VACON® 1000 Fieldbus Options
Operating Guide
1 Power supply terminal
2 Configuration button
3 Indicator lights
4 USB terminal
5.3.1 Indicator Light Definitions
Table 27: Indicator Light Definitions
Indicators Status
CANopen status ERR Red off
Red on
Red blinking
RUN Green on
Green on every 200 ms, off every
1000 ms
Green on every 200 ms, off every
200 ms
Serial status TX Green blinking
Green off
RX Green blinking
Green off
5.3.2 LED Display
Table 28: LED Display Definitions
LED Display Description
01–99 The slave address when the gateway acts as a CANopen slave or a Modbus slave
CF The gateway is in the configuration state
Eo CAN sending error
88 (blink once) Restarting
5.3.3 CANopen Terminal
5 4 3 2
Illustration 16: CANopen Terminal Pinout
Danfoss A/S © 2023.09
1
5 LED display
6 CANopen terminal
7 Terminal resistor switch
8 Modbus terminals
Description
CAN network is normal
CAN port error (baud rate error, Bus off)
The error counter of CAN controller reach or exceed alarm value
Operation state
Stop state
Preoperation state
Serial port is sending data
Serial port no connection or error
Serial port is receiving data
Serial port no connection or error
AQ454734633756en-000101 / 172K1112 | 51
CANopen
