Qmt-5302Nv Vertical Master Telephone - Mircom FleXNet FNC-2000 Installation And Operation Manual

TM
FleX-Net Installation and Operation Manual

QMT-5302NV Vertical Master Telephone

The QMT-5302NV Vertical Master Telephone Module fits into the new BBX-FXMNS Enclosure. The master
telephone is mounted to the inside chassis and field wiring is on the BBX-FXMNS backbox. CONNECTIONS AND
TERMINAL WIRING ARE THE SAME AS THE QMT-5302N, WIRE AS SHOWN IN THE FOLLOWING
INSTRUCTIONS FOR QMT-5302N MASTER FIREFIGHTERS' TELEPHONE.
Figure 78: QMT-5302NV Master Firefighters' Telephone
CALL CONTROL
TROUBLE
INCOMING CALL
ACTIVE
DESELECT ALL CALL CONTROL
113
