Fill level monitoring
12.2

Electronic fill level monitoring

3
If required, a second sensor can be provided. This is mounted on the opposite si-
de of the seed box.
As soon as there is no seed in front of the sensor, the control terminal issues an
acoustic and optical alarm.
The electronic fill level monitoring system,
which includes a sensor (3) in the seed
box, is available as an optional accessory.
It can only be used with an electronic seed
drill control system.
It is mounted at the side of the seed box
and can be positioned on the holder in line
with the height of the desired residual
quantity.
