4.4. Power Consumption

The following tables show the power consumption of the module in different modes.
4.4.1. Power Consumption in Low Power
This chapter information will be included in the future version of this document.
4.4.2. Power Consumption
Table 21: Power Consumption in OFF State and Idle
Description Conditions
OFF State AT+QWIFI=0
Idle AT+QWIFI=1
Table 22: Power Consumption in ANT_WIFI0/BT (SISO Mode, Unit: mA)
Description Conditions
TX (2.4 GHz) 1 Mbps
802.11b
TX (2.4 GHz) 11 Mbps
TX (2.4 GHz) 6 Mbps
802.11g
TX (2.4 GHz) 54 Mbps
TX (2.4 GHz) HT20 MCS0
TX (2.4 GHz) HT20 MCS7
TX (5 GHz) HT20 MCS0
802.11n
TX (5 GHz) HT20 MCS7
TX (5 GHz) HT40 MCS0
TX (5 GHz) HT40 MCS7
802.11a TX (5 GHz) 6 Mbps
FC80A_Hardware_Design
Wi-Fi&Bluetooth Module Series
Modes*
I (Typ.)
WLAN3V3
4
130
VBAT (3.3 V)
428
416
400
299
409
279
376
293
383
295
392
I (Typ.) Unit
VIO
225 µA
0.30 mA
VDDIO (1.8 V)
0.875
0.875
0.850
0.865
0.864
0.870
0.840
0.847
0.841
0.848
0.44
