Power Consumption - Quectel RG520N-AT Hardware Design

USB_VBUS USB connection detect

6.3. Power Consumption

Table 48: Power Consumption
Mode Conditions
Power-off Power off
AT+CFUN=0 (USB 3.0 suspend)
RF Disabled
AT+CFUN=4 (USB 3.0 suspend)
SA FDD PF = 64 (USB 3.0 suspend)
Sleep State
SA TDD PF = 64 (USB 3.0 suspend)
SA PF = 64 (USB 2.0 active)
Idle State
SA PF = 64 (USB 3.0 active)
LTE LB @ 23 dBm
LTE LTE MB @ 23 dBm
LTE HB @ 23 dBm
DL 3CA, 256QAM
LTE CA UL 1CA, 256QAM
Tx power @ 23 dBm
5G NR LB @ 23 dBm
5G NR MB @ 23 dBm
5G SA
(1 Tx)
5G NR HB @ 23 dBm
5G NR UHB @ 26 dBm
5G SA
5G NR UL 2 × 2 MIMO @ 26 dBm
(2 Tx)
RG520N-AT_Hardware_Design
values.
Band/Combinations
-
-
-
-
-
-
-
B5
B2
B30
CA_2A-5A-66A
n12
n66
n30
n77
n77
5G Module Series
3.3 5.0 5.25
Current Unit
μA
150
4 mA
4.1 mA
9.3 mA
9.3 mA
40 mA
60 mA
TBD mA
TBD mA
TBD mA
TBD mA
TBD mA
TBD mA
TBD mA
TBD mA
TBD mA
84 / 109
V
