VACON® 1000 Fieldbus Options
Operating Guide
1
2
3
Illustration 27: RS485 Terminal Pinout
Table 47: RS485 Terminal Specification
Pin
1
2
3
6.3.6 RS232 Terminal
The RS232 interface uses an open 3-pin pluggable terminal.
1
2
3
Illustration 28: RS232 Terminal Pinout
Table 48: RS232 Terminal Specification
Pin Function
1 RX, connects to RX of user device RS232
2 TX, connects to TX of user device RS232
3 GND, connects to GND of user device GND
6.3.7 DeviceNet™ Terminal
1 2 3 4
Illustration 29: DeviceNet Terminal Pinout
™
Table 49: DeviceNet Terminal Specification
™
Pin
1
2
3
4
5
68 | Danfoss A/S © 2023.09
Function
GND
B-, RS485
A+, RS485
5
Wiring
GND (24 V)
CAN-
Shielding
CAN+
+24 V
DeviceNet™
