Mircom MPS-800MP Series Quick Start Manual

FIRE ALARM ADDRESSABLE MANUAL PULL STATIONS
MPS-810MP(U)
1 Stage
Description
Mircom's MPS-800MP(U) Series Fire Alarm Manual Pull
Stations provide manual fire alarm activation. The new
MPS-800 Series uses raised symbols and icons instead of
printed text that makes them universally recognized.
These addressable pull stations are available as single or two
stage dual action devices. Compatible with FX-400 Series and
Flex-Net FX-4000 Fire Alarm Panels.
The MPS-800MP(U) manual stations are constructed of
high quality polycarbonate resin thermoplastic "LEXAN" that
supports high temperatures without deforming.
The MPS-800MP(U) addressable pull stations are accessible
from the front for wiring while mounted making it easy to install.
These pull stations can be mounted on a single gang backbox
and the mounting holes permit easy alignment to the wall.
The suffix "U" indicates USA version.
All manual fire alarm stations shall be installed as per the
specific requirements outlined in the UL/ULC codes, as well
as all other applicable national or local codes.
Addressing is done using the MIX-4090 Device Programmer.
For setting the address on this device, disconnect it from the
loop, or ensure that the loop to which is connected is both
disconnected from the panel and shorted across the SCL+ and
SLC- inputs at the device. Failing to take either of these steps
may change the address programming of previously configured
sensors on the loop.
NOT TO BE USED FOR INSTALLATION PURPOSES.
THIS INFORMATION IS FOR MARKETING PURPOSES ONLY AND
NOT INTENDED TO DESCRIBE THE PRODUCTS TECHNICALLY.
Features
•
•
•
•
•
•
•
•
•
•
•
MPS-802MP
•
2 Stage
•
Operation
Activating the Alarm
•
•
Activating the stage two alarm (MPS-802MP and
MPS-822MP)
•
•
Resetting the manual station
•
•
•
•
Note: Resetting the station does not cancel the alarm at the
MPS-800MP(U) SERIES
Completely made of LEXAN material
Closed-fist operation (ADA – Americans with Disability Act)
No printed text on the devices, symbols and icons are
used instead
Symbols are raised to be easily recognized by touch
Compatible with FX-400 Series and Flex-Net FX-4000 Fire
Alarm Panels
Easy installation
Accessible from the front for wiring while mounted
Mounts on a single gang backbox
Temperature range from 0ºC to 49ºC
UL and ULC listed
Device comes with a reset key
Indoor use only
Alarm LED is viewable from the front - Useful for trouble
shooting
Push in the push bar
Pull down the pull handle
Insert the stage two key into the stage two keyhole, and
then turn the key.
The stage two alarm activates immediately.
Insert the key into the reset keyhole and turn it.
Pull the cover open. The switch is now reset.
Close and lock the stations with the reset key.
Reset the Fire Alarm Control Panel to reset the alarm
panel
CATALOG NUMBER
5964
