ANC-5000 Wiring

Figure 66: ANC-5000 Wiring Diagram
+ - + - + - S
Alternate
Power
IN
100
G.A.
RS-485
Input
IN
NOT USED
3K9 ohms 3K9 ohms
Connect resistors to + and - of MIC and PTT
terminals when master microphone and
telephone is not used.
JW7 JW8
MIC PTT
+ - L + - S
+ - S
Microphone
and push to
talk (PTT)
button is
wired to
Master
Paging
module
L terminal NOT USED
PAGING BUS
+ - S
IN OUT
Wire the Paging Bus
to all other ANC-5000
Audio Network
Controller Modules,
see Figure 73.
