5

RF Specifications

Appropriate antenna type and design should be used with matched antenna parameters according to
specific application. It is required to perform a comprehensive functional test for the RF design before
mass production of terminal products. The entire content of this chapter is provided for illustration only.
Analysis, evaluation and determination are still necessary when designing target products.

5.1. Cellular Network

5.1.1. Antenna Interfaces & Frequency Bands
Table 35: Pin Definition of Cellular Antenna Interfaces
Pin Name Pin No.
ANT0 130
ANT1 157
ANT2 166
ANT3 184
RG520N-AT_Hardware_Design
I/O Description
Antenna 0 interface:
- 5G NR: n77 TRX0
AIO
- LTE: LMB_TRX0 & HB_DRX
- Refarmed: LMB_TRX0 & HB_TRX1
Antenna 1 interface:
- 5G NR: n77 DRX MIMO
AIO - LTE: LMB_PRX MIMO & HB_DRX MIMO
- Refarmed: LMB_PRX MIMO & HB_DRX
MIMO
Antenna 2 interface:
- 5G NR: n77 PRX MIMO
AIO - LTE: LMB_DRX MIMO & HB_PRX MIMO
- Refarmed: LMB_DRX MIMO & HB_PRX
MIMO
Antenna 3 interface:
- 5G NR: n77 TRX1
AIO
- LTE: LMB_TRX1 & HB_TRX0
- Refarmed: LMB_TRX1 & HB_TRX0
5G Module Series
Comment
50 Ω impedance.
