Configuration

Configuration
TM
The FleX-Net network system which includes FX-2003-12N/DS, FX-2009-12N/DS, FX-2017-12N/DS, and
FX-2000MNS is configured using Mircom software MSW-025.
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the requirements in
the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864 and the Standard for Control Units for
Fire Alarm Systems, CAN/ULC-527, certain programming features or options must be limited to specific values or not
used at all as indicated below.
Program feature or option
Alarm Transmit Silence
COPTIR/A Detector
Sensitivity Levels
APB-200/COA Sounder
base correlation to Fire
input
APB-200/COA Sounder
base correlation to CO
input
Configuration Backup, Query and Fast-Forward
The panel supports previous, current and next configuration. The panel can be load configured without taking the
panel off-line. Configuration reverts back to previous or moves to future configuration through front-panel menu.
OPEN Graphic Navigator Software Package
This software package (OPEN GN) allows 3D graphic display of premises and devices. It provides unlimited floor
plans and events, node and job support. It supports input file formats for floors such as: .svg, .dxf, .pdf, .png, .wmf,
.jpeg. Device icons and state animations can be customized.
Ethernet Port
Integrated TCP/IP Stack, Hardware based MAC address. Provides a fully configurable IP address. Use this Ethernet
port to connect to OPEN graphics software. This port also provides web server for diagnostic and system report via
LAN or WAN connection on-site or remotely.
Boolean Logic Engine
Boolean logic functions are now available within the configuration software. Sophisticated logic functions such as:
AND, OR, NOT, ANY n of m, >, <, >=, <>
Built-in timers or user configurable timers and intervals and schedules available to support UUKL operations.
uBoot Based BootLoader
This program (inherent in the configuration) provides leading technology that allows a choice of multiple
configuration files or firmware revisions to support site-specific requirements.
TM
The FleXBoot shell offers UNIX style commands for directory listing, log download, diagnostic probing and
system tuning and optimization.
70
Permitted in UL 864,
CAN/ULC-S527? (Y/N)
No
Yes
Yes
No
Possible settings
Enabled or Disabled
Levels 1 through 6
No sound (no correlation),
Temporal-3, Temporal-4,
March Code, Maintenance
Chirp, Continuous Tone
No sound (no correlation),
Temporal-3, Temporal-4,
March Code, Maintenance
Chirp, Continuous Tone
Settings permitted in UL 864,
CAN/ULC-S527
Disabled or unchecked
Levels 2 through 6
Temporal-3
No Sound (no correlation)
