Tx Power; Rx Sensitivity - Quectel RG520N-AT Hardware Design

Table 39: Truth Table of Antenna Tuner Control Interfaces
GRFC0 Level
Low
Low
High
High

5.1.3. Tx Power

The following table shows the RF output power of the module.
Table 40: Tx Power
Mode Frequency Bands
LTE LTE bands
5G NR bands
5G NR
5G NR HPUE band
(n77)
.
NOTE
For 5G NR bands, they have different standards for different channel bandwidth, see the specifications
as described in Clause 6.3.1 of TS 38.101-1 [2].

5.1.4. Rx Sensitivity

The following table shows conducted RF receiving sensitivity of the module.
RG520N-AT_Hardware_Design
GRFC1 Level
Low
High
Low
High
Frequency Range (MHz)
TBD
TBD
TBD
TBD
Max. Tx Power
23 dBm ± 2 dB (Class 3)
23 dBm ± 2 dB (Class 3)
26 dBm +2/-3 dB (Class 2)
5G Module Series
Band
TBD
TBD
TBD
TBD
Min. Tx Power
< -40 dBm
< -40 dBm
< -40 dBm
72 / 109
