position. Turn plough frame into half-turned position. ...
- Page 20 Therefore the plough will be turned in left handed working position, the roller turned by 90° and locked, the axle (P2) locked, the locking pin (P3) locked and the plough turned in right handed working position. After that swing-in the arm (F4) as far as possible to the plough and lock it.
- Page 21 8 PARKING THE PLOUGH WITH ATTACHED FIXPACK The plough with attached FixPack may only be parked on level and firm ground. Before detaching the plough, the stand (A1) must be swung-down and secured by means of the pin (A2). Attention: The FixPack may only be attached to the plough or detached from the plough, when the plough is attached to the tractor.
- Page 22 9 MAINTENANCE All greasing points must be greased first after 5 working hours and then every 20 working hours. The guiding of the locking pins must be greased regularly, in order to ensure their function. Important: Do not clean this implement with a Pressure Washer during the first 6 weeks.
- Page 23 10 WEIGHTS Type Description Working width Weight apprx. cm apprx. kg FixPack F 150 with flat bar roller Ø 270 FixPack F 200 mm and cutting bar FixPack F 250 FixPack R 150 with tube bar roller Ø 330 FixPack R 200...
