Danfoss VACON 1000 Operating Manual page 74

VACON® 1000 Fieldbus Options
Operating Guide
Table 51: Module and Network Indicator Light Definitions
Module indicator (MS) state
OFF
Green on
Green on
Other
7.3.2 Power Supply Terminal
1
2
3
Illustration 33: Power Supply Terminal Pinout
Table 52: Power Supply Terminal Specification
Pin
1
2
3
7.3.3 Serial I/II/III Terminal
1
2
3
Illustration 34: Serial I/II/III Terminal Pinout
Table 53: Serial I/II/III Terminal Specification
Pin RS485 Function
1 D+, RS485 data positive
2 D-, RS485 data negative
3 GND
7.3.4 RS485 Characteristics
• Network topology: Linear bus, there are active bus terminal resistors at both ends. If the communication quality is unstable, it is
recommended to add terminal resistors (120 Ω, ½ W) in parallel with the 2 data wires at both ends of the bus. Serial interfaces
I/II/II all have a built-in terminal resistor.
• Media: Shielded twisted-pair cable. Shielding can be canceled, depending on environmental conditions (EMC).
• Station number: 32 stations per subsection (without repeater), and can increase up to 127 stations (with repeater).
• Plug connection: 3-pin pluggable terminal. Each terminal is equipped with a 120 Ω terminal resistor switch.
74 | Danfoss A/S © 2023.09
Network indicator (NS) state
Red blinking
Red blinking
Green on
Other
Function
Power GND
Not connected
+24 V DC
RS232 Function
TX, RS232 data transmit (connect to RX of user device)
RX, RS232 data receive (connect to TX of user device)
GND (connect to user device RS232 GND)
Description
Start-up state, waiting to initialize
Initialization complete, but no connection yet with PLC
PLC has connected
Undefined state
AQ454734633756en-000101 / 172K1112
PROFINET I/O
