6.4. Digital I/O Characteristics
Table 49: 1.8 V I/O Requirements
Parameter
Description
V
Input high voltage
IH
V
Input low voltage
IL
V
Output high voltage
OH
V
Output low voltage
OL
Table 50: (U)SIM 1.8 V I/O Requirements
Parameter
Description
USIM_VDD
Power supply
V
Input high voltage
IH
V
Input low voltage
IL
V
Output high voltage
OH
RG520N-AT_Hardware_Design
CA_n77C
DC_2A-n77
Min.
Max.
1.26
2.1
-0.3
0.54
1.35
-
-
0.45
Min.
Max.
1.65
1.95
1.26
2.1
-0.3
0.36
1.44
-
5G Module Series
TBD
mA
TBD
mA
Unit
V
V
V
V
Unit
V
V
V
V
85 / 109
