COUPLING AND UNCOUPLING THE SEED DRILL

4.1

General information

2
1

4.1.1 Coupling parts for LEMKEN soil-working implements

2
- So that the coupled implement is as close as possible to the soil-working im-
plement without colliding with it
20
Coupling and uncoupling the seed drill
The implement is coupled to the three-
point linkage of the soil-working implement
or tractor using its three-point tower by
means of coupling parts and a drawbar (1)
and upper link bolt (2). The coupling parts
are available in three versions.
In this version, the implement can be at-
1
tached to the hydraulic three-point linkage
of a LEMKEN soil-working implement fitted
with special attachment parts (1). The aux-
iliary frame (2) must be connected with the
control arms of the hydraulic three-point
linkage as follows:
- In a way that ensures parallel lifting
