Network Intelligent Analog Fire Alarm and Audio System
LT-894 Rev 4
Installation and Operation Manual
October 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FleXNet FNC-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mircom FleXNet FNC-2000

Summary of Contents for Mircom FleXNet FNC-2000

  • Page 1 Network Intelligent Analog Fire Alarm and Audio System LT-894 Rev 4 Installation and Operation Manual October 2016...

  • Page 3: Table Of Contents

    FleX-Net Installation and Operation Manual Table of Contents Introduction ..........................1 Additional Features........................3 Document Conventions......................3 System Components ....................... 6 Mechanical Installation and Dimensions ................14 BBX-1024XT/R Mechanical Installation.................. 17 Module Mounting Locations ....................20 Display and Adder Modules Mounting Locations..............22 Module Settings ........................
  • Page 4 Table of Contents Displays & Controls ........................ 96 Amplifier Displays......................... 96 Setup ............................97 QBB-5001/R Amplifier Installation..................97 Before Turning the Power "ON"................... 97 Audio Configuration........................ 97 Lobby Enclosures ........................98 ANC-5000 Audio Network Controller Module ............... 99 ANC-5000 Wiring ........................100 QMP-5101NV Vertical Paging Control Module..............

  • Page 5: Introduction

    LCD display. The FleX-Net configuration allows the FleX-Net Fire Alarm Control Panels to be connected to a Mircom network which provides additional input circuits, visual zones, programmable notification appliance circuits and relays. In addition, a FleX-Net Integrated Fire and Audio panel can be used to provide a fully distributed audio and/or integrated telephone system.
  • Page 6 Introduction • Configurable Signal Silence Inhibit, Auto Signal Silence, Two-Stage Operation, Assisted Walk Test. • Outputs for 4 Wire resettable Smoke Power Supply, Auxiliary Power Supply, and an interface to the Mircom RTI- 1 Remote Trouble Indicator. • RS-485 Interface for Remote Annunciators. Remote Annunciators do not occupy a node on the network. Up to seven annunciators can be connected per node.

  • Page 7: Additional Features

    FleX-Net Installation and Operation Manual Additional Features Blackfin based Quad Loop Adder module ALCN-792M. The ALCN-792M is a 2 loop addressable adder module with provision to connect a daughter board ALCN-792D which contains an additional 2 addressable loops for a total of four addressable loops.
  • Page 8 Document Conventions...
  • Page 9 FleX-Net Installation and Operation Manual...

  • Page 10: System Components

    System Components Chassis Types Model Description 12 Amp Mid-Size Main Chassis. This mid-size main chassis comes complete with one Analog Loop Controller (159 AP Analog Sensors and 159 AP Addressable Modules), 4 Class A/B (Style Z/Y) NACs (1.7 Amp each), a DSPL-420 4 line by 20 character LCD display and a 12 ampere power supply which charges 17-65 AH batteries.
  • Page 11 FleX-Net Installation and Operation Manual Model Description 12 Amp Large Main Chassis. This large main chassis comes complete with one Analog Loop Controller (159 AP Analog Sensors and 159 AP Addressable Modules), 4 Class A/B (Style Z/Y) NACs (1.7 Amp each), a DSPL-420 4 line by 20 character back-lit LCD display, and a 12 ampere power supply which charges 17-65 AH batteries.
  • Page 12 System Components Network Controller Modules Model Description Provides network capability for the FX-2000N Fire Alarm panel. One module is required per one FNC-2000 network node panel. The FNC-2000 Fire Network Controller module is mounted in position 2 over the FX-2000N main board. Audio Network Controller module.
  • Page 13 FleX-Net Installation and Operation Manual Model Description DM-1008A Eight Initiating Circuit Module SGM-1004A Four NAC circuit Module RM-1008A Eight Relay Circuit Module PR-300 Polarity Reversal and City Tie Module UDACT-300A Digital Communicator/Dialer Module Display Modules Model Description FDX-008 Fan Damper Module 4 line by 20 character display which can be mounted into backboxes, BBX- DSPL-420...
  • Page 14 System Components Model Description Programmable Input Switches Module (mounts IPS-2424DS with the FX-2009-12NDS and can also be part of the RAXN-LCD) Model RAM-1032TZDS Main Chassis Remote RAM-1032TZDS Annunciator with 16 Bi-coloured LEDs and 32 trouble LEDs. Model RAX-1048TZDS Adder Annunciator RAX-1048TZTZDS Chassis with 48 Bi-coloured LEDs and 48 trouble LEDs.
  • Page 15 FleX-Net Installation and Operation Manual Model Description Network Master Telephone Control Panel QMT-5302NV (Vertical Mount) mounts within the BBX-FXMNS enclosure. QAZT-5302DS Zoned Paging and Telephone Selector Panel Booster Power Supply Model Description Addressable Booster Power Supply mounts to backboxes BB-5014 and BBX-FXMNS. Same unit as the INX-10A and INX-10ADS, except INX-10AC this model comes with a chassis for mounting.
  • Page 16 System Components Flush Trim Rings Model Description Black flush trim ring for BBX-1072ADS and FA-1072TR BBX-1072ARDS. Remote Annunciators Model Description Remote Shared Display Annunciator. Please refer RAXN-LCD to LT-895 RAXN-LCD manual for further information. Remote Shared Graphical Display Annunciator. RAXN-LCDG Please refer to LT-6033 RAXN-LCDG manual for further information.
  • Page 17 Description FX-LOC(R) consists The FX-LOC(R) Local Operating Console along FX-LOC Enclosure includes backbox, inner with the Mircom FleX-Net Network Fire Alarm door and outer white door. system facilitates a Mass Notification System. FX-LOCR, the R suffix The FX-LOC(R) provides critical emergency (as represents a red door.

  • Page 18: Mechanical Installation And Dimensions

    Mechanical Installation and Dimensions Install the enclosure as shown for the BBX-1024DS installation information is in Figure 1. For the BBX-1072ADS see Figure 2, on the following page. Figure 3 demonstrates the BB-5008 backbox installation. Figure 1: .BX-1024DS Flush and Surface Enclosure Installation and Dimensions BBX-1024DS BACKBOX AND DOOR 5 3/4”...
  • Page 19 FleX-Net Installation and Operation Manual Figure 2: BBX-1072ADS Flush and Surface Installation and Dimensions Material: Cold rolled steel, 16GA (0.059”) thick for backbox, 14GA (0.075”) thick for door Finish: Painted except for hinges...
  • Page 20 Mechanical Installation and Dimensions Figure 3: BB-5008 Enclosure Installation Instructions and Dimensions Material: Cold rolled steel BB-5008 Backbox Backbox 16GA (0.059”) thick for backbox 14GA (0.075”) thick for door Finish: Painted except for hinges Backbox with DOX-5008M Door DOX-5008M Metal Door...

  • Page 21: Bbx-1024Xt/R Mechanical Installation

    FleX-Net Installation and Operation Manual BBX-1024XT/R Mechanical Installation The model FX-2003-12NXTDS is an expanded version of the FX-2003-12NDS chassis. The FX-2003- 12NXTDS mounts into the BBX-1024XT(white enclosure) and the BBX-1024XTR(red enclosure) 14.76” wide by 35.8” long by 5.45” Dimensions 16GA (0.059”) thick for backbox Cold Rolled Steel 14GA (0.075”) thick for door Cold Rolled Steel...
  • Page 22 BBX-1024XT/R Mechanical Installation General Chassis Installation 1. Group the incoming wires through the top of the enclosure to prepare it for wiring the modules. Do not run the wires in-between the modules since it could cause a short circuit. 2. Use a wire tie to group wires for easy identification and neatness. 3.
  • Page 23 FleX-Net Installation and Operation Manual Figure 5: Installation Instructions and Dimensions for BB-5014 BB-5014 Backbox Backbox Material: Cold rolled steel 16GA (0.059”) thick for backbox 14GA (0.075”) thick for door Finish: Painted except for hinges Backbox with DOX-5014M Door DOX-5014M Metal Door Note: Mount the power supply in the same manner as shown in Figure 3.

  • Page 24: Module Mounting Locations

    Module Mounting Locations The FX-2003-12NDS or FX-2017-12NDS Main Chassis come pre-assembled with a main fire alarm board, display components and boards. Install the adder modules of different types as shown in the diagrams on the following pages. Notes: For many adder modules to enable communication from the main module to all of the adder modules, it is necessary to add a continuity jumper on the last adder module in a chain (see the appropriate module settings section to verify the location of the continuity jumper on a particular circuit adder module).
  • Page 25 FleX-Net Installation and Operation Manual Figure 7: Module Mounting Locations View #2 Provision for PR-300 or Main Chassis UDACT-300A FX-20XX-12N/DS FNC-2000 in position 2 and other Adder Module in position 1 MD-579 MD-575 Long Ribbon Cable MD-579 Short Power Cable MD-580 Long Power Cable FNC-2000 Fire Network Controller Module This module is required in the main lobby and one per node.

  • Page 26: Display And Adder Modules Mounting Locations

    Display and Adder Modules Mounting Locations FX-2003-12NDS Compact Main Chassis Mounts in the BBX-1024DS Enclosure and supports three adder modules. Interior View Inside Backbox View Slot 3 is reserved for PR-300 or UDACT-300A. If not required, this slot can be used to mount any of the adder modules.
  • Page 27 FleX-Net Installation and Operation Manual FX-2017-12NDS Mid-size Main Chassis Mounts in the BBX-1072ADS/ARDS Enclosure, and supports three display modules and 17 adder modules. Interior View Inside Backbox View FX-2000N Main Board FX-2000 Main Board Slot 3 is reserved for PR-300 or UDACT- 300A.
  • Page 28 Display and Adder Modules Mounting Locations ECX-0012 Expander Chassis for FX-2009-12NDS Mounts and occupies two display positions in BB-5008 or BB-5014 Enclosures, and supports two display and 12 adder modules. Interior View Inside Backbox View Cutout to mount Cutout to mount display module display module NETWORK CONTROLLER MODULES...
  • Page 29 FleX-Net Installation and Operation Manual Display Modules Each display module occupies one display position and mounts to the display cutouts on the following chassis: • FX-2003-12NDS Compact Main Chassis • FX-2003-12NXTDS Mid-size Main Chassis • FX-2017-12NDS Mid-size Main Chassis • FX-2009-12NDS Large Main Chassis •...

  • Page 30: Module Settings

    Module Settings Main Fire Alarm Module (MD-871A “N” Version Main Chassis) This main board has one addressable loop and network capability. Jumper is removed if a PR-300 or UDACT-300A is installed. Jumpers are Factory Set and should not be changed. JW2,JW4 Normally un-installed, add jumper to silence on-board buzzer.
  • Page 31 FleX-Net Installation and Operation Manual SW2 DIP Switch Node Address Setting on Main Fire Alarm Module Refer to table in Appendix C: DIP Switch Settings for Node Address Setting. Available addresses are 1 to 63. DIP Switch SW2-1 is the least significant digit. DSPL-420 Main Display Module The DSPL-420 mounts into backboxes BB-5008(R), BB-5014(R) and BBX-FXMNS.
  • Page 32 Module Settings DSPL-2440 Graphical Main Display Module The DSPL-2440 is a separate item. It can be mounted into backboxes BB-5008(R), BB-5014(R) and BBX-FXMNS. It can replace the DSPL-420 found with the following models: FX-2003-12NDS, FX-2003-12XTDS, FX-2009- 12NDS, FX-2017-NDS, and FX-2000MNS. Figure 10: DSPL-2440 Graphical Main Display Module P1: Cable connects to P14 of the FX-2000N main fire alarm board (Figure 8).
  • Page 33 FleX-Net Installation and Operation Manual FNC-2000 Fire Network Controller Module An FNC-2000 Fire Network Controller module is required in each fire alarm node in the system. The FNC-2000 also provides a connection for an optional FOM-2000-SP Fiber Optics Module. Figure 11: FNC-2000 Fire Network Controller Module This cable connects to P19 on the...
  • Page 34 Module Settings Figure 12: FOM-2000-SP Fiber Optic Network Module One of these modules is required at each panel where fiber optics will be used between them. The FOM-2000-SP will be mounted over the FNC-2000 Network board (over the field wiring terminals) with two #6 Phillips screws and two Hex spacers.
  • Page 35 FleX-Net Installation and Operation Manual Figure 14: IPS-2424DS Programmable Input Switches Module ZONE ZONE ZONE ZONE ZONE ZONE BYPASS BYPASS BYPASS BYPASS BYPASS BYPASS ZONE ZONE ZONE ZONE ZONE ZONE BYPASS BYPASS BYPASS BYPASS BYPASS BYPASS ZONE ZONE ZONE ZONE ZONE ZONE BYPASS...
  • Page 36 Module Settings Figure 15: Fan Damper Control Display Module (FDX-008/KI) There are two models of the Fan Damper Control Display modules available. The FDX-008 provides switch control and LED indication of 8 fan damper zones. The FDX-008KI provides switch control of 7 fan damper zones with the eighth zone activated by keyswitch.
  • Page 37 FleX-Net Installation and Operation Manual Figure 16: FDX-008 Block Diagram of Fan and Monitor Set-up OUTPUT MODULES FX-2000N FIRE ALARM PANEL FANS OFF AUTO ON TROUBLE MONITOR MODULES FDX-008/KI FAN/DAMPER CONTROL MODULE Before mounting the FDX-008KI module, if a keyswitch is to be connected, wire the keyswitch to terminals at TS1 as shown in Figure 17 below.
  • Page 38 Module Settings Figure 18: Hardwire Detection Adder Module (DM-1008A) Power connector to P8 of Data cable to P6 or P5 of main fire alarm module, main fire alarm module or to or to P2 of hardwire loop P13 or P12 of hardwire loop controller module, or controller module, or to previous adder module...
  • Page 39 FleX-Net Installation and Operation Manual Figure 19: Hardwire Signal Adder Module (SGM-1004A) ZONE 4 1 2 3 Data cable to P6 or P5 of Power connector to P8 of main fire alarm module, or main fire alarm module or to P13 or P12 of loop to P2 of loop controller ZONE 3 module, or to previous...
  • Page 40 Module Settings Figure 20: Hardwire Relay Adder Module (RM-1008A) 3 2 1 3 2 1 3 2 1 3 2 1 3 2 1 3 2 1 3 2 1 3 2 1 P2: Data cable to P6 or P5 of main fire alarm module, or to previous adder module. P1: Data connector for next adder module.
  • Page 41 FleX-Net Installation and Operation Manual UDACT-300A MAIN BOARD: There are two jumpers on the UDACT-300A which are used for operation/configuration purposes. Jumper JW1 is used to reset the default passcode. Jumper JW2 is required for configuring (which can be done using the FX-2000N Configurator Software) the UDACT-300A.
  • Page 42 Module Settings Table 6: UDACT-300A Cable Connectors and Miscellaneous Cable Connector Function Ribbon Cable for connecting to P4 of FX-2000N main fire alarm module or to P2 header on the PR-300 if used. RS-232C/RS-485 Connection for computer configuration. Connector for CFG-300 Configuration Tool Press and hold this button to test all the UDACT-300A LEDs Lamp Test button This potentiometer is for adjustment of the CFG-300 LCD contrast.
  • Page 43 FleX-Net Installation and Operation Manual ALCN-792M Quad Loop Adder Module with ALCN-792D Daughter Board The new Quad Loop Adder module provides two addressable loops plus an additional two loops as part of the daughter board ALCN-792D which is mounted over the ALCN-792M. The Quad Loop Adder module may be mounted over the main chassis of the FX-2000N Fire Alarm Panel or on any chassis that supports adder boards.
  • Page 44 Module Settings The ALCN-792D Daughter Board provides another two addressable loops when connected to the ALCN-792M Quad Loop Adder Board. This daughter board is mounted over the ALCN-792M. Wire the two addressable loops on the ALCN-792D Daughter Board in the same manner the ALCN-792M addressable loops are wired. Figure 23: ALCN-792D Daughter Board Four mounting holes (mount to...
  • Page 45 FleX-Net Installation and Operation Manual Wire the ALCN-792M Quad Loop Adder module as shown in Figure 24 below. Figure 24: ALCN-792M Quad Loop Adder Module LOOP 1 LOOP 2 RS-485 ALARM OUT CABLE IN COM (-) RS-485 Loop 1 RS-485 heartbeat Loop 2 Active LED Active LED...

  • Page 46: Field Wiring

    Field Wiring Main Fire Alarm Module Terminal Connections Wire devices to terminals as shown in Figure 25 below. Refer to Appendix A for specifications and to LT-1023 for compatible devices. ATTENTION: Do not exceed power supply ratings: Main Chassis: FX-2003-12NDS, FX-2003-12NXTDS, FX-2009-12NDS or FX-2017-12NDS: total current for NACs is 10A max.
  • Page 47 SEE ANALOG LOOP WIRING SECTION ADDRESSES FOR FIRST 8 POWER-LIMITED, 22V DC, 400 mA MAX CARDS AND Maximum Loop Resistance 40 ohms CONNECTION TO MIRCOM RTI SECOND 8 REMOTE TROUBLE INDICATOR CARDS (SEE RTI INSTALLATION RESPECTIVELY INSTRUCTION) BLK TO TRB+ BLU POWER-LIMITED, REGULATED TO TRL-RED &...

  • Page 48: Analog Loop Wiring

    Field Wiring Analog Loop Wiring Figure 27: Loop Terminal Connections - Class B TWIS TE D P AIR WIR E Conventional Heat Sensors and Manual Pull Stations FX-2000N MAIN FIRE ALARM BOARD 2 P air TWO WIR E S ANALOG LOOP CONNECTIONS 4-WIR E...
  • Page 49 FleX-Net Installation and Operation Manual Figure 28: Loop Terminal Connections - Style 7 TWIS TE D P AIR WIR E ADDR ESSABLE SMOKE DETECTOR WITH ISOLATOR BASE FX-2000N MAIN FIRE ALARM BOARD TWIS TE D P AIR WIR E TWIS TE D P AIR WIR E ADDR ESSABLE THER MAL SENSOR...
  • Page 50 Field Wiring Figure 29: Loop Terminal Connections - Style 6 (Formerly Class A) ADDRESSABLE THERMAL SENSOR TWIS TE D P AIR WIR E FX-2000N MAIN FIRE ALARM BOARD TWIS TE D P AIR WIR E ADDRESSABLE SMOKE DETECTORS Conventional 4-Wire Smoke Detectors, Heat Sensors and Manual Pull Stations ANALOG...
  • Page 51 FleX-Net Installation and Operation Manual Figure 30: Quad Loop Terminal Connections - Class B ALCN-792M QUAD LOOP ADDER MODULE TWISTED P AIR WIRE Conventional Heat Sensors ANALOG and Manual Pull Stations LOOP 1 TWISTED PAIR WIRE 2 Pair ANALOG LOOP 2 TWO WIRES FX-2000N LEGEND...
  • Page 52 Field Wiring Figure 31: Quad Loop Adder Module Terminal Connections - Style 7 ALCN-792M QUAD LOOP ADDER MODULE TWISTED PAIR WIRE TWISTED PAIR WIRE ANALOG LOOP 1 ADDRESSABLE SMOKE DETECTOR WITH ISOLATOR BASE TWISTED PAIR WIRE ANALOG LOOP 2 TWISTED PAIR WIRE ADDRESSABLE THERMAL SENSOR WITH ISOLATOR...
  • Page 53 FleX-Net Installation and Operation Manual Figure 32: Quad Loop Adder Module Terminal Connections - Style 6 TWISTED PAIR WIRE ADDRESSABLE THERMAL SENSOR ALCN-792M QUAD LOOP ADDER MODULE ANALOG LOOP 1 ADDRESSABLE SMOKE DETECTORS Conventional 4-Wire Smoke Detectors, Heat Sensors and Manual Pull Stations ANALOG LOOP 2 LEGEND...

  • Page 54: Fnc-2000 Fire Network Controller Module

    Field Wiring FNC-2000 Fire Network Controller Module The FNC-2000 Fire Network Controller modules are wired from terminals marked Line A, positive and negative (see specific cable recommended in Figure 33 to the Line B terminals of the next FNC-2000 module. Use of shielded cable is not recommended.

  • Page 55: Fom-2000-Sp Fiber Optic Network Adder Module

    FleX-Net Installation and Operation Manual FOM-2000-SP Fiber Optic Network Adder Module The FOM-2000-SP Fiber Optic Network Adder Module is wired with fiber optic cable. It is wired OUT through the transmit connectors marked TX and IN through the receive connectors marked RX. Figure 34: FOM-2000-SP Fiber Optic Network Adder Module Wiring STYLE 7 WIRING TX 1...

  • Page 56: Detection Module (Dm-1008A) Terminal Connections

    Field Wiring Detection Module (DM-1008A) Terminal Connections Wire devices to terminals as shown below. See wiring tables, and Appendix A for electrical specifications and document LT-1023 for compatible devices. Figure 35: Hardwire Detection Module (DM-1008A) Terminal Connections INI 1+ STYLE B SUPERVISED INITIATING CIRCUIT #1 (CLASS B) (ALARM ZONE) (POWER LIMITED)

  • Page 57: Signal Module (Sgm-1004A) Terminal Connections

    Legend: SMOKE DETECTOR 3.9K 1/2W ELR LISTED S5434 MODEL MP-300 MANUFACTURED BY MIRCOM Notes: • The terminal blocks are “depluggable” for ease of wiring. • All power limited circuits must use type FPL, FPLR, or FPLP power limited cable. • SGM-1004A NACs are fully supervised and rated for 24 VDC special application, 1.7A max. They must...

  • Page 58: Relay Module (Rm-1008(A)) Terminal Connections

    Field Wiring Relay Module (RM-1008(A)) Terminal Connections Relays are available as shown below. Figure 37: Hardwire Relay Module Terminal Connections RM-1008A Relay Module AUX RELAY 1 AUX RELAY 5 CONTACTS CONTACTS RLY 1 RLY 5 28 VDC, 1 AMP 28 VDC, 1 AMP RESISTIVE LOAD RESISTIVE LOAD AUX RELAY 2...

  • Page 59: Polarity Reversal And City Tie Module (Pr-300) Wiring

    FleX-Net Installation and Operation Manual Polarity Reversal and City Tie Module (PR-300) Wiring Wire PR-300 Polarity Reversal and City Tie Module (if used) as shown in Figure 38 below. Power Limited cable type FPL, FPLR or FPLP must be used. For USA installation, the installer must use Atlantic Scientific (Tel: 407-725-8000), Model #24544 Protective Device, or similar UL-Listed QVRG secondary protector, as shown.

  • Page 60: Udact-300A Main Board Terminal Connections

    Field Wiring UDACT-300A Main Board Terminal Connections Wire the two telephone lines to RJ31X Connector terminals as shown in Figure 39 below. The UDACT-300A terminals are located on the top left hand corner of the board. If using a cellular or wireless service, use the Line 2 interface connection only.

  • Page 61: Power Supply Connections

    FleX-Net Installation and Operation Manual Power Supply Connections The power supply is part of the main chassis. The ratings are outlined in the table below. Power Supply Battery Fuse on Main Model Electrical Input Ratings Total Current Module FX-2003-12NDS, FX-2003- 120 VAC, 60 Hz, 4A / 20 Amp, 1-1/4"...

  • Page 62: Wiring Tables And Information

    Field Wiring Wiring Tables and Information Table 9: Wiring Table for Initiating Circuits. Wire Gauge Maximum Wiring Run to Last Device (ELR) (AWG) 2990 4760 1450 7560 2300 12000 3600 19000 5800 30400 9200 Note: Maximum loop resistance should not exceed 100 Ohms. Table 10: Wiring Table for NACs ain board NACs are rated for 1.7 amps each.
  • Page 63 FleX-Net Installation and Operation Manual Table 11: Analog Loop Wiring Wire Gauge (use Loop Total (Out and In) Maximum twisted pair) Twisted Pair Wire Run (AWG) 10,000 3049 7971 2429 4980 1518 3132 Note: • Line capacitance shall not exceed 0.5 mF. •...

  • Page 64: System Checkout

    System Checkout System Checkout Before Turning the Power On 1. To prevent sparking, do not connect the batteries. Connect the batteries after powering the system from the main AC supply. 2. Check that all modules are installed in the proper location with the proper connections. 3.

  • Page 65: Indicators, Controls, And Operation

    FleX-Net Installation and Operation Manual Indicators, Controls, and Operation Refer to Figure 41 below for LED indicators, control buttons, and switches locations. Figure 41: Indicators and Control Location Queue controls and 16 configurable AC On CPU Fault indicators for Alarm, bi-coloured zone Indicator Indicator...
  • Page 66 Common Indicators Indicators Description The Buzzer is activated by any of the following Fire Alarm - Steady Supervisory Alarm - Fast Rate Trouble - Trouble Rate Buzzer Monitor - Configurable to sound at Trouble Rate If the Buzzer is turned on in response to a Non-Latching Trouble or Supervisory, it will be turned off if the condition causing it goes away and there is no other reason for it to be on.
  • Page 67 FleX-Net Installation and Operation Manual Common Controls LCD Display: The display is a large 4 line by 20 character back-lit alphanumeric LCD. It displays information on the panel and its devices. There are cursor buttons for menu selection and control. Information provided by the LCD display is an alarm log, an event log, current levels, device information, verification and maintenance reports.
  • Page 68 Indicators, Controls, and Operation System Reset Button The System Reset button causes the Fire Alarm Control Panel, and all Circuits, to be reset • Resets all Latching, Trouble Conditions • Resets all Initiating Circuits • Resets 4-Wire Smoke Supply and Aux. Power Supply •...
  • Page 69 FleX-Net Installation and Operation Manual Single Stage Operation In a single stage system, all alarm inputs are treated in a similar manner. Alarm inputs include any of the following: non-verified alarm, verified alarm, sprinkler alarm, water-flow alarm, and general alarm circuits. Any of these alarm inputs occurring when the panel is not already in alarm cause the following: •...
  • Page 70 Indicators, Controls, and Operation Subsequent First Stage alarms when the panel is already in alarm, cause the following: • The buzzer sounds steadily • If signals have been silenced as a result of the silence button or the Auto signal silence timer, signals are resounded as they were before signal silence, the Signal Silence LED turns off, and the Auto Signal Silence timer, if configured, is restarted •...
  • Page 71 FleX-Net Installation and Operation Manual Circuit Types The term circuits refers to an actual electrical interface, either initiating (detection) or indicating (signal). The term zone is a logical concept for a fire alarm protected area, and will consist of at least one circuit. Often the terms zone and circuit are used interchangeably, but in this manual the term circuit is used.
  • Page 72 (open-circuit). This circuit is used for monitoring a trouble condition from an external device such as a Trouble-Only Mircom Series 500 Audio System. Both open and short circuits generate a non-latching trouble condition. Indicating (Signal) Circuits Types...
  • Page 73 FleX-Net Installation and Operation Manual Evacuation Codes Single stage codes On 100% of the time Continuous 3 of 0.5 second on, 0.5 second off then, 1.5 second pause Temporal Code 0.5 second on, 0.5 second off March Code 5 seconds on, 10 seconds off California Code Two-stage codes: Alert Code...

  • Page 74: Configuration

    The FleX-Net network system which includes FX-2003-12N/DS, FX-2009-12N/DS, FX-2017-12N/DS, and FX-2000MNS is configured using Mircom software MSW-025. NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES This product incorporates field-programmable software. In order for the product to comply with the requirements in...

  • Page 75: Typical Flex-Net Tm System Layouts With Audio

    Typical FleX-Net System Layouts with Audio The following figures show two typical applications for the FleX-Net system with audio. Figure 43 below shows a typical FleX-Net system layout with the main lobby control panel as Node 1 and the combination Fire Alarm and Audio Network systems as Node 2 and 3. The diagram also shows addressable fire alarm loops, paging and telephone connections and audio cabinets.
  • Page 76 Typical FleX-NetTM System Layouts with Audio Figure 44 below shows the FleX-Net fire alarm and audio shown within the Integrated Network Fire/Audio cabinet as Node 2 and 3. Paging and telephone devices are hooked up to Nodes 2 and 3. Figure 44: Typical FX-2000N Network System with Audio and Non-Audio Nodes CACF Node 1...

  • Page 77: System Components For The Integrated Fire/Audio Cabinet

    System Components for the Integrated Fire/Audio Cabinet Network Fire Alarm Model Description Main network fire alarm board includes one SLC and four Style Z/Y (Class A/B) NACs. The main FX-2000MNS board is mounted on a backplate which can hold up to 9 internal adder modules.

  • Page 78: Fiber Optics Module

    System Components for the Integrated Fire/Audio Cabinet Fiber Optics Module Model Description Connects to the FNC-2000 Fire Alarm Network FOM-2000-SP Controller Module and allows fiber optics cabling. Adder Modules Model Description DM-1008A, SGM-1004A, Loop and Circuit Adder Modules RM-1008A Auxiliary Modules Model Description PR-300...

  • Page 79: Flex-Net Tm Mass Notification System (Bbx-Fxmns) Enclosure

    FleX-Net Mass Notification System (BBX-FXMNS) Enclosure This enclosure can accommodate all existing modules, except the QMP-5101N Network Master Paging Control module and the QMT-5302N Master Firefighters’ Telephone. New models, QMP-5101NV vertical mounting master paging microphone and QMT-5302NV Master Telephone panels are used instead to mount within the BBX-FXMNS Enclosure.
  • Page 80 FleX-NetTM Mass Notification System (BBX-FXMNS) Enclosure The BBX-FXMNS backbox supports the QMB-5000N amplifier backplane and card cage which holds up to four amplifiers, the FX-2000MNS Fire Alarm main board chassis and PS-2040 Power Supply. Figure 46: BBX-FXMNS Backbox Dimensions and Contents BBX-FXMNS Backbox 16.5”...
  • Page 81 FleX-Net Installation and Operation Manual Figure 47: BBX-FXMNS Enclosure Complete View BBX-FXMNS FRONT DOORS AND DEADFRONT CHASSIS BBX-FXMNS BACKBOX...
  • Page 82 FleX-NetTM Mass Notification System (BBX-FXMNS) Enclosure Figure 48: Mounting Vertical Microphone and Telephone Modules in the BBX-FXMNS Back side of BBX-FXMNS inner door Door Hinge Modules are mounted from the backside of the middle door using the screws provided Door Hinges Door Hinge...

  • Page 83: Mechanical Installation For The Expansion Audio Cabinet

    Mechanical Installation for the Expansion Audio Cabinet QBB-5001/R Expansion Audio Cabinet Installation Expansion audio cabinets are mounted as shown in Figure 49 below. The QBB-5001/R is the backbox and door. The QBB-5001/R backbox may be flush or surface mounted. The QBB-5001TR is the metal flush trim. Install all cabinets and enclosures empty.

  • Page 84: Bbx-Fxmns Audio Module Placement And Internal Wiring

    BBX-FXMNS Audio Module Placement and Internal Wiring The modules that mount into the audio card cage are the amplifier modules. Up to four amplifiers may be installed in each BBX-FXMNS enclosure with one of the four as a backup. Slot #1 is used for the ANC-5000 and/or TNC- 5000 modules.

  • Page 85: Integrated Fire Alarm Connection

    Integrated Fire Alarm Connection The FX-2000MNS Chassis consists of the Network Fire Alarm main board and chassis. Battery Power The power cable is used to provide power from the batteries to the FX-2000MNS Fire Alarm main board and the audio card cage motherboard. Power from the batteries is first directed to the Battery Disconnect Board, from this board the power is connected to the main fire alarm board and the audio card cage.

  • Page 86: Qbb-5001/R Expansion Audio Cabinet Module Placement

    QBB-5001/R Expansion Audio Cabinet Module Placement The modules that mount into the QBB-5001/R expansion audio cabinet include the QPS-5000N Power Supply, the QMB-5000B Motherboard, and the QBC-5000N Battery Charger. Module interconnects are shown in Figure 51. There is no module installed into Slot #1 of the QMB-5000B Motherboard, as shown below. Up to seven Amplifier Modules (Models QAA-5230-70/25, QAA-5230S-70/25, QAA-5415-70, QAA-5415-25 and/or QAA-5160-70/25) may be installed into Slots #2 to #8 on the QMB-5000B motherboard.

  • Page 87: Qps-5000N Power Supply Connection

    FleX-Net Installation and Operation Manual QPS-5000N Power Supply Connection Two jumpers are provide as shown in figure below for 120 VAC connection. For 240 VAC application, remove both jumpers and replace one jumper between the two middle terminals. The two terminals on the right are N (neutral), L (live) for AC voltage connection.

  • Page 88: Installing And Removing Amplifiers

    When multiple QBB-5001/R audio cabinets are used in an installation, each has its own QPS-5000N Power Supply, QBC-5000N Battery Charger, and batteries. A total of three audio cabinets may be used by simply interconnecting with Mircom MD-525 Extension Cables from the QMB-5000N "Out" Connector, to the "In" Connector on the next QMB-5000B motherboard.
  • Page 89 FleX-Net Installation and Operation Manual motherboard #3. Figure 53: Interconnecting Extra QMB Motherboard Amplifiers are defined as in slot positions 2 to 5 for the Node Motherboard QMB-5000N QMB-5000N NODE MOTHERBOARD Regular MD-525 Ribbon Cable QMB-5000B EXPANSION MOTHERBOARD #1 Regular MD-525 Ribbon Cable QMB-5000B EXPANSION MOTHERBOARD #2 Special MD-525 Ribbon Cable...

  • Page 90: Audio Network Card And Telephone Network Card

    Audio Network Card and Telephone Network Card Each Integrated Fire/Audio Cabinet requires an ANC-5000 Audio Network Controller Card. The TNC-5000 Telephone Controller Network card is necessary only if Telephone circuits are required. Below is a diagram for mounting both audio and telephone cards into the large network fire alarm chassis, FX-2009-12NDS.

  • Page 91: Audio Amplifier Wiring

    WIRING MANUFACTURED BY SPEAKER Class A or B EXAMPLE MIRCOM 30 WATTS MAX Notes: • All circuits are power limited and supervised. • Cut jumper J1 when using an isolator. • There are two fuses on this board. Both are 4A fast blow.

  • Page 92: Qaa-5230S-70/25 Amplifier Wiring

    Figure 56: QAA-5230S-70/25 Wiring QAA-5230S-525-70/25 22 K, 1W ELR 1/2 OF TERMINAL BLOCK MODEL MP-302 SPEAKER MANUFACTURED BY ZONE B MIRCOM 25 Watts CLASS B 30 WATTS 22 K, 1W ELR 1/2 OF MODEL MP-302 MAX EACH SPEAKER MANUFACTURED BY...

  • Page 93: Qaa-5415-70 And Qaa-5415-25 Amplifier Wiring

    QAA-5415 but instead of 70 Volts it is 25 Volts. Figure 57: QAA-5415-70 or QAA-5415 Wiring QAA-5415-70 OR QAA-5415-25 22K, 1W ELR TERMINAL BLOCK MODEL MP-302 ZONE D SPEAKER MANUFACTURED BY MIRCOM 22K, 1W ELR MODEL MP-302 ZONE C SPEAKER MANUFACTURED CLASS B WIRING BY MIRCOM 15 WATTS...
  • Page 94 Audio Amplifier Wiring Figure 58: Using a Speaker Isolator with the QAA-5415-70 or QAA-5415-25 Amplifiers QAA-5415-70/25 AMPLIFIER CUT JUMPER OVER U3 WHEN USING A SPEAKER ISOLATOR JUMPER Note: When using a speaker isolator (SISA-204 or SISA-204 for use in Canada only), jumper JP1 (top left- hand corner, component side) must be cut on the QAA-5230-70/25 and on the QAA-5160-70/25.
  • Page 95 FleX-Net Installation and Operation Manual Figure 59: QAA-4CLA Class A Converter For QAA-5415-70/25 Amplifier...
  • Page 96 Audio Amplifier Wiring Figure 60: QAA-4CLAS Class A Converter For QAA-5230S-70/25 Amplifier...

  • Page 97: Qaa-5160-70/25

    MODEL MP-301 SPEAKER MANUFACTURED 60 WATTS MAX BY MIRCOM Notes: • All circuits are power limited and supervised. • There are two fuses on this board. Both are 8A fast blow. • See speaker wiring chart for wire gauge selection.
  • Page 98 Audio Amplifier Wiring Table 12: Wiring Chart for 70V Speakers Maximum Wiring Run To Last Device (ELR) Total Power 18AWG 16AWG 14AWG 12AWG Watts 2500 4000 1219 6000 1828 8000 2438 1500 2500 4000 1219 6000 1828 1200 2000 3500 1066 Notes for Wiring Charts: 1.

  • Page 99: Backup Amplifier

    FleX-Net Installation and Operation Manual Backup Amplifier Any amplifier may be designated as a backup amplifier when backup is required. It should be installed in any audio cabinet and in the right-most slot position of a QMB-5000B backplane. Figure 62: QAA-5160-70/25 Amplifier (Backup Application) Any amplifier may be designated as the backup amplifier and this backup amplifier...

  • Page 100: Displays & Controls

    Displays & Controls Displays & Controls Figure 63: Audio Cabinet Displays and Controls PAGE PAGE PAGE PAGE PAGE PAGE PAGE EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC...

  • Page 101: Setup

    FleX-Net Installation and Operation Manual Setup QBB-5001/R Amplifier Installation The following instructions are based on the assumption that the fire alarm is already installed. 1. Install the QBB-5001/R Audio Backbox and door in the desired location. 2. Install the QMB-5000B Motherboard / Card-Cage into the backbox. 3.

  • Page 102: Lobby Enclosures

    Lobby Enclosures The QMP-5101N paging and QMT-5302N telephone control modules fit into the BB-5008 and BB-5014 lobby backboxes. All selector panels mount into the BB-5008 and BB-5014 backboxes also. Below find the dimensions for both the backboxes. Figure 64: BB-5008 and BB-5014 Backboxes BB-5014 Lobby Backbox BB-5008 Lobby Backbox Notes:...

  • Page 103: Anc-5000 Audio Network Controller Module

    FleX-Net Installation and Operation Manual ANC-5000 Audio Network Controller Module Figure 65: ANC-5000 Audio Network Controller board Connects to TNC-5000 Telephone Network Controller Module P7 AMPS Interface Heartbeat RESET/CPU Fail System OK COMM RX COMM TX LEDs for Plugs into the Audio/CLASS D TX Information QMB-5000N...

  • Page 104: Anc-5000 Wiring

    ANC-5000 Wiring Figure 66: ANC-5000 Wiring Diagram JW7 JW8 PAGING BUS + - L + - S + - S + - + - + - S + - S Alternate G.A. RS-485 Power Input Wire the Paging Bus Microphone to all other ANC-5000 and push to Audio Network...
  • Page 105 FleX-Net Installation and Operation Manual Figure 67: Audio Paging Bus Wiring CLASS A WIRING Paging Paging Bus Out Bus In ANC-5000 ANC-5000 Paging Paging Node 4 Node 5 Bus In Bus Out Paging Paging Bus Out Bus In ANC-5000 ANC-5000 Paging Paging Node 3...

  • Page 106: Qmp-5101Nv Vertical Paging Control Module

    QMP-5101NV Vertical Paging Control Module The QMP-5101NV Paging Module fits into the new BBX-FXMNS Enclosure. It mounts on the inside dead chassis (part of the BBX-FXMNS). CONNECTIONS AND TERMINAL WIRING ARE THE SAME AS THE QMP-5101N, WIRE AS SHOWN IN THE FOLLOWING INSTRUCTIONS FOR QMP-5101N PAGING CONTROL MODULE. Figure 68: QMP-5101NV Vertical Paging Control Module...

  • Page 107: Paging Modules

    FleX-Net Installation and Operation Manual Paging Modules The QMP-5101N Network Master Paging Control Module mounts into the BB-5008 and BB-5014 backboxes. QMP-5101N Network Master Paging Control Module The QMP-5101N Network Master Paging Control Module connects via a ribbon cable to the first QAZT-5302DS Zoned Selector Panel and to the previous display module.
  • Page 108 Paging Modules Figure 70: QMP-5101N/V Network Master Paging Control Module Connections and Terminal Blocks TO NEXT MICROPHONE (IF THIS IS THE LAST FROM PREVIOUS MICROPHONE, MICROPHONE PLACE EOL 3K9 ohm RESISTOR HERE SHIELD SHIELD BETWEEN + and - OF PTT TERMNALS). SHIELD SHIELD TO QAZT-5302 SELECTOR PANEL...

  • Page 109: Qmp-5101N/V Network Paging Wiring

    FleX-Net Installation and Operation Manual QMP-5101N/V Network Paging Wiring Figure 71: QMP-5101N/V Network Master Paging Control Module Wiring to the ANC-5000 Audio Network Controller Module QMP-5101N/V Network Master Paging Module Master microphone and push to talk button are wired by Factory to these terminals This connection to Aux Power is required when...

  • Page 110: Qazt-5302Ds Zoned Paging Selector Panel

    Paging Operation QAZT-5302DS Zoned Paging Selector Panel Each QAZT-5302DS annunciates and controls up to 24 audio zones. There is one button and two LEDs per zone. The lower amber LED indicates Zone trouble. The upper green LED indicates whether that Paging Paging Paging...

  • Page 111: Qmp-5101N/Qmp-5101Nv Pushbutton Controls

    FleX-Net Installation and Operation Manual QMP-5101N/QMP-5101NV Pushbutton Controls Warden Page Button When depressed, the Warden Page button enables voice paging from the firefighters' telephone (if connected) to all zones selected for paging, unless page inhibit is active. Note that pressing PTT will not result in any paging activity unless there are zones selected for paging.

  • Page 112: Tnc-5000 Telephone Network Controller Module

    TNC-5000 Telephone Network Controller Module Module Mounting Locations The TNC-5000 Telephone Network Controller board can be mounted in two places. The TNC-5000 Telephone Network Controller Board is mounted above (beside) the ANC-5000 Audio Network board, both are mounted on a metal backplate and the ANC-5000 plugs into slot 1 on the QMB-5000N audio backplane of the BBX-FXMNS, see 72.

  • Page 113: Typical Addressable Telephone Set-Up

    FleX-Net Installation and Operation Manual Figure 73: Mechanical Installation of the TNC-5000 within the BB-5008 and BB- 5014 TNC-5000 Partial Interior View TNC-5000 board (to right of main board) mounts over ANC-5000 board ANC-5000 Metal plate mounts over positions 4 to 9 inclusive Typical Addressable Telephone Set-up The typical addressable telephone set-up is with an addressable fire alarm system using the TNC-5000 and from...

  • Page 114: Connectors And Terminal Locations

    Connectors and Terminal Locations Connectors and Terminal Locations Refer to 75 for connector and terminal locations. Table 3 below shows the cable connections and jumpers required and additional wiring. Table 3: TNC-5000 Connectors and Terminals TNC-5000 Connects to Connector and Terminals P10 Cable P11 on the ANC-5000 Audio Network Controller Module.

  • Page 115: Tnc-5000 Telephone Wiring

    FleX-Net Installation and Operation Manual TNC-5000 Telephone Wiring Figure 76: Telephone Bus Wiring Diagram Tel. Bus Tel. Bus TNC-5000 TNC-5000 Tel. Bus Tel. Bus Tel. Bus Tel. Bus TNC-5000 TNC-5000 Tel. Bus Tel. Bus Tel. Bus Tel. Bus TNC-5000 TNC-5000 Tel.
  • Page 116 TNC-5000 Telephone Wiring Master Telephone (if used) at the main fire alarm center, otherwise Zone 1 is wired as another telephone zone when a master telephone is not required. Figure 77: TNC-5000 Telephone Zone Wiring FROM PREVIOUS FIREPHONE MODULE. E.O.L 10K ohms TWISTED SHIELDED PAIR IS RECOMMENDED USE TWISTED SHIELDED PAIR...

  • Page 117: Qmt-5302Nv Vertical Master Telephone

    FleX-Net Installation and Operation Manual QMT-5302NV Vertical Master Telephone The QMT-5302NV Vertical Master Telephone Module fits into the new BBX-FXMNS Enclosure. The master telephone is mounted to the inside chassis and field wiring is on the BBX-FXMNS backbox. CONNECTIONS AND TERMINAL WIRING ARE THE SAME AS THE QMT-5302N, WIRE AS SHOWN IN THE FOLLOWING INSTRUCTIONS FOR QMT-5302N MASTER FIREFIGHTERS’...

  • Page 118: Qmt-5302N Master Firefighters' Telephone

    QMT-5302N Master Firefighters’ Telephone The QMT-5302N mounts into the BB-5008 and BB-5014. QMT-5302N Network Master Firefighters' Telephone Control Module is used in conjunction with the FleX-Net Fire Alarm system at the CACF Node. Slide-in labels (NP-6657) are supplied with the Master Telephone. Place labels as shown in 79. The QAZT-5302DS Telephone Selector panels are used for selecting telephone zones (up to 24 zones per selector panel) and include blank labels for labelling the telephone zones.

  • Page 119: Qmt-5302N Connections

    FleX-Net Installation and Operation Manual QMT-5302N Connections The connections required on the QMT-5302N Network Master Firefighters’ Telephone Control Module are the cable from the previous display module to P1 or IN connector on the bottom left of the board and the OUT connection goes to the IN connector of the next display board.

  • Page 120: Qazt-5302Ds Network Firefighters' Telephone Selector Panel

    QAZT-5302DS Network Firefighters’ Telephone Selector Panel Figure 81: QAZT-5302DS Network Firefighters' Telephone Selector Panel Each QAZT-5302DS annunciates and controls up to 24 telephone zones. There is one button and two LEDs per zone. The lower amber LED indicates zone Telephone Telephone Telephone Telephone...
  • Page 121 FleX-Net Installation and Operation Manual Connect the first QAZT-5302DS Network Firefighters’ Telephone Selector panel to the master telephone by connecting the Ribbon In cable into P2 on the QMT-5302N/NV Master Telephone. Ribbon Out cable to the Ribbon In of the next QAZT-5302DS or P1 of the next display panel (up to six total). See diagram below. QAZT-5302DS can be used as a telephone or paging selector panel by installing a jumper, see diagram below.

  • Page 122: Telephone Operation

    Telephone Operation Telephone Operation 1. When any telephone zone rings (the local buzzer sounds intermittently, and the green zone LED and Incoming Call LED flash) press that zone's button (on the selector panel QAZT-5302DS) once to answer. Once any one zone has been answered, calls from any other zone will cause that zone's green LED and the Incoming Call LED at the master telephone to flash and the buzzer will sound.

  • Page 123: Appendix A: Specifications

    FleX-Net Installation and Operation Manual Appendix A: Specifications Main Fire Alarm Chassis (FX-2017-12NDS) Main Fire Alarm Chassis (FX-2003-12NDS) General Same as FX-2009-12N/DS except: Larger Chassis has capacity for 3 display modules and 17 adder One Analog Loop capable of monitoring 159 AP Sensors and modules.

  • Page 124: Compliance

    Appendix A: Specifications ANC-5000 Audio Controller Module RAXN-LCDG Annunciator standby: 255 mA 24V DC nominal. Current Consumption: Standby: 117 mA Max., All LED's "On": 150 mA Max alarm: 265 mA TNC-5000 Telephone Controller Module RAXN-LCD Annunciator standby: 195 mA Current Consumption: 24V DC nominal, range of 20 to 39V DC.

  • Page 125: Uli/Ulc Integrated Fire Alarm And Audio Panel Specifications

    FleX-Net Installation and Operation Manual ULI/ULC Integrated Fire Alarm and Audio Panel Specifications Note: All circuits are power limited, unless specified otherwise. Overall PS-2040 Power Supply • 0 to 49 degrees Celsius, 0 to 93 + or - 2% RH (non-condensing) operating range •...
  • Page 126 • Current consumption: standby: 55mA alarm: 350mA, plus 75mA/watt speaker power Model QMP-5101N or QMP-5101NV Paging Microphone • Mounts in Mircom BB-1000, BB-5000, FX-LOC, and BBX-FXMNS (for QMP-5101NV) enclosures • Current Consumption: standby: 3mA alarm: 7mA Model QAZT-5302/DS Paging Selector Panel •...

  • Page 127: Appendix B: Power Supply And Battery Calculations

    FleX-Net Installation and Operation Manual Appendix B: Power Supply and Battery Calculations Power Requirements (All currents are in amperes) Total Total Model Number Description Standby Alarm Standby Alarm Main Chassis (12 Amp) 0.310 0.733 FX-2003-12NDS FX-2017-12NDS Main Chassis (12 Amp) 0.310 0.733 FX-2009-12NDS...

  • Page 128: Raxn-Lcd/Raxn-Lcdg

    20 character backlit alphanumeric LCD display (or for the RAXN-LCDG a graphical display) which uses a simple menu system complete with a directional key pad and switches for Enter, Menu, Cancel and Info. For more information see Mircom documents LT-895 and LT-6033. Models: •...

  • Page 129: Appendix C: Dip Switch Settings

    FleX-Net Installation and Operation Manual Appendix C: DIP Switch Settings FX-200X-XX Network Main Board Address Setting (DIP SWITCH SW2) SW2 DIP SWITCHES Node Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8...

  • Page 130: Anc-5000 Board With Ethernet Port, Address Setting (Dip Switch Sw1)

    Appendix D: Alarm Verification Timing ANC-5000 Board with Ethernet Port, Address Setting (DIP SWITCH SW1) ADDR SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8 ANC-5000 Board without Ethernet Port, Address Setting (DIP SWITCH SW1) ADDR SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8...

  • Page 131: Appendix E: Wiring For Addressable Supervised Output Module

    Appendix E: Wiring For Addressable Supervised Output Module CSIS - 202A CSIS - 202A Supervised Signal Supervised Signal BPS -1100 Isolator #1 Isolator #2 Booster Power Supply ROOM 2 ROOM1 ROOM1 ROOM 2 RETURN RETURN RETURN RETURN ROOM1 ROOM 2 ROOM1 ROOM 2 SIGNAL...

  • Page 132: Appendix F: Ulc Compatible Speakers

    Appendix F: ULC Compatible Speakers MIRCOM MODEL NUMBER dbA @ 10 feet Mounting and Shape 4" Speakers (70V) SP-104A-70 (4"round) IB-104 Recessed Round 1/4 watt 85 dbA 1/2 watt 86 dbA IB-204 Recessed, IB-404 SP-204A-70 (4"square) Square Surface 1 watt...

  • Page 133: Appendix G: Uli Compatible Speakers

    FleX-Net Installation and Operation Manual Appendix G: ULI Compatible Speakers COOPER-WHEELOCK MODEL NUMBER dbA @ 10 feet Mounting and Shape Square Speakers (25V or 70V) 1/8 watt 77 dBA 1/4 watt 81 dbA E50-R (red) 1/2 watt 83 dbA Standard Electrical Box, 5” square speaker E50-W (white) 1 watt 86 dbA...

  • Page 134: Appendix H: Power Supply & Batteries For Audio

    Appendix H: Power Supply & Batteries for Audio Use the form below to determine the required main chassis and secondary power supply (batteries). IMPORTANT NOTICE The main AC branch circuit connection for Fire Alarm Control Unit must provide a dedicated continuous power without provision of any disconnect devices.

  • Page 135: Appendix I: Fxmns Used As A Mass Notification System (Acu)

    Installation and Operation Manual Appendix I: FXMNS Used as a Mass Notification System (ACU) The MNS portion of a complete Mircom FleX-Net Network Fire Alarm system consists of a BBX-FXMNS Enclosure (see Node 2 in figure below). The BBX-FXMNS includes a RAXN-LCD Annunciator which is designated an ACU (Autonomous Control Unit) and a Master Microphone to provide emergency audio.

  • Page 136: Qmp-5101N Network Paging Wiring For Mass Notification

    QMP-5101N Network Paging Wiring for Mass Notification Figure 84: QMP-5101N Network Master Paging Control Module Wiring to the ANC- 5000 Audio Network Controller Module MNS - ACU FX- LOC(R) TWISTED QMP-5101N Network QMP-5101N Network SHIELDED Master Paging Module Master Paging Module PAIR CABLE Daisy chain PTT and...

  • Page 137: Configuration For Mass Notification

    FleX-Net Installation and Operation Manual Configuration for Mass Notification There are two groups that can be created for the nodes; one group is the fire/central control and the second is mass notification. In order to have this distinction, all zones have to be assigned a “Zone Priority”. Priority can be high, low, normal or a percentage of + or - increments of 5.
  • Page 138 Configuration for Mass Notification This screen capture shows selection of Node 2 as Mass Notification Select Node 2 as the MNS Mass Notification System.

  • Page 139: Acu Emergency Response Operation

    FleX-Net Installation and Operation Manual This screen capture shows input zone priority settings for the Mass Notification Node 2 FX-LOC(R) Active As part of the Mass Notification requirements, an RAX-1048TZDS Zone Annunciator is part of the MNS. Configure one zone of the RAX-1048TZDS per each FX-LOC(R) connected to the MNS (ACU). Each LED is configured to illuminate when the respective FX-LOC(R) paging is in use.

  • Page 140: Appendix J: Apb-200/Coa Sounder Bases

    Appendix J: APB-200/COA Sounder Bases The FleX-Net Network Fire Alarm system can accommodate up to 32 APB-200/COA sounder bases per panel (node). The sounder base audio is synchronized on the same loop basis. Below is a wiring diagram for connecting the sounder bases to auxiliary power with supervision. Figure 85: Sounder Base Wiring to Auxiliary Power Supply with Supervision COSAP/A Fire CO COSAP/A Fire CO...

  • Page 141: Warranty & Warning Information

    FleX-Net Installation and Operation Manual Warranty & Warning Information Warning Please Read Carefully Note to End Users: This equipment is subject to terms and conditions of sale as follows: Note to Installers This warning contains vital information. As the only individual in contact with system users, it is your responsibility to bring each item in this warning to the attention of the users of this system.
  • Page 142 Warranty & Warning Information be able to reach the alarm initiating device, such as when the fire is in a chimney, walls or roofs, or on the other side of closed doors; and, smoke and heat detectors may not detect smoke or heat from fires on another level of the residence or building.
  • Page 143 Installation and Operation Manual Limited Warranty Mircom Technologies Ltd., MGC Systems Corp. and MGC System International Ltd. together with their subsidiaries and affiliates (collectively, MGC) warrants the original purchaser that for a period of three years from the date of shipment, proprietary manufactured product shall be free of defects in materials and workmanship, under normal use.
  • Page 144 Warranty & Warning Information Out of Warranty Repairs MGC will at its option repair or replace out-of-warranty products which are returned to its factory according to the following conditions. Anyone returning goods to MGC must first obtain an authorization number. MGC will not accept any shipment whatsoever for which prior authorization has not been obtained.
  • Page 148 CANADA - Main Office U.S.A TECHNICAL SUPPORT © Mircom 2016 25 Interchange Way 4575 Witmer Industrial Estates North America Printed in Canada Vaughan, ON L4K 5W3 Niagara Falls, NY 14305 Tel: (888) Mircom5 Subject to change without prior notice Tel: (888) 660-4655...

Table of Contents
