UM-WI-056
DA16200 DA16600 FreeRTOS Getting Started Guide
Switch Pin
9 Does not use
10 Does not use
SW3 1 Enables UART1 of DA14531 (1-wire UART)
2 Enables UART1 of DA14531 (1-wire UART)
SW4 1 Manual control of the internal RF SPDT.
Pin1 OFF & Pin2 OFF: internally controlled.
Pin1 ON & Pin2 OFF: DA14531 RF path ON
2
Pin1 OFF & Pin2 ON: DA16200 RF path ON
SW5 1 Measures current consumption of DA16200 with
DA16600 EVK Pro
2 Measures current consumption of DA14531 with
DA16600 EVK Pro
The current consumption can be measured at jumpers P1 and P2 with current measuring equipment.
See Section 6.5 f or details on the test setup.
When DA16600 EVK Pro is used f or measuring current consumption, remove jumpers P1 and P2
and set pins 1 and 2 of SW5 to the ON position.
To measure the current consumption of DA16200, remove the jumper on P2 and turn ON pin1 of
SW5. To measure the current consumption of DA14531, remove the jumper on P1 and turn ON pin2
of SW5. The current consumption of the DA16200 and the DA14531 can be measured
simultaneously. For more details on the DA16600 EVB, see the DA16600 DEVKT Electric Schematic
Ref . [10].
User Manual
CFR0012
Description
Revision 1.8
83 of 106
Relevant pin
- -
- -
DA14531 P0_5/WLAN_ACT
DA14531 P0_5/WLAN_ACT
DA14531 P0_6/BT_ACT
- -
- -
© 2023 Renesas Electronics
Default
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
